Anritsu Field Master Pro Manual de usuario

Part Number: 10580-00492

Revision: C

Published: January 2023

Anritsu Company

490 Jarvis Drive

Morgan Hill, CA 95037-2809

USA

Measurement Guide

High Accuracy Power Meter

MS2090A Field Master Pro™

MS2080A Field Master™

MS2070A Field Master™

High Accuracy Power Meter Option 19

Notes

Power Meter measurements require a supported Anritsu USB power sensor that is sold separately.

Not all instrument models offer every option or every measurement within a given option. Refer to

the Technical Data Sheet of your instrument for available options and supported measurements.

Front-2 PN: 10580-00492 Rev. C High Accuracy Power Meter MG

Unauthorized Use or Disclosure

Anritsu Company has prepared the product user documentation for use by Anritsu Company personnel and

customers as a guide for the proper installation, operation, and maintenance of Anritsu Company equipment and

software programs. The drawings, specifications, and information contained therein are the property of Anritsu

Company, and any unauthorized use of these drawings, specifications, and information is prohibited; they shall not be

reproduced, copied, or used in whole or in part as the basis for manufacture or sale of the equipment or software

programs without the prior written consent of Anritsu Company.

Export Management

The Anritsu products identified herein and their respective manuals may require an Export License or approval by

the government of the product country of origin for re-export from your country. Before you export these products or

any of their manuals, please contact Anritsu Company to confirm whether or not these items are export-controlled.

When disposing of export-controlled items, the products and manuals must be broken or shredded to such a degree

that they cannot be unlawfully used for military purposes.

Contacting Anritsu for Sales and Service

To contact Anritsu, visit the following URL and select the services in your region:

http://www.anritsu.com/contact-us

High Accuracy Power Meter MG PN: 10580-00492 Rev. C Contents-1

Table of Contents

Chapter 1—General Information

1-1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

1-2 Option Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

1-3 Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

User Interface Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Illustrations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

1-4 Calibration and Verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

1-5 Contacting Anritsu for Sales and Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Chapter 2—High Accuracy Power Meter (Option 19)

2-1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

2-2 High Accuracy Power Meter GUI Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Status Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

2-3 General Measurement Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Example Measurement Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

2-4 AMPLITUDE Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

2-5 SETUP Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

2-6 ZERO/CAL Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

2-7 LIMIT Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

2-8 Presetting the Analyzer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

PRESET Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

2-9 Saving and Recalling Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Saving a Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Recalling a Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

FILE Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10

Contents-2 PN: 10580-00492 Rev. C High Accuracy Power Meter MG

High Accuracy Power Meter MG PN: 10580-00492 Rev. C 1-1

Chapter 1 — General Information

1-1 Introduction

This measurement guide covers the Anritsu High Accuracy Power Meter (Option 19) calibration and setup

measurements. Instruments with Option 19 and an appropriate Anritsu power sensor can be used to make

high accuracy power measurements.

Related Manuals

For additional information and literature covering your product, visit the product page of your instrument and

select the Library tab:

http://www.anritsu.com/en-US/test-measurement/products/ms2090a

http://www.anritsu.com/en-us/test-measurement/products/ms2080a

http://www.anritsu.com/en-us/test-measurement/products/ms2070a

Product Information, Compliance, and Safety

Read the Product Information, Compliance, and Safety Guide for important safety, legal, and regulatory

notices before operating the equipment, PN: 10100-00069.

User Guide

For a complete overview of the instrument hardware and system functions, refer to your instrument user

guide. The user guide provides information on the following topics:

•Listing of all related documentation such as measurement guides, programming and maintenance

manuals.

•Instrument Care, maintenance and calibration

•External Connections to the top and side panels

•Power Requirements and Battery Information

•System settings such as Wi-Fi, GNSS/GPS, date/time, language settings, etc.

•Other advanced settings and tools such as file management, screenshot settings, port setup, and option

configuration.

•Diagnostics and software updates

1-2 Option Description General Information

1-2 PN: 10580-00492 Rev. C High Accuracy Power Meter MG

1-2 Option Description

This section provides a brief overview of the available options covered in this guide.

The High Accuracy Power Meter Option 19 uses an external USB power sensor (sold separately) to facilitate

high accuracy power measurements using Field Master Series instruments as the host controller. Refer to

Table 2-1, “Option 19 USB Power Sensors in Chapter 2.

1-3 Document Conventions

The following conventions are used throughout the instrument documentation set.

User Interface Navigation

The instrument user interface consists of menus, buttons, toolbars, and dialog boxes. Elements in navigation

paths are separated as follows: MARKER > PEAK SEARCH > NEXT PEAK.

Illustrations

Screen-captured images contained in this document are provided as examples. The chapters included in this

measurement guide provide information on advanced measurement features, instrument settings and menu

overviews, for a featured option. The actual displays, screen menus, and measurement details may differ based

on the instrument, model, firmware version, installed options, and current instrument settings.

1-4 Calibration and Verification

The instrument comes fully calibrated from the factory and there are no field-adjustable components. Anritsu

recommends annual calibration and performance verification by local Anritsu service centers. Accredited

calibration to ISO17025 and ANSI/NCSL Z540-1 are available and can include a calibration certificate, test

report, and uncertainty data. Contact Anritsu sales and service centers for more information.

1-5 Contacting Anritsu for Sales and Service

To contact Anritsu, visit the following URL and select the services in your region:

http://www.anritsu.com/contact-us

Note

Not all instrument models offer every option. Some options are available as a time-limited trial.

For example, High Accuracy Power Meter is offered as a 90-day time-limited option by ordering

Option 9019. The option start time begins when the user first activates the option. Please refer

to the Technical Data Sheet of your instrument for information on purchasing and activating

time-limited options.

High Accuracy Power Meter MG PN: 10580-00492 Rev. C 2-1

Chapter 2 — High Accuracy Power Meter

(Option 19)

2-1 Introduction

This chapter covers the Anritsu High Accuracy Power Meter (Option 19) measurements for in use with

Field Master Series handheld instruments. Instruments with Option 19 and an appropriate Anritsu power

sensor can be used to make high accuracy power measurements. This option provides accurate, true RMS

measurements for both CW and complex digitally modulated signals. Table 2-1 lists the Option 19 compatible

with Anritsu power sensors. This chapter provides a general overview of the instrument and its user interface.

Note

The Anritsu power sensor is not included with Option 19. A high accuracy power sensor must be

purchased separately and the instrument must have compatible firmware that supports your installed

sensor. Visit www.anritsu.com for details.

Table 2-1. Option 19 USB Power Sensors

Model Description Frequency Range

Connector

(50 Ω)

Data Sheet

(for complete

specifications)

MA24104Aa

a. The MA24104A sensor is discontinued and is replaced by the MA24105A.

Inline High Power

Sensor 600 MHz to 4 GHz Type N(f) 11410-00483

MA24105Ab

b. The MA24105A provides additional measurement capabilities.

Inline Peak Power

Sensor 350 MHz to 4 GHz Type N(f) 11410-00621

MA24106A High Accuracy RF

Power Sensor 50 MHz to 6 GHz Type N(m) 11410-00424

MA24108A Microwave USB Power

Sensor 10 MHz to 8 GHz Type N(m) 11410-00504

MA24118A Microwave USB Power

Sensor 10 MHz to 18 GHz Type N(m) 11410-00504

MA24126A Microwave USB Power

Sensor 10 MHz to 26 GHz Type K(m) 11410-00504

MA24208A Universal USB Power

Sensor 10 MHz to 8 GHz Type N(m) 11410-00841

MA24218A Universal USB Power

Sensor 10 MHz to 18 GHz Type N(m) 11410-00841

MA24330A Microwave CW USB

Power Sensor 10 MHz to 33 GHz Type K(m) 11410-00906

MA24340A Microwave CW USB

Power Sensor 10 MHz to 40 GHz Type K(m) 11410-00906

MA24350A Microwave CW USB

Power Sensor 10 MHz to 50 GHz Type V(m) 11410-00906

2-2 High Accuracy Power Meter GUI Overview High Accuracy Power Meter (Option 19)

2-2 PN: 10580-00492 Rev. C High Accuracy Power Meter MG

2-2 High Accuracy Power Meter GUI Overview

This section illustrates the main graphical displays and SETUP menu presented for the high accuracy power

meter. For a basic power measurement example, refer to Section 2-3 “General Measurement Setup”

on page 2-4. For a general overview of the instrument and its user interface, refer to “Instrument Overview”

chapter of user guide.

1. Status Panel: This menu provides quick access to common settings used for power meter measurements.

Refer to “Status Panel” on page 2-3.

2. Current Power Measurement: The number displayed here is the current power measurement (in dBm or

watts) or the current relative power in dB or percentage. The number here tracks the analog meter pointer.

3. Max Hold Marker: The marker here indicates the max hold value. The max hold value is also displayed in the

table below the meter.

4. Limits: The red/blue transitions on the scale indicate the upper and lower limit values. When the pointer is in the

blue region, the measurement is passing; when the pointer is in the red regions, the measurement is failing.

5. Sensor Model: The connected sensor model number and status is displayed here.

6. SETUP Menu: Provides access to the main measurement setup parameters.

7. Measurement Table: The data here shows the current and max hold power measurements in both dBm and

watts, or relative power in dB and percent (%).

8. Limit Pass/Fail: The measurement table boarder is shown in red for failing measurements or green for passing

measurements.

Figure 2-1. High Accuracy Power Meter Display

4 5

2 3

High Accuracy Power Meter (Option 19) 2-2 High Accuracy Power Meter GUI Overview

High Accuracy Power Meter MG PN: 10580-00492 Rev. C 2-3

Status Panel

The status panel and features illustrated in this section are unique to the HIPM and to the particular

measurement and view that is selected. Press the Chevron icon to collapse the status panel and view the

corresponding minimized status panel.

CAL FREQUENCY: Sets the measurement frequency. The frequency value is sent

to the power sensor to apply the appropriate calibration factor.

EXTERNAL GAIN: Press this submenu key to toggle relative power On or Off.

This measurement shows the relative level of the desired base

power level input to your instrument. When ON, the message

EXTERNAL LOSS: Press this submenu key to toggle relative power On or Off.

This measurement shows the relative level of the desired base

power level input to your instrument. When ON, the message

REL POWER: Toggles relative power On or Off. This measurement shows the

relative level of the desired base power level input to your instrument. For example,

if you are measuring a 10 dBm signal, and REL POWER is enabled, then a drop to

7 dBm will show as –3 dB and 50 %.

MAX HOLD: Max Hold retains the highest power level measurement.

AVERAGES: Sets the number of measurements to be averaged.

Figure 2-2. High Accuracy Power Meter Status Panel and minimized status panel

1. Minimized Status Panel: This menu provides quick access to common settings used for power meter

measurements.

Figure 2-3. High Accuracy Power Meter Display with minimized status panel

2-3 General Measurement Setup High Accuracy Power Meter (Option 19)

2-4 PN: 10580-00492 Rev. C High Accuracy Power Meter MG

2-3 General Measurement Setup

Field Master Series instruments display the power values in both dBm and Watts, and offers the following

measurement features:

•Relative Power displays power changes with respect to a desired reference value in both dB

and % (percent).

•Limit values can be turned on as needed to indicate if a measurement is within or outside specified

limits.

•Averages provides a settable number of a running average count.

•Max Hold retains the highest power level measurement.

•External Gain and Loss setting allows power level compensation for passive losses (such as cable loss or

attenuators) or active gains (such as RF power amplifiers).

•Zeroing the sensor improves accuracy by removing measured system noise. Refer to Table 2-2 for the

power range in which accuracy is improved. Calibration factors can be used to correct both efficiency and

mismatch loss.

Caution

Ensure the power level that you are measuring does not exceed the input rating of the power sensor

being used or damage may result. Additional attenuators can be used to ensure that the power does

not exceed the specified measurement range.

Table 2-2. Power Range for Improving Accuracy via Zeroing to Remove Noise

Sensor Power Range

MA24104A +3 dBm to +13 dBm

MA24106A, MA24108A, MA24118A, MA24126A –30 dBm to –40 dBm

MA24208A, MA24218A –45 dBm to –60 dBm

MA24330A, MA24340A, MA24350A –50 dBm to –70 dBm

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Instrumento de medición de Anritsu

Anritsu

Anritsu Field Master Pro MS2090A Manual de usuario

Anritsu

Anritsu Lightning 37 E Series Manual de usuario

Anritsu

Anritsu Spectrum Master MS2721B Manual del propietario

Anritsu

Anritsu MP1632C Manual de usuario

Anritsu

Anritsu PIM Master MW8208A Manual de usuario

Anritsu

Anritsu MS2690A Manual de usuario

Anritsu

Anritsu MT8820C Instrucciones de instalación y funcionamiento

Anritsu

Anritsu VectorStar ME7848E Series Manual de usuario

Anritsu

Anritsu 54100A Series Instrucciones de instalación y funcionamiento

Anritsu

Anritsu MP1900A Series Manual de usuario

Anritsu

Anritsu Spectrum Master MS2720T Manual del propietario

Anritsu

Anritsu MS2681A Manual de usuario

Anritsu

Anritsu MS2711A Manual de usuario

Anritsu

Anritsu VNA master Manual de usuario

Anritsu

Anritsu Field Master MS2080A Manual de usuario

Anritsu

Anritsu IQ Fiber Master MT2780A Manual de usuario

Anritsu

Anritsu MS2830A Manual de usuario

Anritsu

Anritsu MS9740A Manual de usuario

Anritsu

Anritsu Spectrum Master MS2720T Manual de usuario

Anritsu

Anritsu Site Master S331D Manual del propietario

Anritsu

Anritsu MS2830A Manual de usuario

Anritsu

Anritsu ShockLine MS46522A Manual de usuario

Anritsu

Anritsu VectorStar ME7828A Series Manual de usuario

Anritsu

Anritsu MP1570A Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
