INSTRUCTION MANUAL

OIL-FREE SCROLL COMPRESSOR

SLE-2/2H

SLE-3/3H

SLE-5/5H

Thank you for purchasing our oil-free scroll air compressor.

●Before operation, be sure to read this instruction manual thoroughly for safe

and efficient use for a long operating lifetime.

●After reading it, store in a convenient place for immediate and future

reading.

Before use, be sure to fill in the blank spaces below for future repair and after service.

MODEL

SERIAL No.

Purchased from

Date of purchase

Date of use

Important information and Safety precautions

▪Important information

Read all important information and safety precautions before use. The operator shall be fully knowledgeable of

the requirements stated within this instruction manual, including important warnings, cautions and operation.

Read manual before performing any maintenance.

•Indications of warnings and cautions

WARNING

May cause injury or death.

CAUTION

May result in injury or property damage.

•Examples of warnings and cautions

May cause electric shock.

Do not touch.

Must be grounded.

＊Supplier is not responsible for any injuries or damages caused by disregard of warnings, operating instruction

specifications or maintenance schedules.

l@;

Indicates important notices you must observe.

They are helpful to achieve top performance and functions of the equipment.

Keep this booklet in an appropriate place for immediate reference.

Important

Important information and Safety precautions

▪Safety precautions

WARNING

Install in a safe area.

To prevent a fire or explosion, install in an area free of flammable gases or organic solvents.

Never install outdoors.

To prevent fire or electric shock, never install outdoors.

Turn off the main electric source.

To prevent electric shock or serious injury, always turn off the main electric source before

inspecting or wiring the unit.

Ask a qualified electrician.

Only a qualified electrician should perform maintenance on the unit.

Be sure to ground.

Unit must be grounded to prevent electric shock.

Never use to compress anything other than air.

Unit must only be used to compress air.

Do not use with respiratory equipment, which

could cause serious injury or death.

Important information and Safety precautions

WARNING

Not for use as life support.

Serious bodily injury and/or death may occur. Unit must only be used to compress air.

Do not touch.

Keep hands and fingers away from fans, pulleys and belts while the power is on.

Serious injury, including entanglement of fingers or hands can occur.

Release pressure.

Release pressure from unit before conducting maintenance and/or inspection.

Failure to do so may cause serious injury.

Conduct maintenance and inspection.

Conduct maintenance and inspection according to this manual to prevent unit failure.

Important information and Safety precautions

CAUTION

Use at ambient temperatures of 36°F to 104°F.

Drain will freeze at less than 36°F and will cause unit failure.

Using over 104°F will cause a shorter lifespan or unit damage.

Use in an area free of dirt and dust.

Failure to do so may result in equipment failure.

Use in an area free of corrosive gas.

Failure to do so may result in equipment failure.

Only qualified personnel should perform repairs

to prevent electric shock or fire.

Keep Away.

Keep away from the compressor while it is operating, and allow it to cool before servicing.

Failure to do so may result in serious burns and or bodily harm.

Never alter the compressor

Fire and or electric shock may occur if unit is altered and warranty will be void.

Use genuine parts

Be sure to use only genuine parts during maintenance.

Failure to do so may result in equipment failure.

Contents

Important information and Safety precautions

■Important information ----------------------------------

■Safety precautions ---------------------------------------

■Contents ----------------------------------------------------

Before use

■Inspect the product -------------------------------------

Installation

■Precaution about installation ----------------------------

■Installation space ----------------------------------------

■Ventilation -------------------------------------------------

■Installation for base cover -----------------------------

■Piping -------------------------------------------------------

■Electrical wiring -------------------------------------------

Test operation

■Operation --------------------------------------------------

Problems and remedies

■Compressor -----------------------------------------------------

Maintenance and inspection

■Compressor maintenance standards --------------------

■How to carry out maintenance ----------------------------

Specifications

■Compressor specifications ----------------------------------

Appendix

■Outer dimensions ---------------------------------------------

■Circuit diagram ------------------------------------------------

Warranty

■Warranty and remain ---------------------------------------

Before use

▪Inspect the product

•Inspect the product to be sure you have the model you ordered.

•Check that there is no deformity or damage which occurred during transportation. Any shipping damage must be

immediately filed with the freight carrier.

•Check that the following accessories are included.

oCompressor instruction manual

oPump instruction manual

oAuto drainer instruction manual

oBase cover x 2

oRubber mat x 4

oBall valve

SL; Scroll 2; 2HP 208; 208V

3; 3HP 230; 230V

E; Enclosure 5; 5HP 460; 460V

S; Single phase

T; Three phase

N/A;

115psi (Maximum pressure)

145psi (Maximum pressure)

230

Installation

▪Precautions about installation

WARNING!

Do not use in an area which is exposed to rain, steam or high humidity.

High humidity can cause electric shock or fire.

Do not install in an area with corrosive gas (ammonia, acid, salinity, ozone gas and sulfur dioxide)

preventing a shorter lifespan of the unit.

WARNING!

To prevent a fire or explosion, install in an area free of flammable gases or organic solvents.

Ambient temperature

Use at ambient temperatures of 36°F to 104°F.

Using at less than 36°F will cause unit failure or freezing.

CAUTION!

Install this product on a level floor to prevent vibration and noise, causing damage to the unit.

CAUTION!

Install in an area which is free of dust. Dust can cause increased temperature and wear,

resulting in a shorter lifespan and/or unit failure.

Installation

▪Installation space

Secure the space around the compressor for safe inspection and maintenance.

Installation space

(inch)

Above

Front side

Other Sides

▪Ventilation

When using in an enclosed closed room, install a fan for ventilation.

Model

British Thermal Unit

(BTU)

SLE-2

SLE-2H

5120

SLE-3

SLE-3H

7680

SLE-5

SLE-5H

12800

▪Installation for base cover

Please install the base covers by using the tapping screws at the base as shown below.

Installation

▪

▪Piping

(1) Take pressure loss into consideration and decide the piping diameter of the exhaust piping.

(2) Connect the outlet of the compressor and piping by using a rubber hose and flexible tube.

Direct connection to a steel pipe can transfer vibration of the compressor to the pipe causing issues for the

print board of the compressor. Only use a rubber hose for the oil-free compressor.

(3) When there is a riser or concave section in the piping, be sure to install a drain valve at the low end.

Install a drain valve at the low end of the main piping as well.
