FG# FGP46-1616-567

Optima, 16x16 RGBHV 500 MHz

with BNC, Stereo with 5T and

DVC, includes control panel

FG# FGP46-1212-567

Optima,12x12 RGBHV 500 MHz

with BNC, Stereo with 5T and

DVC, includes control panel

FG# FGP37-1208-567

Precis, 12x08 RGBHV 500 MHz

with BNC, Stereo with 5T and

DVC, includes control panel

FG# FGP37-0804-567

Precis, 08x04 RGBHV 500 MHz

with BNC, Stereo with 5T and

DVC, includes control panel

FG# FGP46-1616-560

Optima, 16x16 RGBHV 500MHz

with BNC, includes control panel

FG# FGP46-1212-560

Optima, 12x12 RGBHV 500 MHz

with BNC, includes control panel

FG# FGP37-1208-560

Precis, 12x08 RGBHV 500 MHz

with BNC, includes control panel

FG# FGP37-0804-560

Precis, 08x04 RGBHV 500 MHz

with BNC, includes control panel

FG# FGP37-0808-567

Precis, 08x08 RGBHV 500 MHz

with BNC, Stereo with 5T and

DVC, includes control panel

FG# FGP37-1204-567

Precis, 12x04 RGBHV 500 MHz

with BNC, Stereo with 5T and

DVC, includes control panel

FG# FGP37-0808-560

Precis, 08x08 RGBHV 500 MHz

with BNC, includes control panel

FG# FGP37-1204-560

Precis, 12x04 RGBHV 500 MHz

with BNC, includes control panel

FG# FGP46-1608-560

Optima, 16x08 RGBHV 500 MHz

with BNC, includes control panel

FG# FGP46-1608-567

Optima, 16x08 RGBHV 500 MHz

with BNC, Stereo with 5T and

DVC, includes control panel

We are featuring 16 of the most popular RGBHV

over BNC models from our Precis and Optima

lines. The quality you’ve come to expect from

AMX AutoPatch, now at a more competitive price.

Stock up on matrix switchers today with the new

AMX SLAM DUNK promotion — and at 500 MHz

these high-performance players are a sure thing for

any small to mid range installation.

FG# FGP46-0816-567

Optima, 08x16 RGBHV 500 MHz

with BNC, Stereo with 5T and

DVC, includes control panel

FG# FGP46-0816-560

Optima, 08x16 RGBHV 500 MHz

with BNC, includes control panel

• 500 MHz (+4/-3dB)

• PureSync™

• Superior crosstalk specications

• Audio output volume control

• Audio input adjustments

• Complete audio breakaway capabilities

• RS-232 control port; simple BCS serial control protocol

• Groupings and presets

• Simple Touch X/Y Control Panel featuring backlit buttons

• Optional TCP/IP control available

• Backed by AMX Warranty

• 24-hour technical support

CROSS REFERENCE TABLE

AMX Order# Extron Order# Crestron Order#

FGP37-0804-560 60-337-12

FGP37-0804-567 60-337-11 CEN-RGBHV8X4

FGP37-0808-560 60-336-12

FGP37-0808-567 60-336-11 CEN-RGBHV8X8

FGP46-0816-560 60-395-12

FGP46-0816-567 60-395-11

FGP37-1204-560 60-335-12

FGP37-1204-567 60-335-11 CEN-RGBHV12X4

FGP37-1208-560 60-334-12

FGP37-1208-567 60-334-11 CEN-RGBHV12X8

FGP46-1212-560 60-852-12

FGP46-1212-567 60-852-11

FGP46-1608-560 60-333-12

FGP46-1608-567 60-333-11

FGP46-1616-560 60-332-12

FGP46-1616-567 60-332-11 CEN-RGBHV16X16

FEATURES

3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • 469.624.8000 • +1.469.624.7400 • 469.624.7153 fax • www.amx.com

© 2008 AMX. All rights reserved. The AMX logo and AutoPatch are registered trademarks of AMX. All other trademarks and registered trademarks are property of their respective owners. AMX reserves the right to alter specifications and pricing without notice at any time.
