Amprobe AMP-330 Manual de usuario

AMP-330

AMP-330-EUR

1000A ACDC TRMS

CAT IV Clamp

Multimeter

OFF

ZERO

NCV(EF)

HOLD

MAX 1000A

1000V CAT III

600V CAT IV

REC SELECT Hz

CRESTPEAK-RMS

CAT III

1000V

CAT IV

600V

COM

TRMS

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

AMP-330 / AMP-330-EUR

1000A ACDC TRMS CAT IV Clamp Multimeter

User Manual

7/2014, 6003318 A

English

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

AMP-330 1000A ACDC TRMS CAT IV Clamp Multimeter

CONTENTS

SYMBOL......................................................................................................... 3

SAFETY INFORMATION ................................................................................. 4

UNPACKING AND INSPECTION ..................................................................... 5

MEASUREMENTS........................................................................................... 6

Measuring AC and DC Voltage ................................................................ 7

Voltage detection (NCV) .......................................................................... 8

Measuring AC and DC Current ................................................................ 9

Precise Low-Current Measurement ......................................................... 10

Microamps μA Measurement .................................................................. 11

Measuring Resistance, Continuity and Diode ........................................ 12

Measuring Capacitance and Temperature ............................................. 13

Measuring & 3-Phase Rotation .................................................. 14

Auto Power Off ........................................................................................ 15

SPECIFICATIONS............................................................................................. 16

ELECTRICAL SPECIFICATIONS ....................................................................... 17

MAINTENANCE AND REPAIR ........................................................................ 21

BATTERY REPLACEMENT............................................................................... 21

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

1Jaw

2Tactile Barrier

3Jaw Release

4Display

5Backlight/Flashlight Button

6REC/PEAK-RMS Button

7SELECT Button

8Antenna for Non-Contact

Voltage Detection

AMP-330 1000A ACDC TRMS CAT IV Clamp Multimeter

9Precise Low Current

Measuring Location

10 Indicator of the Jaw Center

for Current Measurement

11 Rotary Switch

12 Data Hold/ZERO button

13 Input Terminals

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

14 Low battery indicator

Data hold

15 Alternative Current (AC)

Direct Current (DC)

AC + DC

Varable Frequency Dive

16 Negative reading

17 Relative zero is active

18 Precise low current

measurement mode

19 kΩ:KiloOhms

Hz: Hertz

20 μF: Microfarads

μA: Microamps

A: Amps

V: Volts

SYMBOLS

Application and removal from hazardous live conductors

permitted

Caution! Risk of electric shock.

WCaution! Refer to the explanation in this manual.

TThe equipment is protected by double insulation or reinforced

insulation.

JEarth (Ground).

CAT IV

Overvoltage Category IV is for installed at or near the origin of

electrical supply to a building, between the building entrance

and the main distribution board. Such equipment may include

electricity tariff meters and primary over current protection

devices.

21 Motor rotation indicator

Phase rotation indicator

22 PEAK-RMS mode

(in-rush current) is active

23 Continuity buzzer is active

24 Diode test mode is active

25 Recording mode is active

Crest mode is active

MAX: MAX mode is active

MIN: MIN mode is active

AVG: AVG mode is active

26 Auto-ranging

18 19

25 24 23 22

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

CAT III

Overvoltage Category lll is for equipment intended to form

part of a building wiring installation. Such equipment includes

socket outlets, fuse panels, and some mains installation control

equipment.

BAlternating Current (AC).

FDirect Current (DC).

NBattery.

Underwriters Laboratories. [Note: Canadian and US.]

PComplies with European Directives.

Conforms to relevant Australian standards.

=Do not dispose this product as unsorted municipal waste.

Contact aqualified recycler.

SAFETY INFORMATION

The Meter complies with:

• UL/IEC/EN 61010-1, CAN/CSA C22.2 No. 61010-1, Pollution Degree 2,

Measurement category IV 600 V and Measurement category III 1000 V

• IEC/EN 61010-2-033

• IEC/EN 61010-2-032

• IEC/EN 61010-031 (test leads)

• EMC IEC/EN 61326-1

Measurement Category IV (CAT IV) is for installed at or near the origin of

electrical supply to a building, between the building entrance and the main

distribution board. Such equipment may include electricity tariff meters and

primary over current protection devices.

Measurement Category III (CAT III) is for equipment intended to form part

of a building wiring installation. Such equipment includes socket outlets,

fuse panels, and some mains installation control equipment.

CENELEC Directives

The instruments conform to CENELEC Low-voltage directive 2006/95/EC and

Electromagnetic compatibility directive 2004/108/EC.

W

Warning: Read Before Using

To avoid possible electric shock or personal injury:

• Use the Meter only as specified in this manual or the protection

provided by the Meter might be impaired.

• Avoid working alone so assistance can be rendered.

• Never measure AC current while the test leads are inserted into the

input jacks.

• Do not use the Meter in wet or dirty environments.

• Do not use the Meter if it appears damaged. Inspect the Meter before

use. Look for cracks or missing plastic. Pay particular attention to the

insulation around the connectors.

• Inspect the test leads before use. Do not use them if insulation is

damaged or metal is exposed.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

• Check the test leads for continuity. Replace damaged test leads before

using the Meter.

• Have the Meter serviced only by qualified service personnel.

• Use extreme caution when working around bare conductors or bus

bars. Contact with the conductor could result in electric shock.

• Do not hold the Meter anywhere beyond the tactile barrier.

• When measuring current, center the conductor in the clamp.

• Do not apply more than the rated voltage, as marked on the Meter,

between the terminals or between any terminal and earth ground.

• Remove test leads from the Meter before opening the Meter case or

battery cover.

• Never operate the Meter with the battery cover removed or the case

open.

• Never remove the battery cover or open the case of the Meter without

first removing the test leads or the jaws from a live conductor.

• Use caution when working with voltages above 30 V ac rms, 42 V ac

peak, or 60 V dc. These voltages pose a shock hazard.

• Do not attempt to measure any voltage that might exceed the

maximum range of the Meter.

• Use the proper terminals, function, and range for your measurements.

• Do not operate the Meter around explosive gas, vapor, or dust.

• When using probes, keep fingers behind the finger guards.

• When making electrical connections, connect the common test lead

before connecting the live test lead; when disconnecting, disconnect

the live test lead before disconnecting the common test lead.

• Disconnect circuit power and discharge all high-voltage capacitors

before testing resistance, continuity, or diodes.

• Use only 1.5V AA batteries, properly installed in the Meter case, to

power the Meter.

• To avoid false readings that can lead to electrical shock and injury,

replace the battery as soon as the low battery indicator (N) appears.

Check Meter operation on a known source before and after use.

• When servicing, use only specified replacement parts.

• Adhere to local and national safety codes. Individual protective

equipment must be used to prevent shock and arc blast injury where

hazardous live conductors are exposed.

• Do not use the Meter if the wear indicator in the jaw opening is not

visible.

• Only use the test lead provided with the Meter or UL Listed Probe

Assembly rated CAT III 1000 V or better.

UNPACKING AND INSPECTION

Your shipping carton should include:

1 Clamp meter

1 Test leads (Black, Red and Yellow)

1 Alligator clip set

1 Banana plug K-type thermocouple

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

1 1.5 V AA batteries (installed)

1 Users manual

1 Carrying case

If any of these items are damaged or missing, return the complete package

to the place of purchase for an exchange.

MEASUREMENTS

W

Warning

To avoid possible electric shock or personal injury:

• When measuring current, center the conductor in the clamp.

• When making current measurements, disconnect the test leads from

the Meter.

• Keep fingers behind Tactile Barrier.

• Use the proper function and range for measurements.

• Disconnect circuit power and discharge all high-voltage capacitors

before testing resistance and diode.

• When using probes, keep fingers behind the finger guards.

• Connecting test leads:

- Connect the common (COM) test lead to the circuit before connecting

the live lead;

- After measurement, remove live lead before removing the common

(COM) test lead from the circuit.

Button Description

SELECT Press SELECT button to select the alternative

measurement function on the rotary switch.

Press button to turn ON or to turn OFF LCD

backlight and flashlight. LCD backlight and flashlight

automatically turns off after approximately 32 seconds

HOLD /

ZERO

Press HOLD to freeze the display reading ( is

displayed) and releases the reading when pressed a

second time.

W Warning

To avoid possible electric shock or personal injury,

when Display HOLD is activated, be aware that the

display will not change when you apply a different

voltage.

Press ZERO (HOLD) > one second to clear last

reading from the display ( is displayed) and establish

a baseline for applicable selected functions.

DC-Zero mode for DC and AC+DC currents. Press

ZERO (HOLD) > one second to activate DC-Zero (display

shows “dc_0” for one second). When nulled value is

larger than +/- 5 DC A, an acoustic warning (3 short

beeps) will occur.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

REC /

PEAK-RMS

Press REC button to activate maximum, minimum and

average reading memory mode ( MAX MIN AVG

is displayed). The meter beeps when MAX and MIN

reading is updated during measurement. Press REC

button again to read the MAX, MIN and AVG reading

in sequence. Press REC button > one second to exit

MAX/MIN/AVG reading memory mode.

Press REC / PEAK-RMS button > one second to enter

PEAK-RMS mode ( is displayed) to capture

inrush current or voltage RMS values (80 ms). Press a

second time > one second to exit.

Note: Auto Power Off is automatically disabled under

MAX/MIN/AVG and PEAK-RMS modes.

Hz / CREST Press Hz button to activate frequency measurement

mode. Press a second time to exit.

Press REC button > one second to activate CREST mode

(5 ms) to capture current or voltage peak values (

MAX is displayed). Press again to toggle between

MAX and MIN. The meter beeps when MAX or

MIN reading is updated during measurement. Press

CREST button > one second to exit CREST mode.

Note: Auto Power Off is automatically disabled under

CREST modes.

Measuring AC and DC Voltage

To measure ac or dc voltage:

1. Turn the rotary function switch to or

2. Press SELECT button to choose measurement function (AC V, DC V,

DC+AC V, Hz or EF - Non contact voltage detection). The display reflects

the chosen function mode.

3. Connect the black test lead to the COM terminal and the red test lead

to the V terminal. Before connecting the probes to the measurement

points, add any clips to the probes that are necessary.

4. Measure the voltage by touching the probes to the desired test points

of the circuit.

5. View the reading on the display.

6. When measuring AC voltage, press Hz button to view the frequency

reading on the display.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Note:

• AC V (and hence DC+AC V and Hz) function is equipped with digital

low-pass filter, and is capable of dealing with VFD (Variable Frequency

Drives) signals. It also improves AC V reading stability in noisy electrical

environments.

Voltage Detection (NCV)

Non-Contact Voltage Detection:

1. Turn the rotary switch to NCV (EF). Press SELECT button to toggle

NCV (EF) mode (“EF” is displayed).

2. The voltage detection antenna is located along the top-right

end of the stationary clamp jaw for detecting electric field surrounds

energized conductors

3. Detected electric field signal strength is indicated by a series of bar-

graph segments on the display and beeper. The stronger the electric

field detected, the more bar-graph segments are displayed and more

intense beep sounds.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Multímetro de Amprobe

Amprobe

Amprobe AM-220 Manual de usuario

Amprobe

Amprobe ac68C Manual de usuario

Amprobe

Amprobe AM535 Manual de usuario

Amprobe

Amprobe 33XR-A Manual de usuario

Amprobe

Amprobe KWC-2000 Manual de usuario

Amprobe

Amprobe ACD-10 TRMS-PLUS Manual de usuario

Amprobe

Amprobe 5XP-A Manual de usuario

Amprobe

Amprobe AM-120 TRMS Manual de usuario

Amprobe

Amprobe PM51A Manual de usuario

Amprobe

Amprobe AC71B Manual de usuario

Amprobe

Amprobe AM-520-EUR Manual de usuario

Amprobe

Amprobe 30XR-A Manual de usuario

Amprobe

Amprobe AM-500 Manual de usuario

Amprobe

Amprobe PM51A Manual de usuario

Amprobe

Amprobe AM-530 Manual de usuario

Amprobe

Amprobe AM-540 Manual de usuario

Amprobe

Amprobe 38XR-A Manual de usuario

Amprobe

Amprobe ACD-15 Pro Manual de usuario

Amprobe

Amprobe AM-250 Manual de usuario

Amprobe

Amprobe AM-560 Manual de usuario

Amprobe

Amprobe 30XR-A Manual de usuario

Amprobe

Amprobe DM73C Manual de usuario

Amprobe

Amprobe 5XP-A Manual de usuario

Amprobe

Amprobe AM90 Manual de usuario

Manuales populares de Multímetro de otras marcas

Agilent Technologies

Agilent Technologies 34420A Manual de usuario

Fluke

Fluke 83 Manual de usuario

Hameg

Hameg HM 8012 Manual de usuario

Mastech

Mastech MY70 Manual de usuario

Steren

Steren MUL-300 Manual de usuario

Somogyi Elektronic

Somogyi Elektronic home SMA 92 Manual de usuario

Gossen MetraWatt

Gossen MetraWatt METRAmax 6 Manual de usuario

PeakTech

PeakTech 4000 Manual de uso y cuidado

YOKOGAWA

YOKOGAWA 90050B Manual de usuario

Gossen MetraWatt

Gossen MetraWatt METRALINE DMM16 Manual de usuario

Fluke

Fluke 8846A Manual de operación y mantenimiento

Tempo Communications

Tempo Communications MM200 Manual de usuario

Elenco Electronics

Elenco Electronics CM-1555 Manual de usuario

Mastech

Mastech MS8238C Manual de usuario

SDAR

SDAR 830A, 830B, 830D, 830C Manual de usuario

RS PRO

RS PRO RS-9519BT Manual de usuario

BGS technic

BGS technic 8890 Manual de usuario

Morris

Morris 57074 Manual de usuario
