Amprobe THWD-10 Manual de usuario
Users Manual
• Mode d’emploi
• Bedienungshandbuch
• Manual d’Uso
• Manual de uso
THWD-10 / THWD-10W
RH Meter
RH Meter with Wireless
THWD-10
THWD-10W
RH Meter
RH Meter with Wireless
Users Manual
June 2010, Rev.1
©2010 Amprobe Test Tools.
All rights reserved. Printed in Taiwan
English
Limited Warranty and Limitation of Liability
Your Amprobe product will be free from defects in material and
workmanship for 1 year from the date of purchase. This warranty
does not cover fuses, disposable batteries or damage from accident,
neglect, misuse, alteration, contamination, or abnormal conditions
of operation or handling. Resellers are not authorized to extend
any other warranty on Amprobe’s behalf. To obtain service during
the warranty period, return the product with proof of purchase
to an authorized Amprobe Test Tools Service Center or to an
Amprobe dealer or distributor. See Repair Section for details. THIS
WARRANTY IS YOUR ONLY REMEDY. ALL OTHER WARRANTIES -
WHETHER EXPRESS, IMPLIED OR STAUTORY - INCLUDING IMPLIED
WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE OR
MERCHANTABILITY, ARE HEREBY DISCLAIMED. MANUFACTURER
SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL
OR CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY
CAUSE OR THEORY. Since some states or countries do not allow the
exclusion or limitation of an implied warranty or of incidental or
consequential damages, this limitation of liability may not apply
to you.
Repair
All test tools returned for warranty or non-warranty repair or
for calibration should be accompanied by the following: your
name, company’s name, address, telephone number, and proof of
purchase. Additionally, please include a brief description of the
problem or the service requested and include the test leads with
the meter. Non-warranty repair or replacement charges should be
remitted in the form of a check, a money order, credit card with
expiration date, or a purchase order made payable to Amprobe®
Test Tools.
In-Warranty Repairs and Replacement – All Countries
Please read the warranty statement and check your battery before
requesting repair. During the warranty period any defective test
tool can be returned to your Amprobe® Test Tools distributor for
an exchange for the same or like product. Please check the “Where
to Buy” section on www.amprobe.com for a list of distributors near
you. Additionally, in the United States and Canada In-Warranty
repair and replacement units can also be sent to a Amprobe® Test
Tools Service Center (see address below).
Non-Warranty Repairs and Replacement – US and Canada
Non-warranty repairs in the United States and Canada should be
sent to a Amprobe® Test Tools Service Center. Call Amprobe® Test
Tools or inquire at your point of purchase for current repair and
replacement rates.
In USA In Canada
Amprobe Test Tools Amprobe Test Tools
Everett, WA 98203 Mississauga, ON L4Z 1X9
Tel: 877-AMPROBE (267-7623) Tel: 905-890-7600
Non-Warranty Repairs and Replacement – Europe
European non-warranty units can be replaced by your Amprobe®
Test Tools distributor for a nominalv charge. Please check the
“Where to Buy” section on www.amprobe.com for a list of
distributors near you.
European Correspondence Address*
Amprobe® Test Tools Europe
In den Engematten 14
79286 Glottertal, Germany
Tel.: +49 (0) 7684 8009 - 0
*(Correspondence only – no repair or replacement available from
this address. European customers please contact your distributor.)
THWD-10/THWD-10W RH Meter
THWD-10
RH Meter
13
12
11
10
4
1
6
3
2
5
7
8
9
THWD-10W
1) “ ” Power
2) °C /°F
3) “ ” backlight
4) “REL” Relative
5) “MAX/MIN” Record
6) “HOLD” Data Hold
7) “WB/DP” WB/DP/Ambient
temperature
8) “K/NTC/K-DP”
9) “SAVE” data save
10) “READ” data recall
11) Wireless(THWD-10W)
12) Display
13) Input
1) Humidity display
2) Temperature display
3) K type temperature
measurement mode
4) NTC temperature
measurement mode
5) K type temperature
minutes Dew point
temperature mode
6) Automatic power off
enabled
Screen Display
7) Low battery
8) Relative enabled
9) HOLD enabled
10) Maximum,Minimum,
Maximum-Minimum,
or average reading
displayed
11) Wet bulb or dew point
temperature displayed
12) Wireless function
enabled (THWD-10W)
2
7
8
9
6 1
4 53
12
10
11
1
CONTENTS
SYMBOLS............................................................................ 2
UNPACKING AND INSPECTION .......................................... 4
INTRODUCTION .................................................................. 4
Features .......................................................................... 4
OPERATION INSTRUCTIONS............................................... 5
““ Power Switch.......................................................... 5
“°C/°F” Selecting the Temperature Scale ..................... 5
“” Button.................................................................... 5
“REL” Button.................................................................. 5
“MAX/MIN” Button ....................................................... 5
“HOLD” Button .............................................................. 6
“WB/DP” Button ............................................................ 6
“K/NTC/K-DP” Button.................................................... 6
“SAVE” Button ............................................................... 7
“READ”, “ ”, “ ” Button........................................... 7
Wireless Mode................................................................ 7
SPECIFICATION.................................................................... 8
MAINTENANCE................................................................... 11
2
SYMBOLS
Caution! Refer to the explanation in this Manual
Complies with European Directives
Tested Comply With FCC Standards
Do not dispose of this clamp meter as unsorted
municipal waste.
WARNING and PRECAUTIONS
• To avoid electrical shock, do not use this instrument
when working voltages at the measurement surface
over 24V AC or DC.
• To avoid damage or burns, do not make
temperature measurement in microwave ovens.
• Repeated sharp exing can break the thermocouple
leads. To prolong lead life, avoid sharp bends in the
leads, especially near the connector.
• Do not immerse the hygrometer sensor head into
liquids since this causes permanent damage to the
sensor.
Federal Communications Commission
This device THWD-10W complies with Part 15 of the
FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that may
cause undesired operation.
3
Note
This equipment THWD-10W has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection. This
equipment generates, uses and can radiated radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation if this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Shielded interface cables must be used in order to comply
with emission limits.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
Wireless Note
Wireless receiver must keep a distance at least 40cm from
the meter and meter to meter distance must be at least
30cm.
