Ameriwood HOME Systembuild 2041335COM Manual de usuario

2041335COM

MudroomCabinet

‐Unitcantipovercausingsevereinjuryordeath.

‐Anchorunittostudinwall(ifinstructedto).

‐DoNotallowchildrentoclimbonunit.

‐Putheavyitemsonlowershelvesordrawers.

B342041335COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

WARNING

ForthelatestinformationonSystemBuildproducts

followusatAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐866‐452‐4081(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.systembuild.com

AssemblyDifficultyMeter

Easy Tough

ContactUs!

HelpfulHints

2

systembuild.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐866‐452‐4081

Monday‐Friday

9am‐5pmCST

Visitsystembuild.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:1HOUR

3

systembuild.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You



Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.

PressCAMBOLTintohole.

PresspartstogethersoCAMBOLTinserts

intoedgehole.

Usingascrewdriver,turntheCAMLOCKclockwiseto

locktheCAMLOCKandCAMBOLTintotheirholes

andfasteningpartstogether.

PressCAMLOCKintohole.

Endhole

Arrowtopointtowardsend

holeinedgeofpart.

4

systembuild.com

BeforeYouStart

Quick

Tip

Assembly

Tube

You

PleaseNote:

Youmayneedtolightlytapthewooddowelsintotheholesduring

yourassemblyprocess.

5

systembuild.com

BoardIdentification

Notactualsize

Tube

You

LeftPanel

33509335010

RightPanel

313509335020

Top

33509335030

Bottom

33509335040

FixedShelf

33509335050

AdjustableShelf

33509335060

BackPanel

K350933500

DEF

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

6

systembuild.com

BoardIdentification

Notactualsize

Tube

You

7

systembuild.com

PartList

ActualSize

Tube

You

NotActualSize

(x10)

#A22710

cam bolt

(x10)

#A22700

cam lock

(x10)

#A21670

wood dowel

(x4)

#A23030

confirmat screw

(x2)

#A11080

7/16" screw

(x8)

#A12420

5/8" screw

(x4)

#A12930

1-1/8" screw

(x32)

#A21110

nail

(x4)

#A44140

foot

(x1)

#I20680

clothes rod

(x1)

#A84050

safety bracket

12346

(x4)

#A80250

shelf support

912

(x2)

9‐#A82010(white)

12‐#A82020(black)

rod bracket

8

systembuild.com

STEP1

Tube

You

(x4) (x4)

Proper orientation of CAM LOCK

Tip

Assembly

Quick

9

systembuild.com

STEP2

Tube

You

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x4)

10

systembuild.com

STEP3

Tube

You

212

(x4) (x1) (x1)
