Ameriwood HOME 9275335COM Manual de usuario

9275339COM(BayOak)

FireplaceTVStand

B349275000COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com AssemblyDifficultyMeter

Easy Tough

WARNING

Thispieceoffurniturecanoverturnandcauseserious

injuries&ordeath.

Anchorthefurnituretoastudinthewall(ifthisisrequired).

Donotallowchildrentoclimbonfurniture

Keepheavieritemsonlowershelves.

9275335COM (Nightfall Oak)

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



PresspartstogethersoCAMBOLTinserts

intoedgehole.

PressCAMBOLTintohole. PressCAMLOCKintohole.

Endhole

Usingascrewdriver,turntheCAMLOCKclockwiseto

locktheCAMLOCKandCAMBOLTintotheirholes

andfasteningpartstogether.

Arrowtopointtowardsend

holeinedgeofpart.

4

ameriwoodhome.com

BeforeYouStart

Quick

Assembly

Tip

PleaseNote:

Youmayneedtolightlytapthewooddowelsintotheholesduring

yourassemblyprocess.

5

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftPanel

39275335010

RightPanel

39275335020

LeftPartition

39275335030

RightPartition

39275335040

Divider(2)

39275335050

Top

39275335060

Bottom

39275335070

FixedShelf

39275335080

TVRail

39275335090

Kick

39275335100

Support

39275000110

CDE

FGH

IJK

parts for 9275335COM (Nightfall Oak)

6

ameriwoodhome.com

BoardIdentification

Notactualsize

Thispieceispaperboardconstruction.Itisnotmadefromwood,but

isrequiredfortheassemblyofyourunit.

LowerBackPanel(2)

K927533520

UpperBackPanel

K927533510

BACK

PANEL

BACK

PANEL

parts for 9275335COM (Nightfall Oak)

7

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftPanel

39275339010

RightPanel

39275339020

LeftPartition

39275339030

RightPartition

39275339040

Divider(2)

39275339050

Top

39275339060

Bottom

39275339070

FixedShelf

39275339080

TVRail

39275339090

Kick

39275339100

Support

39275000110

CDE

FGH

IJK

parts for 9275339COM (Bay Oak)

8

ameriwoodhome.com

BoardIdentification

Notactualsize

Thispieceispaperboardconstruction.Itisnotmadefromwood,but

isrequiredfortheassemblyofyourunit.

LowerBackPanel(2)

K927533920

UpperBackPanel

K927533910

BACK

PANEL

BACK

PANEL

parts for 9275339COM (Bay Oak)

9

ameriwoodhome.com

PartList

ActualSize

NotActualSize

6 8

(x16)

#A22700

cam lock

(x16)

#A22710

cam bolt

(x8)

#A21660

wood dowel

(x8)

#A23030

confirmat screw

(x60)

#A21110

nail

(x15)

#A12120

#8X7/16"pan

(x14)

#A22760

quickloc

(x4)

#A11080

#6X7/16"flat

(x8)

#A80250

shelfsupport

(x3)

#A54270

connectingplate

(x2)

#H13240

glassshelf

Notethatyourunitmaycontainextrahardware

10

ameriwoodhome.com

PartList

#B64396

TVwarninglabel

(x1)

#A95070

fireplaceinsert

w/lightkit

12a

12b

BACK

PANEL
