Ameriwood HOME 6762341COM Manual de usuario

6762341COM

Fireplace Console

B346762341COM0

THIS INSTRUCTION BOOKLET CONTAINS

IMPORTANT

SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

Follow Ameriwood Home

Tube

You

Date of Purchase ___ / ___ / ___

Lot Number:

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

Assembly Difficulty Meter

Easy Tough

Secure Your Furniture

Keep your home and family safe

with the wall anchor kit that is

included with the product.

Serious or fatal crushing injuries can

occur from tipping furniture.

WARNING: Manufacturer assumes no liability

for improper installation or excessive loads

placed on screws or bracket. This wall anchor

is not a substitute for proper adult supervision.

Helpful Hints

ameriwoodhome.com

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com to view the

limited warranty valid in the U.S. and Canada.

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a

(right) and

(left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

Tube

You

PEOPLE NEEDED FOR ASSEMBLY: 1-2

ameriwoodhome.com

Before You Start

Quick

Tip

Assembly

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Parts are labeled on the surface or edge of the part

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

Press parts together so CAM BOLT inserts

into edge hole.

Press CAM BOLT into hole. Press CAM LOCK into hole.

End hole

Using a screwdriver, turn the CAM LOCK clockwise to

lock the CAM LOCK and CAM BOLT into their holes

and fastening parts together.

Arrow to point towards end

hole in edge of part.

ameriwoodhome.com

Before You Start

Quick

Assembly

Tip

Please Note:

You may need to lightly tap the wood dowels into the holes during

your assembly process.

ameriwoodhome.com

Board Identification

Not actual size

Left Panel

36762341010

Right Panel

36762341020 Top Shelf

36762341030

Bottom

36762341040

Left Partition

36762341050 Right Partition

36762341060 TV Shelf

36762341070

Door (x2)

36762341080

Adjustable Shelf (x2)

36762341090

Left Upper

Support

36762341100

Right Upper

Support

36762341110

Center Upper

Support

36762341120 Left Support

36762341130 Right Support

36762341140

BCD

EFG

JKLMN

Support Rail

36762341150

Vertical Rail (x2)

36762341160

Upper Rail

36762341170

Lower

Back Panel (x2)

K676234100

These pieces are paperboard construction.

They are not made from wood, but are

required for the assembly of your unit.

ameriwoodhome.com

Board Identification

Not actual size

Upper Back Panel

K676234110

ameriwoodhome.com

Part List

Actual Size

Not Actual Size

(x14)

#A22700

cam lock

(x14)

#A22710

cam bolt

(x10)

#A22920

connector

(x10)

#A22910

connector bolt

(x14)

#A21670

wood dowel

(x14)

#A23030

confirmat screw

(x8)

#A80250

shelf support

(x56)

#A21110

nail

(x4)

#A17400

7/8" bolt

(x13)

#A12120

7/16" screw

(x3)

#A53510

angle bracket

(x4)

#A22760

quickloc

(x2)

#A51715

handle

(x1)

#A53655

bracket

(x4)

#A65640

euro hinge

(x1)

#A95010

fireplace insert

126

712

810

14 15 16

(x2)

#A89210

rubber pad

ameriwoodhome.com

STEP1

(x6)

Be sure connector (6) is

positioned as shown

before inserting into hole.

ameriwoodhome.com

STEP2

(x6)

ameriwoodhome.com

STEP3

finished edge

Turn clockwise

to lock in place.
