American Standard 3051.110.AXX Manual de usuario

30” x 51” Walk-In

Soaking Tub, Air Spa And Whirlpool

High Gloss

Walk-in Bath 30” x 51” Soaking Tub, Air Spa And Whirlpool

⁮3051.110.SXX Soaking Tub

•Acrylic with fiberglass reinforcement.

•Free standing metal support frame with five

adjustable leveling feet

•Easy access, powder coated aluminum door system

•Contoured, built-in seat.

•Built-in grab bar and textured bottom.

•Faucet / accessory deck areas.

•Color match cable driven drain assembly.

⁮3051.110.WXX Whirlpool system

•Electronic control with timer.

•1 HP variable flow pump system.

•12 adjustable massage jets with

•Automatic Tub Cleaning System - Ozone.

⁮3051.110.AXX Air Spa system

•Electronic control with timer.

•1 HP variable flow heater blower.

•Multiple seat and floor air injectors.

•Automatic purge cycle

⁮3051.110.CXX Combo system

•Combines Whirlpool And Air System

Nominal Dimensions

30” x 51” x 37 1/2”

Compliance Certifications

•ETL – INTERTEK SEMKO

•IAPMO - USPC

•ANSI Z 124.1.2 –for Plastic Bathtubs

•ASME A112.19.7 – Whirlpool Appliances

•ASME A112.19.15 –for Walk-in Bathtubs

•CSA B-45.5 – Canadian Plumbing Fixtures

To Be Specified – Required:

⁮Drain Configuration: Left (L) Or Right (R)

⁮Color: White (W) Or Linen (L)

⁮Faucet

⁮Quick Drain™: 9QUD

⁮Whirlpool Heater*: 9ILH (Whirlpool System Only)

⁮Chromatherapy: 9CTP

⁮Neck Rest: 9NR

⁮Tub Extender: 9EXT

(

ecif

color

)

SEE REVERSE FOR ROUGHING –IN

DIMENSIONS AND PRODUCT SPECIFICATIONS

* NOTE: The whirlpool heater is designed to

maintain water temperature during operation.

It will not heat cold water to desired bathing

temperature

30” x 51” Walk-In

Soaking Tub, Air Spa And Whirlpool

High Gloss

NOTES:

TUB IS SUPPORTED BY THE FRAME AND FIVE

INTEGRATED ADJUSTABLE FEET, NO ADDITIONAL

SUPPORT IS REQUIRED.

REFER TO INSTALLATION INSTRUCTIONS SUPPLIED

WITH TUB FOR ADDITIONAL INFORMATION.

FITTINGS NOT INCLUDED AND MUST BE ORDERED

SEPARATELY.

PROVIDE SUITABLE REINFORCEMENT TO SUB

FLOOR FOR ALL SUPPORTS.

IMPORTANT:

Dimensions of fixtures are nominal, may vary and are

subject to change or cancellation. No responsibility is

assumed for use of

superseded or voided leaflet

GENERAL SPECIFICATIONS FOR 3051.110.XXX

WALK-IN BATH TUB

INSTALLED SIZE___________51 x 30-1/2 x 37-1/2 In. (1295 x 762 x 950 mm)

WEIGHT ____________________________________________315 Lbs. (142 kg)

WEIGHT w/ WATER __________________________________815 Lbs. (370 kg)

OPERATING GAL. _____________________________________60 Gal. (225 L.)

FLOOR LOADING _______________________75 Lbs/Sq. Ft (365 Kgs/Sq. m.)

(PROJECTED AREA)

CUBE (FT³) _____________________________________________________33.5
