AMD LV-651 User's Manual de usuario

LV-651

Mini-ITX Motherboard

User’s Manual

Edition 1.0

2006/7/21

LV-651User’s Manual

The information in this document is subject to change without prior notice to make

improvements to the products.

This document contains proprietary information and protected by copyright. No part of this

document may be reproduced, copied, or translated in any form or any means without prior

written permission of the manufacturer.

All trademarks and/or registered trademarks contains in this document are property of their

respective owners. Disclaimer

The company shall not be liable for any incidental or consequential damages resulting from

the performance or use of this product.

The company does not issue a warranty of any kind, express or implied, including without

limitation implied warranties of merchantability or fitness for a particular purpose.

The company has the right to revise the manual or include changes in the specifications of

the product described within it at any time without notice and without obligation to notify any

person of such revision or changes.

Trademark

All trademarks are the property of their respective holders.

LV-651User’s Manual

Packing List

Please check the package before you starting setup the system

Hardware:

LV-651 series motherboard x 1

Cable Kit:

COM port Cable x1

Printed Matters:

User’s Manual x 1

Driver CD x 1

44-pin ATA33 IDE Cable x 1

I/O Shield Cable x 1

Floppy Cable x 1

44pin

40pin

44pin

Power Cable x 1

LV-651User’s Manual

Index

Chapter 1 <Introduction>………………………………………………………………7

1.1 <Product Overview>…………………………………………………………..7

1.2 <Product Specification>............................................................................8

1.3 <Mechanical Drawing>........................................................................…10

1.4 <Block Diagram>.....................................................................................11

Chapter 2＜Hardware Setup＞………………………………………………………12

2.1 <Connector Location>………………………………………………………..12

2.2 <Jumper Reference>………………………………………………………..13

2.3 <Connector Reference>…………………………………………………….14

2.3.1 <Internal Connector>……………………………………………….14

2.3.2 <External Connector>………………………………………………14

2.4 <CPU and Memory Setup>………………………………………………..15

2.4.1< CPU Setup> .............................................................................15

2.4.2 <Memory Setup>........................................................................15

2.5 <CMOS Setup>…….………………………………………………………..16

2.6 <Enhanced IDE & CF Interface>…………………………………………17

2.7 <Floppy Port>……………………………………………………………….18

2.8 <LAN Interface>…………………………………………………………….19

2.9 <Onboard Display Interface>………………………………………….…19

2.9.1 <Analog VGA Interface>………….……………………………..…19

2.9.2 < Digital Display >…………………………………………….20

2.10 <Onboard Audio Interface>…………………………………….……….26

2.11 <USB2.0 Interface>……………………………………………………….27

2.12 <GPIO Interface>………………………………………………………….29

2.13 <Serial Port Jumper Setting>…………………………………………..30

2.14 <Power and Fan Connector>…………………………………….……..32

2.14.1 <Power Input>………………………………………….………….32

LV-651User’s Manual

2.14.2 <Power Output>…………………………………….….32

2.14.3 <Fan Connector>………………………………………………….33

2.15 <Indicator and Switch>………………………………………………….34

Chapter 3 <BIOS Setup>…………………………………………………………….37

Appendix A <I/O Port Pin Assignment>………………………………………….38

A.1 <IDE Port>…………………………………………………………………..38

A.2 <Floppy Port>……………………………………………………………….40

A.3 <Serial Port>………………………………………………………………..40

A.4 < CRT Port >………………………………………………………………..41

A.5 <LAN Port>…………………………………………………………………41

A.6 <USB Port>…………………………………………………………………41

A.7 <PS/2 Keyboard & MousePort>………………………………………….42

A.8 <LPT Port>…………………………………………………………………42

Appendix B <Flash BIOS>…………………………………………………………43

B.1BIOS Auto Flash Tool……………………………………………………...43

B.2Flash Method………………………………………………………………..43

Appendix C <System Resources>…………………………………………….….45

C.1 I/O Port Address Map ………………………………………………….…45

C.2 Memory Address Map ……………………………………………………47

C.3 System IRQ Resources…………………………………………………..48

Appendix D <WatchDog Timer Setting>.…................................................…49

Contact Information…………………………...……………………………………50

LV-651User’s Manual

(The Page is Left For Blank)

LV-651 User’s Manual Introduction

Product Overview 7

Chapter 1 <Introduction>

1.1 <Product Overview>

LV-651 is the Mini-ITX motherboard with AMD Geode LX800 platform, with onboard VGA,

AC97 audio, Giga LAN interface. Based on the AMD Geode LX800 processor, the board

provides many advanced features for reduced power consumption, fanless design and high

cost/price rate of production.

Low Power Consumption

Based on the AMD Geode LX800@500MHz processor onboard, it only takes up to 3.8W at

maximum powering, and is completely suitable for fanless design. Without any cooling fan

onboard, it can avoid the heat problem when the cooler failed in accidence.

Onboard TFT/LVDS LCD interface

Based on the AMD Geode LX800@500Mhz of integrated graphics, the board provides

onboard graphics with up to 256 MB of frame buffer, 18-bit/24-bit LVDS and 24-bit TFT

interfaces.

Embedded Component

Due to the low profile design, the board provides CF card socket for flash disk with porting

embedded OS and up to DDR SDRAM.

Single Voltage Input

The board only requires DC 8~24V or standard 20-pin ATX power supply input; user’s can

easily connect the board with an adapter without the huge power supply.

LV-651 User’s Manual Introduction

Product Specification

1.2 <Product Specification>

General Specification

Form Factor Mini -ITX motherboard

CPU Embedded AMD Geode LX800 500MHz

Fanless with heat sink only

Memory One 184-pin DDR DIMM socket support up to 1GB DDR SDRAM

Optional on board 256M DDR SDRAM

Unbufferred, none-ECC memory supported only

Chipset AMD LX800 and CS5536

BIOS Phoenix-Award v6.00PG 4Mb PnP flash BIOS

Green Function Power saving mode includes doze, standby and suspend modes.

ACPI version 1.0 and APM version 1.2 compliant

Watchdog Timer System reset programmable watchdog timer with 1 ~ 255 sec./min.

of timeout value

Real Time Clock AMD CS5536 built-in RTC with lithium battery

Enhanced IDE Ultra DMA33 IDE interface supports up to 2 ATAPI devices

One 44-pin IDE port onboard

One Compact Flash Type II socket on solder side

Multi-I/O Port

Chipset Winbond W83627HG-AW

Serial Port One RS-232 and one RS232/422/485 serial ports

USB Port Four Hi-Speed USB 2.0 ports with 480Mbps of transfer rate

Parallel Port One D-sub 25pin LPT Port

Floppy Port One slim type Floppy port

IrDA Port One IrDA compliant Infrared interface supports SIR

K/B & Mouse External PS/2 keyboard and mouse ports on rear I/O panel

GPIO One 12-pin Digital I/O connector with 8-bit programmable I/O

interface

VGA Display Interface

Chipset AMD Geode LX800 built-in VGA controller with 2D Graphic

Frame Buffer Up to 256MB shared with system memory

Display Type Supports CRT, 24-bit TFT LCD & 18/24-bit single channel LVDS

LCD

Connector External DB15 female connector on rear I/O panel

Onboard 40-pin TFT connector

Onboard 40-pin LVDS connector

Ethernet Interface

Controller 1 x Realtek RTL8110S-32 Gigabit Ethernet controller

Type Triple speed 10/100/1000Base-T

Auto-switching Fast Ethernet

LV-651 User’s Manual Introduction

Product Specification 9

Full duplex, IEEE802.3U compliant

Connector One External RJ45 connector with LED on rear I/O panel

Audio Interface

Chipset Realtek ® ALC203 AC97 Audio compliance

Interface 2 channels sound output

Connector External Audio phone jack for Line-out, Line-in, MIC-in.

Onboard audio connector with pin header

Onboard CD-IN connector

Expansive Interface

PCI One Mini-PCI socket for TYPE III.

Bus master. 2nd Bus master is shared with Mini-PCI.

One PCI slot with riser card to support 2 PCI

Power supply: +3.3V, +5V

Power and Environment

Power Requirement 8~24V DC input or Standard 20-pin ATX power supply

Dimension 170 (L) x 170 (H) mm

Temperature Operating within 0 ~ 60℃(32 ~ 140℉)

Storage within -20 ~ 85℃(-4 ~ 185℉)

Ordering Code

LV651X-P AMD LX800 processor Mini-ITX with onboard VGA, GigaLAN,

LPT, RS232, USB2.0, Audio, IEEE1394, LCD and DDR DIMM

LV651X-256 Same as above but with 256M DDR SDRAM on board

The specifications may be different as the actual production.

LV-651 User’s Manual Introduction

MechanicalDrawing

1.3 <Mechanical Drawing>
