AmazonBasics B00LRK8JDC Manual de usuario

Portable Power Bank -10,000 mAh

B00LRK8JDC

English . . . . . . . . . . . . . .3

Français . . . . . . . . . . . . .16

日本語 . . . . . . . . . . . . 31

Deutsch . . . . . . . . . . . . .45

Italiano . . . . . . . . . . . . . .61

Español . . . . . . . . . . . . .76

English

Instruction Manual

English

AmazonBasics

Portable Power Bank -10,000 mAh

Contents

•PowerBank

• USB charging cable

•Storagebag

• This PB10 instruction manual

Compatibility

• Your power bank has 2 output ports for

a combined output of 5V/3.4A. Your

device’s power input should not be

greater than 5V/3.4A. The 5V/1A port

(port 1) is labeled with 1 icon and the

5V/2.4A port (port 2) is labeled with

2icons.

Product overview

Power button

When your power bank isn’t charging a

device, pressing the power button turns

LEDs on indicate your power bank’s charge

level.

When your power bank is charging a device,

pressing and holding the power button for 2

seconds turns your power bank on or off.

2.4A and 1.0A

USB output ports

LEDs

Micro USB

input port

Power

button

Power overload protection: Your power

bank has overload protection. To protect

your power bank and your connected

device in an overload situation, charging

stops and the LEDs turn off.

An overload can occur if the device you are

charging needs a higher power input than

your power bank can supply or if your

power bank is outputting more than 5V/3.4A

of power.

Charging your power bank

1. Plug the small connector on the

included USB charging cable into the

micro USB port on your power bank.

2. Plug the large connector on the cable

into a power source, like an AC power

adapter (not included) or a USB port on

a computer. The LEDs light from left to

right to show the current battery level.

When charging is complete, all the LEDs

stay lit.

Note: When the LED on the far left is

blinking, you need to charge your power

bank.

Checking the power level

When you’re not charging your power bank

or a device, you can check your power

bank’s power level by pressing the power

button. One or more LED(s) light to indicate

the power level.

LEDs Power level

Left LED

blinking

< 10%

1 lit Between 10% and 25%

2 lit Between 25% and 50%

3 lit Between 50% and 75%

All lit Between 75% and 100%

Charging your device

1. Plug the USB connector on the cable

that came with your device into the input

port on your device first, then plug the

other end of the cable into the one of the

output ports on your power bank.

Notes:

• You can charge two device at the same

time as long as the total power

requirement for the devices is not

greater than 5V/3.4A.

• We recommend that you use the

charging cable that came with your

device or the micro USB cable that

came with your power bank to charge

your device. Using other cables may

significantly reduce the charging speed

(or prevent you from charging).

2. If you want to stop charging your device,

press and hold the power button for 2

seconds and turn off your device.

Charging stops and the LEDs turn off.

Press the power button again to resume

charging.

Notes:

• When a lightning cable is connected to

your power bank and your power bank

is not charging a device, the LEDs stay

on for 6 hours, then turn off. If you

want to turn off the LEDs immediately,

press and hold the power button for

about 2 seconds.

• To re-start charging your iPhone or

iPad, connect the lightning cable to the

device, then press the power button to

turn your power bank back on.

LEDs

LEDs: Your power bank:

All flash, then one LED

turns on Is charging. As the power

level increases, the number

of lit LEDs changes from left

to right. When your power

bank is fully charged, all four

LEDs light.

Is charging a device. As

your power bank’s power

level decreases, the number

of lit LEDs changes from

right to left.

All four LEDs are on Is fully charged.

Far left LED blinks Has a low battery charge.

One LED blinks rapidly,

then all the LEDs turn

off

Is in an overload state.

All four LEDs are off Needs to be charged.

Note: If you unplug your

power bank from a device,

the blue LED stays on for 5

seconds.
