Altinex Multi Tasker MT107-204 Manual de usuario

MULTI-TASKER™

MANUAL PART NUMBER: 400-0396-001

8 INPUTS, FIBER OPTIC

FOR MULTI-TASKER™

MATRIX SWITCHER

USER’S GUIDE

MT107-204

MULTI-TASKER™

TABLE OF CONTENTS

Page

PRECAUTIONS / SAFETY WARNINGS ..............2

GENERAL..........................................................2

INSTALLATION .................................................2

CLEANING.........................................................2

FCC /CE NOTICE..............................................2

ABOUT YOUR MT107-204...................................3

TECHNICAL SPECIFICATIONS...........................3

PRODUCT DESCRIPTION ..................................4

APPLICATION DIAGRAM ....................................5

DIAGRAM 1: TYPICAL CONFIGURATION ........5

DIAGRAM 2INTERNAL VIEW ..........................6

INSTALLING YOUR MT107-204 ..........................7

OPERATION ........................................................7

RS-232 CONTROL.............................................7

DESCRIPTION OF COMMANDS .......................7

TROUBLESHOOTING GUIDE .............................7

NO OUTPUT ......................................................7

ALTINEX POLICY ................................................8

LIMITED WARRANTY/RETURN POLICY ..........8

CONTACT INFORMATION ................................8

MULTI-TASKER™

PRECAUTIONS / SAFETY WARNINGS 1

Please read this manual carefully before using your

MT107-204. Keep this manual handy for future

reference. These safety instructions are to ensure

the long life of your MT107-204 and to prevent fire

and shock hazard. Please read them carefully and

heed all warnings.

1.1 GENERAL

•Qualified ALTINEX service personnel, or their

authorized representatives must perform all

service.

1.2 INSTALLATION

•To prevent fire or shock, do not expose this unit

to rain or moisture. Do not place the MT107-204

in direct sunlight, near heaters or heat radiating

appliances, or near any liquid. Exposure to

direct sunlight, smoke, or steam can harm

internal components.

•Handle the MT107-204 carefully. Dropping or

jarring can damage the card.

•Do not pull the cables that are attached to the

MT107-204.

•Insert the card carefully into the slots of the

Multi-Tasker™ without bending any edges.

1.3 CLEANING

•Clean only the connector area with a dry cloth.

Never use strong detergents or solvents, such

as alcohol or thinner. Do not use a wet cloth or

water to clean the card. Do not clean or touch

any component or PCB.

1.4 FCC / CE NOTICE

•This device complies with part 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) This device may not cause

harmful interference, and (2) this device must

accept any interference received, including

interference that may cause undesired

operation.

•This equipment has been tested and found to

comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference when the

equipment is operated in a commercial

environment. This equipment generates, uses,

and can radiate radio frequency energy and, if

not installed and used in accordance with the

instruction manual, may cause harmful

interference to radio communications. Operation

of this equipment in a residential area is likely to

cause harmful interference in which case the

user will be required to correct the interference

at his own expense.

•Any changes or modifications to the unit not

expressly approved by ALTINEX, Inc. could void

the user’s authority to operate the equipment.

MULTI-TASKER™

ABOUT YOUR MT107-204 2

MT107-204

8 INPUTS, FIBER OPTIC INPUT CARD

The MT107-204 is an 8 Fiber Optic Input

expansion card for use with the MT107-104 64X64

Matrix Engine. The MT107-204 is capable of

receiving Altinex Fiber Optic signals produced from

Altinex's DA1935KM Transmitter.

Each MT107-204 connects to the Input Connector

on the MT107-104 Matrix Engine. Up to 8

MT107-204's may be connected to the Engine.

Each card is connected with the Engine via

specially provided, high bandwidth cables.

Input signals are received through high

performance fiber optic receivers converting the

signals to digital TTL levels. Once received, the

signals are redirected to any output through the

Matrix Engine.

Altinex's software and hardware allow for the

switching of any input to output combination and

prevents illegal switching combinations that may

damage components.

TECHNICAL SPECIFICATIONS 3

FEATURES/

DESCRIPTION MT107-204

GENERAL

Inputs 8

Input Connectors ST Fiber Optic Receiver

Compatibility

Signal types Keyboard and Mouse

Serial Data

Signal Rate 5Mbaud

Table 1. MT107-204 General

MECHANICAL MT107-204

Enclosure Slots Required 1 Slot per Card

Weight 0.4 lb (0.2 kg)

Connector Panel Black Anodized

T° Operating 10°C-50°C

T° Maximum 75°C

Humidity 90% non-condensing

MTBF (calc.) 38,000 hrs

Table 2. MT107-204 Mechanical

ELECTRICAL MT107-204

Input

Fiber Optic Receiver

Compatible Fibers 62.5/125um

Output

Output to Matrix Engine TTL Levels

Maximum Rate 5MBaud (5mb/s)

Table 3. MT107-204 Electrical

MULTI-TASKER™

PRODUCT DESCRIPTION 4

MULTI-TASKER™

APPLICATION DIAGRAM 5

DIAGRAM 1: TYPICAL CONFIGURATION

MULTI-TASKER™

DIAGRAM 2 INTERNAL VIEW

MT107-204, 8 FIBER OPTIC INPUTS

OUTPUT

40P ID

IN8

IN7

IN6

IN1

IN2

IN3

IN4

IN5

OUT8

OUT7

OUT6

OUT3

OUT4

OUT5

OUT2

OUT1

FIBER

OPTIC

POWER

PRESENT

MULTI-TASKER™

INSTALLING YOUR MT107-204 6

Step 1. Locate the Matrix Engine, MT107-104 or

MT107-100, currently installed in the

Multi-Tasker™. Ensure there are enough

empty slots in the enclosure to allow for

the one or more MT107-204's to be

installed.

Step 2. Route the ribbon cables through the notch

in the add-on boards and connect to the

Engine base assembly using the special

high bandwidth cables provided. Make

sure that the cable connector is secured

in the socket of the input connector card.

Step 3. Carefully, slide the MT107-204 into a slot

in the Multi-Tasker™ Enclosure.

Step 4. Secure each card by tightening the

retainer screws at the top and bottom of

each card.

Step 5. Connect the output of the DA1935KM

transmitter to one of the inputs on the

MT107-204.

Step 6. Connect the output of the MT107-304 to

the input of the DA1934KM Receiver.

Step 7. Using MTSetup or other RS-232

communication software, send commands

to the Engine to connect the new input to

the desired output.

OPERATION 7

7.1 RS-232 CONTROL

The MT107-204 has many advanced remote

control capabilities when used in the

Multi-Tasker™ Enclosure as part of an

MT107-100 Matrix Switcher. These capabilities

are accessible through standard RS-232

communication. The actual controlling can be

accomplished through a computer control

system or any other device capable of sending

RS-232 commands.

7.2 DESCRIPTION OF COMMANDS

Please, see the MT107-104 User's Guide for a

full listing of commands available for the

MT107-204 as part of a Multi-Tasker™ Matrix

Switcher.

TROUBLESHOOTING GUIDE 8

We have carefully tested and have found no

problems in the supplied MT107-204. However, we

would like to offer suggestions for the following:

8.1 NO OUTPUT

Cause 1: The source has a problem.

Solution: Check the source by connecting the

keyboard and mouse directly to the

computer and verifying they work

correctly. If they are functioning, see

Solution 2.

Solution 2: Verify the MT107-204 is connected

to the MT107-100/104 and that the

cable is in good condition. If there is

no signal, please, call Altinex at

(714) 990-2300.

MULTI-TASKER™

Cause 3: The path is not selected.

Solution: Make sure the input to output path is

correctly selected.

For example, Input 17 is connected

to Output 1 in the matrix engine.

Physically, the source signal should

be connected to Input 17 and the

receiving cable should be connected

to Output 1. See RS-232 accessible

commands in Section 7 of the

MT107-100/104's User Guide for

command details.

If the devices still fail to function

properly, see Cause 4.

Cause 4: Cable connections are incorrect.

Solution: Make sure that cables are properly

connected. Also, make sure that the

continuity and wiring are good. If the

are still not functioning, see

Cause 5.

Cause 5: The transmitting or receiving

device has a problem.

Solution: Make sure the receiving DA1934KM

and Transmitting DA1935KM have

power and are properly connected.

If there is still no response, please

call Altinex at (714) 990-2300.

ALTINEX POLICY 9

9.1 LIMITED WARRANTY/RETURN POLICY

Please see the Altinex website at

www.altinex.com for details on warranty and

return policy.

9.2 CONTACT INFORMATION

ALTINEX, INC

592 Apollo street

Brea, CA 92821 USA

TEL: 714 990-2300

TOLL FREE: 1-800-ALTINEX

WEB: www.altinex.com

E-MAIL: [email protected]
