Altec Lansing Shockwave 200 Manual de usuario

IMT7100

SHOCKWAVE 200

180W

IMT7100

Quick Start Guide UL Adaptor

IMT7100

SHOCKWAVE 200

180W

Press and hold button for 3 seconds to

power on or power off speaker

Brief introduction to buttons on top panel

Power Button：

Play/Pause (BT mode only),

AUX mode: Short press MUTE

Previous song Next song

Reset to default settings:

Press and hold the BASS button for 10S to reset all settings back to factory default.

Light Modes:

Briefly press to turn on the lighting.

Cycles through 9 modes and

then back to off

FM Mode:

Briefly press to enter into FM mode

AUX mode:

Briefly press to enter into AUX mode

BT & Party-sync Button:

Briefly press to enter into Bluetooth pairing mode,

Press and hold for Bluetooth disconnect,

Double-click for party-sync connect or disconnect

Bass Modes:

Briefly press to cycle through 3 bass

modes, Standard (flat), Bass Enhance

1 and Bass Enhance 2

AL Shockwave 200

Bluetooth Connection

Party-sync with AL SHOCKWAVE Family

Go to the Bluetooth settings menu on your phone. Make sure

that Bluetooth is turned on. Connect to the device listed

as “AL Shockwave 200”

If needed briey press the BT button to enter into BT mode;

Item Number Item name Pairing Name

IMT7000

IMT7100

IMT7200

IMT7300

Shockwave Wireless Party Speaker AL Shockwave

Shockwave 200 Wireless party speaker

Shockwave 300 Wireless Party Speaker

Shockwave 400 Wireless Party Speaker

AL Shockwave 200

AL Shockwave 300

AL Shockwave 400

ALShockwave 200

If you want to change to a dierent BT device when already paired press and

hold the BT button, the speaker will disconnect from its paired device. A dierent

device can now be paired.

A double press of the BT button is used to enter/exit party-sync mode on

extra speakers if you have them as below.

LIGHTING CONTROL

The Altec Lansing SHOCKWAVE family has four members that support party-sync.

You can mix and match between any of these four models, setting up one

speaker as the primary unit connected to up to 100 other speakers all playing

in sync.

1. Connect one speaker to your Bluetooth device in the normal way via Bluetooth.

2. Double press the BT button on this rst speaker to enter Party sync and

make it the primary speaker.

3. Double-press the BT button on the next speaker to enter Party-sync mode,

its BT LED will ashes slowly and it will nd and connect to the rst (primary)

speaker.

4. Repeat No 3 if you have more speakers you want to connect.

5. To exit party-sync double press the BT button on the speakers you wish

to disconnect and return to normal operation.

Notes:

Playback volume is adjusted via the rst (primary) speaker.

The BT playback controls only operate on the rst (primary) speaker.

Turning o the rst (primary) speaker turns o all speakers.

All secondary speakers can be turned on/o individually and their light modes

changed via their individual controls.

Briey press the LIGHTS button to switch lighting mode.

(Note: Some modes which use ‘sound-to-light’ need music playing to be visible)

Mode 1:

Rotating ring in three colors

Mode 2:

Flashing to music

Mode 3:

‘Spectrum’

Mode 4:

‘Stacking/re-stacking’ lights both sides

Mode 5:

Rotating lights in multi-colors

Mode 6:

Breathing on/o

Mode 7:

Flashing to music, solid lighting when no audio

Mode 8:

‘Bar-graph’ in multi-colors

Mode 9:

Rotating ‘stacking/re-stacking’ lights

Each press moves to the next mode and back round to o.

Descriptions about the various ports on the speaker

INPUT/OUTPUT PORTS

Knob to adjust the volume of microphone

Input socket for wired microphone

USB OUT:

For charging your mobile devices

LINE IN (AUX-IN):

For connecting the line level output or headphone

output of mobile devices or CD players etc.

DC IN:

charging your speaker from the PSU

Charging-in indicator:

Solid red when charging, will be off when fully charged

RESET:

Button is recessed inside.

For use only in the unlikely case of a lock up.

Use paperclip or pin to perform restart of the speaker.

USB-A output: 5V 1A

Power Audio: 180W (Peak) Total

Driver Units: 2 x 5.25” Bass + 2” Tweeter.

S/N: ≥70dB

Distortion: ≤0.5%(1K,1W)

USB-C charging Input: 19V 1.5A

Length of UL Adaptor cable: 110cm

Dimensions: L223*H465*D190 mm
