Allot SG-9500 Series Instrucciones de instalación

Service Gateway

SG-9500

Hardware Guide

Allot SG-9500 Hardware Guide

Important Notice

Allot Communications Ltd. ("Allot") is not a party to the purchase agreement under which Allot Service Gateway

9500 was purchased, and will not be liable for any damages of any kind whatsoever caused to the end users using this

manual, regardless of the form of action, whether in contract, tort (including negligence), strict liability or otherwise.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND

SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ALLOT OR ANY OF ITS SUBSIDIARIES. ALLOT

ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN

THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Please read the End User License Agreement and Warranty Certificate provided with this product before using the product.

Please note that using the products indicates that you accept the terms of the End User License Agreement and Warranty

Certificate.

WITHOUT DEROGATING IN ANY WAY FROM THE AFORESAID, ALLOT WILL NOT BE LIABLE FOR ANY

SPECIAL, EXEMPLARY, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY KIND,

REGARDLESS OF THE FORM OF ACTION WHETHER IN CONTRACT, TORT (INCLUDING NEGLIGENCE),

STRICT LIABILITY OR OTHERWISE, INCLUDING, BUT NOT LIMITED TO, LOSS OF REVENUE OR

ANTICIPATED PROFITS, OR LOST BUSINESS, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

photocopied, stored on a retrieval system, transmitted, or translated into any other language without a written permission and

specific authorization from Allot Communications Ltd.

Trademarks

Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their

respective companies, and are used only for identification or explanation and to the owners' benefit, without intent to infringe.

Allot and the Allot Communications logo are registered trademarks of Allot Communications Ltd.

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment

is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

Changes or modifications not expressly approved by Allot Communication Ltd. could void the user's authority to operate the

equipment.

Allot SG-9500 Hardware Guide

Version History

Each document has a version and a build number. You can tell the exact version and build

of this document by checking the table below. Details of this document version are

contained in the top row of the table below.

Document updates are released in electronic form from time to time and the most up to date

version of this document will always be found on Allot’s online Knowledge Base. To check

for more recent versions, login to the support area www.allot.com/support.html and from

the knowledgebase tab, enter the title of this document into the search field.

Doc

Release

Document Build

Date

Summary of

Changes

09/09/16

Operating Altitude

clarified

27/07/16

Battery replacement

procedure added

1/06/16

1G Fiber and

Copper added

Allot SG-9500 Hardware Guide

vii

TABLE OF CONTENTS

Important Notice ........................................................................................................................... v

Version History............................................................................................................................. vi

TABLE OF CONTENTS............................................................................................................vii

CHAPTER 1: INTRODUCING THE SG-9500................................................... 1-1

Planning Your Deployment.......................................................................................................1-2

Packing List.................................................................................................................................1-2

Cabling and Transceivers..........................................................................................................1-3

Cable types................................................................................................................................ 1-3

Transceivers.............................................................................................................................. 1-4

Connectors................................................................................................................................1-4

CHAPTER 2: CONNECTORS AND LEDS....................................................... 2-1

Front Panel..................................................................................................................................2-1

Front Panel Buttons and LEDS Description.............................................................................2-2

Front Panel Connectors.............................................................................................................2-3

Rear Panel...................................................................................................................................2-3

Rear Panel Connectors..............................................................................................................2-3

Power Supply............................................................................................................................2-4

CHAPTER 3: BYPASS..................................................................................... 3-1

External Bypass Unit..................................................................................................................3-1

HD 8 Fiber or Copper Bypass Unit...........................................................................................3-2

HD 16 Fiber Bypass Unit..........................................................................................................3-3

HD 24 Fiber Bypass Unit..........................................................................................................3-5

External Bypass Control Cabling .............................................................................................3-7

CHAPTER 4: POWER CONNECTIVITY PLANNING....................................... 4-1

Power Source Requirements .....................................................................................................4-1

Electrical GroundingRequirements..........................................................................................4-2

Cable and Cord Specifications..................................................................................................4-2

AC Power Cord Specifications................................................................................................. 4-2

DC Cable Specifications...........................................................................................................4-3

CHAPTER 5: PREPARATION AND INSTALLATION ..................................... 5-1

Unpacking the SG-9500 .............................................................................................................5-1

Mounting the SG-9500...............................................................................................................5-2

Space and Airflow Requirements............................................................................................. 5-2

Rack Mounting the Service Gateway

.....................................................................................5-2

DC Power Source......................................................................................................................5-5

CHAPTER 6: DEPLOYING THE SG-9500....................................................... 6-1

Allot SG-9500 Hardware Guide

viii

Connecting Network Traffic......................................................................................................6-1

Powering Up the SG-9500..........................................................................................................6-2

Initial Configuration ..................................................................................................................6-3

The iLO System........................................................................................................................6-3

Configuring the SG-9500..........................................................................................................6-3

CHAPTER 7: MAINTENANCE......................................................................... 7-1

Component Replacement...........................................................................................................7-1

Power Modules ...........................................................................................................................7-1

System RTC Battery ..................................................................................................................7-2

CHAPTER 8: TECHNICAL INFORMATION .................................................... 8-1

Technical Specifications.............................................................................................................8-1

Environmental Specifications....................................................................................................8-2

Safety Certifications...................................................................................................................8-2

Laser Safety Requirements........................................................................................................8-3

Laser Classification...................................................................................................................8-3

Laser Information .....................................................................................................................8-3

Laser Safety Statutory Warning................................................................................................8-3

Training for Laser Safety..........................................................................................................8-3

Laser Device Operating Precautions......................................................................................... 8-3

Allot SG-9500 Hardware Guide

TABLE OF FIGURES

Figure 1-1 –Full Duplex LC Connector ......................................................................................1-5

Figure 2-1 –SG-9500...................................................................................................................2-1

Figure 2-2 –SG-9500 Front Panel without Bezel........................................................................2-1

Figure 2-3 –SG-9500 Front Panel LEDs..................................................................................... 2-2

Figure 2-4 –SG-9500 Rear Panel ................................................................................................2-3

Figure 2-5 –NETWORK/STEERING Links...............................................................................2-3

Figure 2-6 –SG-9500 AC Power Feed ........................................................................................2-5

Figure 2-7 –SG-9500 DC Power Feed ........................................................................................2-5

Figure 2-8 –SG-9500 DC PEM with Grounding Screw..............................................................2-6

Figure 3-1: HD 8 Fiber Bypass Unit ............................................................................................3-2

Figure 3-2: HD 16 Fiber Bypass Unit ..........................................................................................3-3

Figure 3-3: HD 24 Fiber Bypass Unit ..........................................................................................3-5

Figure 3-4: Fan out Fiber Optic cable (Single Mode)..................................................................3-5

Figure 3-5: Allot USB Bypass Cable ..........................................................................................3-7

Figure 4-1: IEC-320 C13 to C14 Power Cord.............................................................................4-2

Figure 5-1: AC Power Cable Anchors..........................................................................................5-4

Figure 6-1: Connecting to Network Traffic.................................................................................. 6-1

Figure 6-2: Connecting iLO to a Dedicated Switch.....................................................................6-4

Figure 6-3: Initial Screen..............................................................................................................6-5

Figure 6-4: System Utilities Screen..............................................................................................6-6

Figure 6-5: System Configuration Screen....................................................................................6-6

Figure 6-6: Network Options Screen............................................................................................ 6-7

Figure 6-7: iLO Login Information..............................................................................................6-8

Figure 6-8: iLO Login Screen ......................................................................................................6-9

Figure 6-9: iLO Overview Screen................................................................................................6-9

Figure 6-10: iLO Remote Console Screen .................................................................................6-10

Figure 6-11: iLO Remote Console.............................................................................................6-11

Allot SG-9500 Hardware Guide

Figure 7-1: Battery Removal........................................................................................................7-3

Allot SG-9500 Hardware Guide

1-1

Chapter 1: Introducing the SG-9500

Allot Service Gateway 9500 provides a powerful service delivery platform in an Intel-

based appliance, designed especially for cloud data center, enterprise, and ISP networks.

Its small-footprint is equipped with the same rich features and functions as our chassis-

based Allot Service Gateway, enabling you to roll out Security as a Service as well as

other revenue-generating services rapidly and cost-effectively, while you lower your

total cost of ownership and accelerate ROI.

Powerful and cost-efficient service delivery platform

140 Gbps per appliance; up to 1 Tbps in a cluster

Real-time Layer-7 application visibility, policy enforcement and charging

Real-time visibility of encrypted traffic

Supporting turnkey Security as a Service solutions

Deployment and management across any access

Easy installation and pay-as-you-grow scalability

Chapter 1: Introducing the SG-9500

Allot SG-9500 Hardware Guide

1-2

Planning Your Deployment

This equipment is intended to be installed by trained service personnel and in

environments where access by unauthorized personnel is restricted (Restricted Access

Location). The SG-9500 complies with the requirements for operator access when all

cards and covers are in place.

Please note that the power resources used by the SG-9500 must be planned and installed

by a qualified electrical engineer only. Before installing or using the SG-9500, please

read all Safety Information carefully to avoid electrical hazards that can result in injury

or loss of equipment.

In addition, be aware that all network and power connections to the SG-9500 are from

the rear of the device so there must be adequate space behind the unit for safe access at

all times.

Packing List

Verify that the following items are included with the SG-9500:

SG-9500 System, either SG-9500-24P-AC or SG-9500-24P-DC.

Pair of AC power IEC-320 C13/C14 cables (included in the SG-

9500 AC version only)

One or Two Bypass units (Multi-Mode, Single Mode or Copper)

and appropriate cables to connect to the SG-9500

Up to 24 SFP+ Optical Transceivers (either SR, LR, SX or LX5

Fiber) or Copper transceivers.

2 SFP+ Optical Transceivers (either SR Fiber or LR Fiber) for

Management Ports

NOTE All Transceivers MUST be provided by Allot specifically for the

SG-9500. Any other Transceivers will not function in the SG-

9500.

BYPASS USB Control Cable(s) –number depends on number of

BYPASS units ordered (Allot P/N C245055)

Ethernet cable straight CAT6 RJ45_2_RJ45 3m for management

(Allot P/N C243010)

NOTE Cables to connect from the Bypass Unit to the Network are not

provided by Allot.

Otros manuales para SG-9500 Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Puerta de Allot

Allot

Allot SG-9100 Instrucciones de instalación

Allot

Allot SG-9500 Series Instrucciones de instalación

Allot

Allot SG-9100 Instrucciones de instalación

Manuales populares de Puerta de otras marcas

LST

LST M500RFE-AS Manual de usuario

Kinnex

Kinnex Media Gateway Manual de usuario

2N Telekomunikace

2N Telekomunikace 2N StarGate Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manual de usuario

Telsey

Telsey CPVA 500 - SIP Manual de usuario

RTA

RTA 460A-NNA4 Hoja de especificaciones

Shaw

Shaw Gateway HDPVR Manual de usuario

ABB

ABB VSN900 Guía de inicio rápido

Commander

Commander Pulse Manual de usuario

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manual de usuario

NETGEAR

NETGEAR C6300BD Manual de usuario

Amit

Amit CDW531AM Manual de usuario

HMS

HMS Netbiter EasyConnect EC150 Manual de usuario

Huawei

Huawei EchoLife HG620 Manual de usuario

AT&T

AT&T U-verse 3801 Manual de uso y cuidado

Logic IO

Logic IO RTCU MX2 turbo Manual de usuario

Suttle

Suttle MediaMAX MXM-521 Manual de usuario
