Allnet ALL1692 Manual de usuario

ALL1692 Powerline Network

ALL1692

Powerline Network

Instant Networks for Internet Access…and More!

Solution for SOHO, SMALL OFFICE AND HOME OFFICE

QUICK SETUP GUIDE

for

ETHERNET BRIDGE ALL1692

ALL1692 Powerline Network

PREFACE

This document describes installation of the ALL1692 Network products.

Please read this document before installing the product.

TO THE INSTALLER

This publication contains the following sections:

Important safety instructions

The first thing you need to know before you begin to install

Product installation guide

Specification

ALL1692 Powerline Network

IMPORTANT SAFETY INSTRUCTIONS

This product is intended for connection to the AC power line. For installation instructions, refer to the Installation

section. For removing the device, refer to the Unplug section. The following precautions should be taken when using

this product.

zPlease read all instructions before installing and operating this product.

zPlease keep all instructions for later reference.

zPlease follow all warnings and instructions marked on the product.

zUnplug the AC coupler from the wall outlet before cleaning. Use a damp cloth for cleaning. DO NOT use

liquid cleaners or aerosol cleaners.

zDO NOT operate this product near water.

zThis product should never be placed near or over a radiator, or heat register.

zThis product relies on the building’s electrical installation for short-circuit (over current) protection.

zEnsure that a fuse or circuit breaker no larger than 120 VAC 15A or 240 VAC 6A is used on the phase

conductors (all current-carrying conductors).

zDO NOT allow anything to rest on the product interconnect cords. DO NOT locate this product where people

may walk on the cords.

zBecause the ALL1692 sends data over the powerline, it is recommended that you plug directly into a power

outlet. Do not plug the device into a UPS or power strip with surge protection. The ALL1692 has its own power

filter for protection against surges.

zOnly a qualified technician should service this product. Opening or removing covers may result in exposure to

dangerous voltage points or other risks.

zUnplug the AC coupler from the wall outlet and refer the product to qualified service personnel for the following

conditions:

¾When the interconnect cords are damaged or frayed.

¾If liquid has been spilled into the product.

¾If the product has been exposed to rain or water.

¾If the product does not operate normally when the operating instructions are followed.

¾If the product exhibits a distinct change in performance.

IMPORTANT SAFETY INSTRUCTIONS

ALL1692 Powerline Network

THE FIRST THING YOU NEED TO KNOW BEFORE YOU BEGIN TO INSTALL…

1. Before installing, make sure your PC meets these requirements for hardware installation:

zMicrosoft Windows* 98SE, ME, 2000 or XP OS

zPentium® 166 MHz processor, equivalent or higher

zResource on your PC

At least one free Ethernet port for ALL1692

2. Your PC must not be configured for another network. This means that:

zNo network clients except for Microsoft Network*, Client for Netware* Networks, or Microsoft Family

Logon* are installed

zNo network services except file and printer sharing for Microsoft Networks or Personal Web Server* are

installed

zNo network protocols except Microsoft’s TCP/IP, IPX/SPX, NetBEUI, or Net BIOS support for IPX/SPX

are installed

3. Network installation requires two steps:

1. Install the ALL1692

2. For each PC to be added to the network, repeat the process

4. Check that you have the following parts for each PC on the network:

Product installation guide for Ethernet Bridge (ALL1692)

1. HardwareALL1692

2. Ethernet Cable (CAT 5)

THE FIRST THING YOU NEED TO KNOW

ALL1692 Powerline Network

5. Familiarize yourself with the ALL1692 device connections:

6. Limitation of the PLC device:

To meet the safety regulation, the longest distance between powerline carrier devices will be limited at 100

meter and for in-house use only.. More than 100 meter will cause the signal reduction or data loss.

ALL1692 Powerline Network

Product installation guide

Important:

Do not plug the device into a power strip or surge protector because these devices may consist

of filter and impair signal. Also avoid plugging the device right next to noisy sources such as cell

phone charger, Halogen light, noisy desktop computer, vacuum cleaner, etc. Both cases result in

poor transmission speed.

To install for the PC local Powerline network

1. Use the supplied Category 5 Ethernet cable to connect Ethernet Bridge and your PC’s Ethernet port.

2. Plug the Ethernet Bridge to outlet.

3. You can repeat steps 1 and 2 for connecting many other links depending on your needs.

4. The LINK and LINK/ACT LED indicator light up when you complete the above connection.

5. The ACT LED indicator startsblinking when the data communication proceeds on power line.

6. The COL LED indicator flashes when there is a Powerline communication collision.

To share a xDSL or cable modem with Internet access service

1. Connect one Ethernet Bridge to the broadband router

zPlug the Ethernet Bridge into an AC outlet.

zPlug the provided Ethernet cable into the RJ45 connector of the Bridge and plug the other end of the

cable into an available Ethernet port of the Router.

2. Connect the other Ethernet Bridge(s) to the PC(s) to share the Internet access

zPlug the Bridge into an AC outlet.

zPlug the provided Ethernet cable into the RJ45 connector of the Bridge and plug the other end of the

cable into Ethernet port on the PC.

As wireless AP (Access Point) Extender

1. Connect one Ethernet Bridge to the broadband router

zPlug the Bridge into an AC outlet.

zPlug the provided Ethernet cable into the RJ45 connector of the Bridge and plug the other end of the

cable into an available Ethernet port of the Router.

2. Connect the other Ethernet Bridge to the AP

zPlug the Bridge into an AC outlet.

zPlug the provided Ethernet cable into the RJ45 connector of the Bridge and plug the other end of the

cable into the Ethernet port on the AP.

PRODUCT INSTALLATION GUIDE

ALL1692 Powerline Network

Specification

Items Description

Line Rate 28Mbps

Ftp Data Rate Up to 8Mbps effective throughput

Frequency Band 4.3~20.9 MHz

Access Methods CSMA/CA

Qos 4 Levels

Modulation OFDM / 64 QAM

Port One Ethernet port

Standards IEEE 802.3, IEEE 802.3U, HomePlug 1.0.1

Operating System Window 98 SE, Me, NT, 2000,XP, MAC, Linux

Nodes Supports up to 15 nodes per network

LEDs LINK/ACT, LINK,ACT, COL

Operating : 0~40℃Temperature Storage : -20~60℃

Operating : 10~85% Non-Condensing

Environment

Relative

Humidity Storage : 5~90% Non-Condensing

Power Source 230 VAC 50 Hz

Max. Power consumption 5W

LEDs LINK/ACT On: 100M Ethernet device detected

Off: 10M/No Ethernet device detected

Blinking: Ethernet traffic detected

LINK On: Powerline adapter detected

Off: No Powerline adapter detected

ACT Blinking: Powerline traffic detected

Off: No Powerline traffic detected

COL Blinking: Powerline collision detected

Off: No Powerline collision detected

SPECIFICATION
