Allen-Bradley ArmorBlock 1732E Manual de usuario

Installation Instructions

1732E ArmorBlock Dual-Port

EtherNet/IP 4-Point Analog Input and

Output Modules

Catalog Numbers 1732E-IF4M12R, 1732E-OF4M12R

Table of Contents

Topic Page

Important User Information 2

Environment and Enclosure 3

Preventing Electrostatic Discharge 3

Overview 4

Catalog Number Explanation 6

Install the Module 6

Set the Network Address 6

Mount the Module 8

Product Dimensions 8

Connect the I/O, Network and Auxiliary Cables to the Module 10

Configure the Module 14

Interpret LED Indicators 16

Specifications 19

21732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules

Publication 1732E-IN006C-EN-E - June 2013

Important User Information

Solid-state equipment has operational characteristics differing from those of electromechanical

equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls

(Publication SGI-1.1 available from your local Rockwell Automation sales office or online at

http://www.rockwellautomation.com/literature/) describes some important differences between

solid-state equipment and hard-wired electromechanical devices. Because of this difference, and also

because of the wide variety of uses for solid-state equipment, all persons responsible for applying this

equipment must satisfy themselves that each intended application of this equipment is acceptable.

In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages

resulting from the use or application of this equipment.

The examples and diagrams in this manual are included solely for illustrative purposes. Because of the

many variables and requirements associated with any particular installation, Rockwell Automation, Inc.

cannot assume responsibility or liability for actual use based on the examples and diagrams.

No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits,

equipment, or software described in this manual.

Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell

Automation, Inc., is prohibited.

Throughout this manual, when necessary, we use notes to make you aware of safety considerations.

WARNING: Identifies information about practices or circumstances that can cause an

explosion in a hazardous environment, which may lead to personal injury or death,

property damage, or economic loss.

ATTENTION: Identifies information about practices or circumstances that can lead to

personal injury or death, property damage, or economic loss. Attentions help you

identify a hazard, avoid a hazard and recognize the consequences.

SHOCK HAZARD: Labels may be on or inside the equipment (for example, drive or

motor) to alert people that dangerous voltage may be present.

BURN HAZARD: Labels may be on or inside the equipment (for example, drive or

motor) to alert people that surfaces may reach dangerous temperatures.

IMPORTANT Identifies information that is critical for successful application and understanding of the

product.

1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules 3

Publication 1732E-IN006C-EN-E - June 2013

Environment and Enclosure

Preventing Electrostatic Discharge

ATTENTION: This equipment is intended for use in overvoltage Category II

applications (as defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft)

without derating.

This equipment is considered Group 1, Class A industrial equipment according

to IEC/CISPR 11. Without appropriate precautions, there may be difficulties

with electromagnetic compatibility in residential and other environments due

to conducted and radiated disturbances.

This equipment is supplied as enclosed equipment. It should not require

additional system enclosure when used in locations consistent with the

enclosure type ratings stated in the Specifications section of this publication.

Subsequent sections of this publication may contain additional information

regarding specific enclosure type ratings, beyond what this product provides,

that are required to comply with certain product safety certifications.

In addition to this publication, see:

• Industrial Automation Wiring and Grounding Guidelines, Rockwell

Automation publication 1770-4.1, for additional installation requirements.

• NEMA Standard 250 and IEC 60529, as applicable, for explanations of the

degrees of protection provided by different types of enclosure.

ATTENTION: This equipment is sensitive to electrostatic discharge, which can

cause internal damage and affect normal operation. Follow these guidelines

when you handle this equipment:

• Touch a grounded object to discharge potential static.

• Wear an approved grounding wriststrap.

• Do not touch connectors or pins on component boards.

• Do not touch circuit components inside the equipment.

• Use a static-safe workstation, if available.

• Store the equipment in appropriate static-safe packaging when not in use.

41732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules

Publication 1732E-IN006C-EN-E - June 2013

Additional Resources

If you would like a manual, you can:

• download a free electronic version from the internet:

http://rockwellautomation.com/literature.

• purchase a printed manual by contacting your local Allen-Bradley distributor or

Rockwell Automation representative

Overview

The EtherNet/IP ArmorBlock is a 24V DC I/O module that communicates via

EtherNet/IP. The sealed IP65, IP67 and IP69K housing of these modules requires no

enclosure. Note that environmental requirements other than IP65, IP67 and IP69K may

require an additional appropriate enclosure. I/O connectors are micro M12 style.

EtherNet/IP networks use advanced network technology, for example,

producer/consumer communication, to increase network functionality and throughput.

For detailed information about features, functionality, and configuration requirements

and procedure for the 1732E-IF4M12R, 1732E-OF4M12R modules, see the 1732E

ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules User

Manual, publication 1732E-UM005.

Resource Description

1732E ArmorBlock™ Dual-Port EtherNet/IP 4-Point

Analog Modules Wiring Diagrams 1732E-WD003 Pinout guide wiring diagram for the ArmorBlock

dual-port EtherNet/IP 4-Point Analog modules

(1732E-IF4M12R, 1732E-OF4M12R,

1732E-IT4IM12R, 1732E-IR4IM12R).

1732E ArmorBlock Dual-Port EtherNet/IP 4-Point

Analog Input and Output Modules User Manual

1732E-UM005

A detailed description of module functionality,

configuration, installation procedure and

information on how to use the ArmorBlock

dual-port EtherNet/IP 4-Point Analog Input and

Output modules (1732E-IF4M12R,

1732E-OF4M12R).

Industrial Automation Wiring and Grounding

Guidelines, publication 1770-4.1.More information on proper wiring and grounding

techniques.

1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules 5

Publication 1732E-IN006C-EN-E - June 2013

Module Identification

(1) Function Earth grounds the I/O block’s EtherNet/IP communication circuitry which is designed to mitigate the effect of

noise on the network. The device requires a solid earth ground connection, either through a metal screw to a grounded

metal panel or through a wire. See Ethernet Connector on page 11 for connections.

45871

Link 1 status indicator

Function earth(1)

EtherNet/IP D-code

M12 connector

M12 style

I/O connectors

Micro-style power in Micro-style power out

I/O status

indicators

EtherNet/IP D-code

M12 connector

Link 2 status indicator

Node address switches

Network status indicator

Module status indicator

Auxiliary Power

status indicator

61732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules

Publication 1732E-IN006C-EN-E - June 2013

Optional Accessory

The following table identifies optional accessory that you can use with the modules that

have to be ordered separately.

Catalog Number Explanation

Refer to the table for a description of the module catalog numbers.

Install the Module

To install the module:

• Set the network address

•Mountthemodule

• Connect the Functional Ground and Module power/Auxiliary power cables

• Connect the I/O and Network cables to the module

Set the Network Address

The I/O block ships with the rotary switches set to 999 and DHCP enabled.

To change the network address, you can do one of the following:

• adjust the switches on the front of the module.

• use a Dynamic Host Configuration Protocol (DHCP) server, such as

Rockwell Automation BootP/DHCP.

Option Catalog Number

Snap-in individual marker card(1)

(1) Provides labelling for the terminal blocks to allow for easy identification and description.

1492-MD6X9

Catalog Number Description Network

Connector

Power

Connector

1732E-IF4M12R 24V DC power, 4-Point Analog Input,

Dual-Port EtherNet/IP Module Dual D-code M12 Dual 4-pin micro

1732E-OF4M12R 24V DC power, 4-Point Analog

Output, Dual-Port EtherNet/IP

Module

1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules 7

Publication 1732E-IN006C-EN-E - June 2013

• retrieve the IP address from nonvolatile memory.

The I/O block reads the switches first to determine if the switches are set to a valid

number. To set the network address:

1. Remove power.

2. Remove the switch dust caps.

3. Rotate the three (3) switches on the front of the module using a small

blade screwdriver.

4. Line up the small notch on the switch with the number setting you wish to use.

Valid settings range from 001…254.

5. Replace switch dust caps. Make sure not to over tighten.

6. Reapply power.

7. Record IP address on product label found on the side of enclosure.

Set Network Address

When the switches are set to a valid number, the I/O block’s IP address is 192.168.1.xxx,

where xxx represents the number set on the switches. The I/O block’s subnet mask is

255.255.255.0 and default gateway address is set to 192.168.1.1.

When the I/O block uses the network address set on the switches, the I/O block does not

have a host name assigned to it or use any Domain Name Server.

If the switches are set to an invalid number (for example, 000 or a value greater than 254

excluding 888), the I/O block checks to see if DHCP is enabled. If DHCP is enabled, the

I/O block asks for an address from a DHCP server. The DHCP server also assigns other

Transport Control Protocol (TCP) parameters. The modules are shipped with the

network switches set to 999.

If DHCP is not enabled, the I/O block uses the IP address (along with other TCP

configurable parameters) stored in nonvolatile memory.

44233

Note: You need to remove the

protective switch dust caps before you

can adjust the address settings.

Example shows the node address

switches at 163, which sets the

module IP address to 192.168.1.163.

81732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules

Publication 1732E-IN006C-EN-E - June 2013

Network Address Switch value 001

The module IP address cannot be the same as the gateway address. If the address switches

are set to 001, the module IP address becomes 192.168.1.1, which is the same as the default

gateway address. In this case, the module gateway address will be set to 0.0.0.0.

Default Factory Configuration

The switch value 888 resets the module to default factory configuration on power up. The

module will not operate properly when powered up with this setting. The switches must be

set to a different (and valid) value and then power cycled after a reset.

While in reset state, the module LED flashes red and the network LED goes off.

Mount the Module

Two sets of mounting holes are used to mount the module directly to a panel or machine.

Mounting holes accommodate #6 (M3) pan head screws. The torque specification is

0.68 Nm (6 lb-in.).

Product Dimensions

Refer to the mounting dimensions illustration to help you mount the module.

1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules 9

Publication 1732E-IN006C-EN-E - June 2013

Module Dimensions

37 (1.46)

16.2 (0.64)

168.6 (6.64)

(1.26)

(1.70)

43.3

(0.78)

19.8

166.5 (6.56)

(1.06)

6LGH0RXQWLQJ

)URQW0RXQWLQJ

179 (7.05)

(0.71)

Measurements are in millimeters (inches)

45870

10 1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules

Publication 1732E-IN006C-EN-E - June 2013

Mount the Module in High Vibration Areas

If you mount the module in an area that is subject to shock or vibration, we recommend

you use a flat and a lock washer to mount the module. Mount the flat and the lock washer

as shown in the mounting illustration. Torque the mounting screws to 0.68 Nm (6 lb-in.).

High Vibration Area Mounting

Connect the I/O, Network and Auxiliary Cables to the Module

The 1732E-IF4M12R, 1732E-OF4M12R ArmorBlock EtherNet/IP modules have 5-pin

micro-style M12 I/O connectors. We provide caps to cover the unused connectors on your

module. Connect the quick-disconnect cord sets you selected for your module to the

appropriate ports.

I/O Connectors

Micro-style M12 5-Pin Input Female Connector – 1732E-IF4M12R

45768

Lock washer

Flat washer

45868

(View into connector)

Pin 1 Current Input +

Pin 2 Current Common

Pin 3 Voltage Input +

Pin 4 Voltage Common

Pin 5 No Connect

Otros manuales para ArmorBlock 1732E

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unidad de control de Allen-Bradley

Allen-Bradley

Allen-Bradley ControlNet 1747-ACN15 Manual de usuario

Allen-Bradley

Allen-Bradley ArmorBlock 1732D A Series Manual de usuario

Allen-Bradley

Allen-Bradley POINT I/O 1734-OB2 Manual de usuario

Allen-Bradley

Allen-Bradley 1771-QDC Manual de usuario

Allen-Bradley

Allen-Bradley 1757-ABRIO Manual de usuario

Allen-Bradley

Allen-Bradley ControlLogix DeviceNet 1756-DNB Manual de usuario

Allen-Bradley

Allen-Bradley 1718 Ex I/O Manual de usuario

Allen-Bradley

Allen-Bradley ControlLogix DeviceNet C Series Manual de usuario

Allen-Bradley

Allen-Bradley 160-DN2 Manual de usuario

Allen-Bradley

Allen-Bradley 1756-EN2TSC Manual de usuario

Allen-Bradley

Allen-Bradley 1794-OW8 Manual de usuario

Allen-Bradley

Allen-Bradley ArmorBlock Series Manual

Allen-Bradley

Allen-Bradley 1747-ASB Manual de usuario

Allen-Bradley

Allen-Bradley MicroLogix 1500 1764-MM1 Manual de usuario

Allen-Bradley

Allen-Bradley 1770-KFDG Manual de usuario

Allen-Bradley

Allen-Bradley ControlLogix DeviceNet 1756-DNB Hoja de instrucciones

Allen-Bradley

Allen-Bradley C Series Manual de usuario

Allen-Bradley

Allen-Bradley 1407-CGCM-DLR Manual de usuario

Allen-Bradley

Allen-Bradley DeviceNet 1747-SDN Manual de usuario

Allen-Bradley

Allen-Bradley ControlLogix 1756-ENET/B Manual de usuario

Allen-Bradley

Allen-Bradley DeviceNet 1203-GK5 Manual de usuario

Allen-Bradley

Allen-Bradley POINT I/O PROFIBUS 1734-APB Manual de usuario

Allen-Bradley

Allen-Bradley 1769-SDN Manual de usuario

Allen-Bradley

Allen-Bradley ControlLogix ControlNet B Series Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
