Allegion Interflex IF-4072 Manual de usuario
IF-4072 Controller
Controller
00-4072-04xx
Table of contents
© 2021 Interflex Datensysteme GmbH IF-4072 Controller 2
Table of contents
1 General information.......................................................................................................................... 3
1.1 Short description ......................................................................................................................... 3
1.2 Scope of delivery ........................................................................................................................ 3
1.3 Intended use ............................................................................................................................... 3
1.4 Target group ............................................................................................................................... 3
1.5 Safety.......................................................................................................................................... 4
1.6 Abbreviations .............................................................................................................................. 4
1.7 Cable lengths and cable types.................................................................................................... 5
2 System overview............................................................................................................................... 6
2.1 Range of functions ...................................................................................................................... 7
2.2 IF-4072 controller overview......................................................................................................... 7
3 Mounting the controller.................................................................................................................... 9
4 Connecting the controller ................................................................................................................ 9
4.1 Wiring components ..................................................................................................................... 9
4.2 Connecting the power supply...................................................................................................... 11
5 Initial operation ................................................................................................................................. 12
5.1 Connecting the controller to the network .................................................................................... 13
5.2 Checking and setting network parameters.................................................................................. 14
5.3 Configuring the interfaces and the booking memory .................................................................. 16
5.4 Listing the configuration data of readers..................................................................................... 17
5.5 Restarting the controller.............................................................................................................. 18
6 Updating the software ...................................................................................................................... 20
7 Upgrading the controller.................................................................................................................. 21
8 Technical specifications .................................................................................................................. 21
9 Disposal............................................................................................................................................. 22
10 EU Declaration of Conformity.......................................................................................................... 22
1 General information
© 2021 Interflex Datensysteme GmbH IF-4072 Controller 3
1 General information
1.1 Short description
The controller IF-4070 serves as the connecting link between a maximum of 16 Interflex readers for time
& attendance recording or access control. Two integrated relays and four input contacts allow for the
control and monitoring of doors, for example. The controller is available in four different versions which
support two, four, eight or sixteen readers.
1.2 Scope of delivery
nIF-4072 controller
n7 terminal strips
nCover for USB connector
n9510426 product info
Check the completeness and condition of the goods upon receipt and report any damage caused
during transport immediately.
1.3 Intended use
Controllers of this series are designed for fixed installation in dry rooms.
Any other use is not in accordance with the intended purpose and therefore not permitted. Modifications
to the device are not permitted.
1.4 Target group
This document is solely intended for experts and people trained in electrical engineering.
Only perform the actions described in this document if you belong to this target group. Interflex
Datensysteme GmbH is not liable for any damages caused by improper installation or initial
operation.
1 General information
© 2021 Interflex Datensysteme GmbH IF-4072 Controller 4
1.5 Safety
NOTICE
Property damage due to transient overvoltages
Transient overvoltages (surges, bursts) in the energy supply network can lead to malfunctions and
failures.
uUse suitable mains filters that are professionally installed and operated.
NOTICE
Damage due to electrostatic discharge (ESD)
Electrical components and modules can be damaged by only slight, hardly noticeable electrostatic
discharge (ESD) without this becoming immediately obvious. ESD damages result in malfunctions and
even failure of the product.
uMake sure that effective protective measures against electrostatic discharge are in place when
working on the open device.
1.6 Abbreviations
AC Alternating Current
BLE Bluetooth Low Energy
CIDR Classless Inter-Domain Routing
DC Direct Current
DIP switch Switch in IC design, connections in two rows (Dual In-line Package)
EMC Electromagnetic Compatibility
ESD Electrostatic discharge
GND Ground
IEEE Institute of Electrical and Electronics Engineers
NC contact Normally closed contact
NO contact Normally open contact
PoE Power over Ethernet
RFID Radio-Frequency Identification
SH Shield
1 General information
© 2021 Interflex Datensysteme GmbH IF-4072 Controller 5
SSH Secure shell
1.7 Cable lengths and cable types
Cable Function Max. Length Recommended cable type
230 V AC power supply to power supply unit (if not
pre-installed)
NYM 3 x 1.5mm2
Network cabling: RJ45 patch cable, preferably shield
braiding
100 m From category 5
Cable to floating status contacts, control cable 100 m J-Y(St) Y 2 x 2 x 0.6mm2
J-Y(St) Y 2 x 2 x 0.8mm2
RS485 bus cable to parent or child devices 1200 m J-Y(St) Y 2 x 2 x 0.6mm2
J-Y(St) Y 2 x 2 x 0.8mm2
RS485 branch cable to bus cable 100 m J-Y(St) Y 2 x 2 x 0.6mm2
J-Y(St) Y 2 x 2 x 0.8mm2
Connecting cable between I/O controller board and
reader
100 m J-Y(St) Y 4 x 2 x 0.6mm2
J-Y(St) Y 4 x 2 x 0.8mm2
In long cables, voltage losses can impair the functionality of the connected device. Therefore, do not use
cables longer than specified in the table. Wire the +5 V and GND lines with two cores each for a cable
length > 50 m.
2 System overview
© 2021 Interflex Datensysteme GmbH IF-4072 Controller 6
2 System overview
1Controller 1Cable to floating status contacts
2Inputs for floating status contacts 2Control cable
3Relay with 30V, 2A switch contacts 3Power cable (not applicable for PoE)
4Switch or PoE device 4Ethernet without PoE
5Host system 5Terminal bus cable
6Readers for recording time data 6RS485 branch cable from reader to bus cable
7Reader for access control
8Locking device with access control actuator
and status contact
9Readers for recording time data
2 System overview
© 2021 Interflex Datensysteme GmbH IF-4072 Controller 7
2.1 Range of functions
Main functions of the If-407x controller:
Field of Application
The controllers are operated with the IF6020 or IF6040 host system and control up to 16 Interflex readers
for time & attendance recording or access control that are distributed among three RS485 interfaces. The
controllers check the booking data from the readers and transfer it to the host system in real-time.
Furthermore, they control the booking conditions and display texts of the readers.
Offline mode
Data required for offline operation (e.g., credential numbers, temporal and local permissions) is stored in
the controller via the host system. Thus, the data is always up-to-date even if the connection to IF-6020
and IF-6040 is interrupted and can be checked by the controller in offline mode.
Control and Monitoring
For controlling and monitoring doors, for example, the IF-4070 controller is equipped with digital inputs for
the connection of door contacts or other sensors and output relays with a switching capacity of up to 30
V/ 2 A. Thus, external devices can also be controlled. The input sensors can be configured as indicator,
event, or counting contacts (up to max. 20 Hz).
2.2 IF-4072 controller overview
Connections
1
89 7 5
2 3 4
6
14-pin screw terminal for relay contacts 24-pin screw terminal for relay contacts
38-pin screw terminal for floating status
contacts
46-pin screw terminal for power supply
2 System overview
© 2021 Interflex Datensysteme GmbH IF-4072 Controller 8
5RJ45 socket for the connection to the
Ethernet network (host system)
610-pin for RS485
bus data cables 1 2 3
7USB connection (for future use) 83-pin for RS232
service device
9Host connection via serial interface
(RS232)
LEDs, push-buttons and switches
4
8 7 6
2 31 5
No. Description Function
1SW1 Factory reset: Save IP address settings temporarily and set
default IP address to 172.18.70.52.
2CS Delete stored data, restore standard parameters
3RST Cancel active processes, trigger restart
No. LED Status Operating mode of the controller
4RUN Lights up Application has been started; controller is ready for operation
5VCC Lights up Operating voltage applied
6SPE Lights up Network speed: Lights up at 100 Mb / off at 10 Mb
7ACT Lights up Flashes when data is exchanged via network
8Bus 1 / 2 / 3 Lighted/ off Data exchange with reader on bus 1 / 2 / 3
3 Mounting the controller
© 2021 Interflex Datensysteme GmbH IF-4072 Controller 9
3 Mounting the controller
NOTICE
Damage to property due to manipulation of the controller
Manipulation of the controller can lead to data loss.
uInstall the controller in the secured area, taking the technical requirements into account
uMount the controller on a TS35 DIN rail, e.g. in a distribution box.
4 Connecting the controller
4.1 Wiring components
The cables can be fixed to the cutouts in the bottom plate of the housing with cable ties.
Ethernet network
The device is set up for connection to 10/100 Mb/s Ethernet networks. Connection and speed are
indicated by LEDs on the front panel LEDs and switches.
When assigning the IP address and setting up the network, observe the current state-of-the-art
technology for securing and segmenting corporate networks. Interflex recommends operating all
installed devices and servers in one VLAN.
Bus data cables with readers
You can connect up to 8 readers to each bus interface. A maximum of 16 readers can be
connected to the controller.
nAlways connect a reader with address 1 to bus 1.
nEvenly distribute the readers among the three bus interfaces. The factory setting for the
interfaces is as follows:
– Bus 1: 6 readers max.
– Bus 2: 4 readers max.
– Bus 3: 6 readers max.
Make sure that each reader has a unique hardware address within the bus.
4 Connecting the controller
© 2021 Interflex Datensysteme GmbH IF-4072 Controller 10
BUS 1+
BUS 1-
BUS 2-
BUS 2+
V-
V+
BUS 3+
BUS 3-
You can find further information on how to connect the bus data cables in the section IF-4072 controller
overview [}7].
Floating status contacts and relays
PAT
NO
NC
Cn
230 VRelays
Status contacts
GND
IN 1
IN 2
GND
IN 3
IN 4
An NO or an NC contact can be used for switching devices up to 30 V, 2 A. Outgoing cables can be
looped at the PAT terminals.
