Alcatel Pixi 3 (7) Manual de usuario

Thank you for buying ALCATEL ONETOUCH 9002X.We hope

you will enjoy your high-quality communication experience.

You have purchased a product which uses the open source

(http://opensource.org/) programs mtd, msdosfs, netfilter/

iptables and initrd in object code and other open source

programs licensed under the GNU General Public License and

Apache License.

We will provide you with a complete copy of the corresponding

source codes upon request within a period of three years from

the distribution of the product by TCL Communication Ltd.

You may download the source codes from http://sourceforge.

net/projects/alcatel/files/. The provision of the source code is

free of charge from internet.

Quick Start Guide

English - CJB1CP0ALAAA

Table of contents

1 Your device................................................................3

1.1 Appearance illustration .................................................... 3

1.2 Home screen ...................................................................... 5

1.3 Apps and widgets............................................................... 7

1.4 Basic operation................................................................... 8

2 Settings ....................................................................10

2.1 Device................................................................................. 10

2.2 Personal ............................................................................ 11

2.3 System ................................................................................ 11

3 Phone call ...............................................................12

3.1 Placing a call ...................................................................... 12

3.2 Answering or rejecting a call ........................................ 13

Safety information .......................................................14

General information ....................................................21

Warranty ......................................................................23

This device meets applicable national SAR

limits of 2.0 W/kg. SAR values can be found on

page 19 of this user guide.When carrying the

device or using it while worn on your body,

either use an approved accessory such as a

holster or otherwise maintain a distance of

10 mm from the body to ensure compliance

with RF exposure requirements. Note that

the product may be transmitting even if you

are not using it.

To prevent possible hearing damage, do not

listen at high volume levels for long periods.

Exercise caution when holding your device

near your ear while the loudspeaker is in use.

The tablet contains magnets which may

interfere with other devices and items (such

as credit card, pacemakers, defibrillators, etc.).

Please maintain at least 15 cm of separation

between your tablet and the devices/items

mentioned above.

www.sar-tick.com

1 Your device

1.1 Appearance illustration

Number Function

1Earphone Interface

2Micro-USB connector/Battery charge

3Front camera

4Power key

5Volume Up/Down

6SIM Card and microSD Card

7Rear camera

Inserting the micro SIM card & the microSD card

Take care to insert your SIM and Micro SD card in the correct

direction to avoid damage. Please refer to the following instructions.

Note

Please charge before first use. Normally, press and hold

the Power key will power the tablet on and the Home

Screen will show up, but a battery icon will show instead

of the Home Screen when the tablet is lack of power,

that indicates you should charge before use. Use only charger

recommended by TCL Communication Ltd. and its affiliates.

This device cannot be charged through USB computer connection.

Please plug in your charger before first usage.

1.2 Home screen

Your device includes three pages of Home screen giving you

more space to add your own favorite apps, folders, and widgets

for one-touch access. To switch between screens, sliding your

finger to left or right.

1.2.1 Lock/Unlock your screen

Once your device is powered on, it shows a locked screen

interface, which is set as default.

Press and slide right the locked screen to unlock, slide left to

access camera.

1.2.2 Icons on your screen

Google Search

All Apps

Back

Status Bar

Voice Actions

Home

Recent apps

Name Description

Google

Touch it to access the Google search

engine.

Voice Actions Use Voice Actions to watch a video, send

email, set alarm, get directions, etc.

All Apps Touch to show all apps list interface.

Back Go back to the previous menu or screen.

Home Return to the home screen.

Recent apps Press to view recent apps.

Touch and drag down the Status bar to open the Quick setting

panel or Notification panel. Touch and drag up to close it.

Notification panel

When there are notifications, touch and drag down the Status

bar to open the Notification panel and read the detailed

information.

Touch to switch to the

Quick setting panel

Touch to clear all event–based

notifications (other ongoing

notifications will remain)

Quick setting panel

You can enable or disable functions or change modes by

touching the icons on Quick setting panel.

Touch to switch to

Notification panel.

Touch to access Settings,

where you can set more

items.

1.3 Apps and widgets

1.3.1 Apps

The Applications (apps) list contains all pre-embedded and

newly installed apps. To access the apps list, touch the all apps

key from Home screen.

1.3.2 Widgets

By touching and holding an empty area in Home screen,you can

switch to widgets interface.

1.3.3 Get more apps

Touch the Google Play Store icon to get more apps.

1.3.4 Create and manage shortcut on desktop

Touch and hold an icon on All Apps or Downloaded interface,

it will jump to home screen automatically, drag it to the right

place you want.

1.3.5 Remove apps icon from desktop

Touch and hold the icon you want to delete from the

desktop, drag it right over the , which is at the top of

the screen.

1.3.6 Uninstall apps

Press to enter all Apps, then touch and hold the App icon

you want to uninstall, drag it over the , which appears top-

left in the desktop.

1.4 Basic operation

1.4.1 Power on your device

Press and hold the Power key until the tablet powers on. It will

take a few seconds to light up the screen.

1.4.2 Power off your device

•Press and hold the Power key about 3 seconds until

the options appear, select Power off to power off your

device.

•Press and hold the Power key about 10 seconds to restart

your device.

1.4.3 Stand-by mode

Press Power key once to shut down the screen and the device

enters stand-by mode.

Note: Without operation, the product will enter stand-by

mode automatically. Press Power key once to wake it up.

1.4.4 Connecting to a computer via USB

When connecting your device to computer by USB, you can

transfer files between your device and the computer.

1.4.5 Change your wallpaper

You can change your wallpaper by touching Settings >

Display > Wallpaper.

1.4.6 Wi-Fi

To turn Wi-Fi on and connect to a wireless network:

•Touch Wi-Fi icon on Quick setting panel to turn on/

off Wi-Fi.

•Select Settings, touch the switch below Wi-Fi to

turn on/off Wi-Fi.

•Touch a Wi-Fi network to connect. If the network you

selected is secured, you are required to enter a password

or other credentials (You may need to contact the

network operator for details). When finished, touch

Connect.

Tip: To extend the battery life, turn off Wi-Fi when you're not

using it.

1.4.7 Zoom in/out

Draw your fingers apart/together to zoom in/out (Web

browser, Gallery etc..).

2 Settings

2.1 Device

2.1.1 Sound

You can set Volumes, Touch sounds and Screen locking

sounds to your preference with the Volume up/down key, or

touch Settings > Sound & notification.

2.1.2 Display

Touch Settings > Display, you can see the items:

•Wallpaper Set your wallpaper.

•Brightness

level

Adjust your screen in a comfortable brightness.

•Font size Select a suitable font size for your tablet.

•Sleep Set Screensavers time.

•Daydream Select an animation effect shows in standby

status.

2.1.3 Storage

Touch Settings > Storage to view the memory using status.

2.1.4 Battery

Touch Settings > Battery to check the battery power and

its service status.

2.1.5 APPs

Touch Setting > Applications to check the APP status.
