Alcatel One Touch POP 7 LTE T-Mobile Guía

CJB1FD0ALAAA

PRINTING STATIONS:

T-MOBILE

MAGENTA

4-COLOR

PROCESS

PROCESS MIX:

72% K

SPOT

47% K

TABLE OF CONTENTS

Support..................................................................... 1

Service Activation.................................................... 2

Device Overview ..................................................... 3

SIM Card .................................................................. 4

Memory Card........................................................... 5

Power ........................................................................ 7

Home Screen........................................................... 7

Tethering & Mobile HotSpot ...............................11

Accessing Files .....................................................12

Contacts .................................................................12

Gmail.......................................................................13

Text Entry................................................................13

Text Messaging .....................................................16

Web Browsing .......................................................19

Bluetooth®..............................................................20

Battery & Memory Management.........................21

Protecting Your Device ........................................23

Accessories............................................................24

Caring For Your Device .......................................25

Approved Firmware Versions..............................26

Additional Information..........................................27

TCL Communications Ltd. Warranty..................29

Electronic Recycling Program ............................32

Safety Information.................................................32

ALCATEL Information...........................................44

SERVICE ACTIVATION

If you are a new T-Mobile®customer and your service

has not yet been activated, simply call Customer

Care at 1-800-937-8997 and a T-Mobile Activations

representative will assist you.

You will need the following information

when activating service:

nYour Service Agreement and the agent code on

your Agreement

nYour name, home address, home phone

number, and billing address

Note: For business and government accounts,

please provide the organization’s name,

address, and tax ID.

nYour Social Security number, current driver’s

license number, and date of birth for credit

check purposes

nYour choice of T-Mobile rate plan and services

(see www.t-mobile.com for latest plan

information)

nYour SIM serial number and IMEI number

(located on the box barcode label)

By activating service, you acknowledge that you have read, understand,

and agree to be bound by each of T-Mobile’s Terms and Conditions, and

by your Service Agreement.

SUPPORT

This guide provides you with the information you need

to get started.

For more information and additional support, please

visit www.t-mobile.com/support where you can:

nRegister at my.t-mobile.com to check your

minutes, pay your bill, upgrade your device, and

change your rate plan.

nReview your device’s User Manual and

troubleshooting FAQs.

nView the latest troubleshooting solutions in the

Support Forums or ask a question of your own.

Volume up/down

keys

Power key

Camera

SIM CARD

The SIM (Subscriber Identity Module) card identifies

your device to the wireless network. You cannot

browse the Internet using network without properly

installing SIM card.

Installing SIM card

1. Detach the SIM card from its packaging.

DEVICE OVERVIEW

Headset connector

Micro-USB

Connector

Front

camera

Touch

screen

Back key Recent key

Home key

MEMORY CARD

Memory cards add extra storage space for your

music, pictures, videos, and more. This device uses

a microSD memory card size. Memory card sold

separately.

Installing memory card

1. Insert the microSD card into the microSD slot.

Follow the steps below and the icons on your

device to insert microSD card accurately.

2. Insert SIM card into SIM slot located on left side

of device. Follow the steps below and the icons

on your device to insert SIM card accurately.

Back

•

Touch to go back

to last screen.

Applications icon

•

Touch to open applications menu.

Search bar

• Touch to enter text

search screen.

• Touch to enter voice

search screen.



Favorite applications tray

•

Touch to enter the applications.

•

Touch and hold to move or

change applications.

Swipe main home screen left and right

to view additional home screens.

Recent apps

•

Touch to view recent apps.

Status bar

• Touch and drag down to open

the notifications panel.

Home screen is provided in an extended format to

allow more space for adding applications, shortcuts

etc. Slide all Home screens horizontally left and right

to get a complete view of the Home screens. The

white circles at the lower part of the screen indicate

which screen you are viewing.

Status bar

The Status bar appears at the top of your Home

screen. Icons indicating your tablet’s status and new

notification alerts appear in the Status bar.

Charging your device

1. Insert the small end of the charging cable into

the device micro-USB connector located on top

of device, as shown.

2. Plug the other end of the charging cable into

provided charger, connect charger to power

outlet.

POWER

To turn the power on or off, press and hold the power

key located on right side of device.

HOME SCREEN

You can bring all the items (applications, shortcuts,

folders and widgets) you love or use most frequently

to your Home screen for quick access. Touch the

Home key to get instant access to the Home screen.

109

Unlock the screen

Press the Power key once to light up the screen,

slide the screen up, draw the unlock pattern you have

created or enter PIN or password to unlock the screen.

Add items to the Home screen

1. Tap the Applications icon to access the

Applications menu.

2. Touch and hold the desired item, and then drag

it to a blank area on the preferred Home screen.

Move and delete items

Touch and hold the item you want to move or

delete and then drag it to another location or to the

X Remove icon at the top of the screen.

Change Home screen wallpaper

You can change your wallpaper two different ways:

1. Touch and hold an empty area on the Home

screen and then select WALLPAPERS from

bottom options. Slide left and right to view

Wallpaper image options, touch Set Wallpaper

on top bar to set image.

2. Change your wallpaper by going to Settings >

Display > Wallpaper.

Notifications panel

Touch and drag down the Status bar to open the

Notifications panel. Touch the notifications to view

details or touch on the bottom of Notifications

panel to clear all notifications (ongoing notifications

will remain). In the Notifications panel, touch or swipe

down the top gray bar to access the Settings shortcut

panel. Touch Settings shortcut options displayed to

enable/disable functions or to access full Settings

menu touch Settings icon at top of panel.

Touch to access Settings

menu with all options

Touch to clear all notifications

(ongoing notifications will remain).

Applications menu

To access all Applications from the Home screen, tap

the Applications icon . Swipe up or down through

the menu screens to view all applications. As you

download new applications, they will appear in the

Applications menu in alphabetical order.

1211

2. Toggle Mobile HotSpot button to right On

position, bar will display in blue. If first time

activating Mobile HotSpot, you will be prompted

to create password.

3. Use computer to search for Mobile HotSpot

wireless name ALCATEL ONETOUCH POP7

LTE XXXX ( the last four digits of your device’s

IMEI), select to connect.

4. Enter password to complete connection.

ACCESSING FILES

To access media files and photos saved on your

device or to transfer files from your SD card to your

computer, connect your device to a computer using

supplied USB Cable.

Once connected to computer, swipe down your

device’s Status to see USB for file transfer option,

select this option. Then select the file type you would

like to access:

• Transfer files (MTP) to access media files.

• Transfer photos (PTP) to access camera photos.

Please note, you can only access one file type option

at a time. Once file type is selected use your computer

to access your device files.

TETHERING & MOBILE HOTSPOT

Tether your device

1. Use provided USB Cable to connect your device

to your computer. You will see in Status bar

when USB tethering is active.

2. Tap the Applications icon .

3. Tap Settings .

4. Tap More.

5. Tap Tethering & Mobile HotSpot.

6. Tap the switch icon next to USB tethering to turn

on tethering (Wi-Fi must be off to activate this

option).

Tethering works with Windows® XP, Windows® 7,

Windows 10, Windows Vista®, Mac OS X and Linux.

When you connect your device to a computer with

a USB cable, you can either share your mobile data

connection by tethering or you can share files—you

cannot do both. Do not turn on tethering if you want

to use your computer to access your device’s memory

card.

Activating Mobile HotSpot

1. From Home screen or Applications menu touch

Mobile HotSpot icon.

1413

typing and touch it to view available settings for each

input option.

Adjust the Onscreen Keyboard orientation

Turn the device sideways or upright to adjust the

Onscreen Keyboard orientation. You can also adjust

Onscreen Keyboard orientation by changing the

settings. Select Settings , select Display, then

select Rotate the contents of the screen or Stay in

current orientation after touching the When device

is rotated.

CONTACTS

Adding a new contact

1. From the Home screen, touch .

2. Touch to create a new contact.

3. Enter contact’s name and other contact

information.

4. When finished, touch to save.

GMAIL

Setting up Gmail™

1. From the Home screen, tap the Applications

icon .

2. Tap .

3. Follow the on-screen instructions.

TEXT ENTRY

Onscreen Keyboard settings

Touch from the Home screen, touch Settings

and select Language & input. Scroll to KEYBOARD

& INPUT METHODS, locate keyboard of choice:

Android keyboard, Google Keyboard, or Google voice

1615

TEXT MESSAGING

Use the messaging feature to send and receive text

(SMS) and multimedia (MMS) messages.

Writing a message

In message screen, touch the new message icon

to write text/multimedia messages.

Touch to view the whole

message thread.

Touch to search in all messages.

Touch to create a new message.

To communicate with a saved contact, touch

contact photo in Message history to open

Quick Contact panel. For unsaved contacts,

touch default photo in Message history to

add the number to your Contacts.

Android keyboard

Touch to switch

between << abc/

Abc/ABC >> mode.

Press and hold

to open settings.

Touch to

input space.

Touch to switch between symbol

and numeric keyboard.

Touch to

enter text.

Text editing

You can edit the text you have entered.

• Touch and hold or double-tap within the text you

would like to edit.

• Drag the tabs to change the highlighted selection.

• The following options will be available: CUT,

COPY, SHARE, SELECT ALL, REPLACE... and

PASTE.

Otros manuales para One Touch POP 7 LTE T-Mobile

Tabla de contenidos

Otros manuales de Tableta de Alcatel

Alcatel

Alcatel A30 FIERCE Manual de usuario

Alcatel

Alcatel JOY TAB KIDS2 Manual de usuario

Alcatel

Alcatel Smart 3T10 Manual de usuario

Alcatel

Alcatel TKEE MAX Manual de usuario

Alcatel

Alcatel 1T 7 Manual de usuario

Alcatel

Alcatel OneTouch Pixi 3 (7) 8055 Manual de usuario

Alcatel

Alcatel ONETOUCH HERO 8 D820X Manual de usuario

Alcatel

Alcatel TKEE MINI Manual de usuario

Alcatel

Alcatel ONE TOUCH T60 Manual de usuario

Alcatel

Alcatel onetouch Pop8 Manual de usuario

Alcatel

Alcatel onetouch pixi 7 Manual de usuario

Alcatel

Alcatel Joy Tab Guía

Alcatel

Alcatel onetouch pixi 7 Manual de usuario

Alcatel

Alcatel 9009G Manual de usuario

Alcatel

Alcatel Joy Tab Manual de usuario

Alcatel

Alcatel OneToucy Pop7 Manual de usuario

Alcatel

Alcatel onetouch pixi 7 Manual de usuario

Alcatel

Alcatel A30 FIERCE Guía

Alcatel

Alcatel 1T7 4G Manual de usuario

Alcatel

Alcatel ONETOUCH PIXI 7 I 212 Manual de usuario

Alcatel

Alcatel Oone Touch T60 Manual de usuario

Alcatel

Alcatel One Touch Pop 10 P360X Manual de usuario

Alcatel

Alcatel JOY TAB 2 Manual de usuario

Alcatel

Alcatel One Touch T10 Manual de usuario

Manuales populares de Tableta de otras marcas

Laser

Laser MID-1060 Guía del usuario

MUNBYN

MUNBYN IRT09J Guía de inicio rápido

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz Manual de usuario

Dell

Dell Latitude ST Manual del propietario

Lenovo

Lenovo IdeaTab S6000L Manual del propietario

Venturer

Venturer WT9L11 Manual de usuario

EDUGEAR

EDUGEAR UnoBook Manual de usuario

Philips

Philips PI3210G/58 Manual de usuario

ADLINK Technology

ADLINK Technology IMT-BT Manual de usuario

TwinMOS

TwinMOS TwinTAB-T102D1 Manual de usuario

Archos

Archos 9.7 xenon Manual de usuario

Getac

Getac E100 Manual de usuario

HANNspree

HANNspree HANNspad SN70T3 Manual de usuario

Philips

Philips PI3105W2/55 Manual de usuario

LG LG-V935 Manual de usuario

Zeki

Zeki TBDB763B Manual de usuario

Ricoh

Ricoh eQuill Manual de usuario

DT Research

DT Research DT365CT Instrucciones de montaje
