AKX AKX-CH7 Manual de usuario
REVISION DATE
20150123
DOCUMENT NUMBER
NOTICE The manufacturer will accept no responsability for any electrical
damage resulting from improper installation of this product, be that either
damage to the vehicle itself or to the installed device. This device must be in-
stalled by a certified technician. Please review the Installation Guide carefully
before beginning any work.
BEFORE INSTALLATION
1- Connect module to computer
2- Login to Weblink account
3- Flash firmware to module (module is not preloaded with firmware)
4- Use accessories accordingly (accessories are sold separately)
U.S. Patent No. 8,856,780
INSTALL GUIDE
AKXCHRSCH8AKXCH7EN
HARDWARE
AKXCH7/AKXCH74BAM/AKXCH72WSS
ACCESSORIES
ADSUSB REQUIRED
COMPATIBLE RFKIT OPTIONAL
DIRECTED SMARTSTART & ADSHRNRSSM01 OPTIONAL
FIRMWARE
AKXCHRSCH8AKXCH7
www.autokinetix.comAutomotive Data Solutions Inc. © 2015
20226
U.S. Patent No. 8,856,780
VEHICLE LIST - 1 OF 1
MAKE
MODEL
YEAR
INSTALL TYPE
FEATURES
DATA IMMOBILIZER BYPASS
3X LOCK START/STANDALONE MOD.
DOOR LOCK
DOOR UNLOCK
ARM OEM ALARM
DISARM OEM ALARM
TRUNK/HATCH RELEASE
DOOR STATUS OUTPUT
TRUNK STATUS OUTPUT
BRAKE PEDAL STATUS OUTPUT
TACHOMETER OUTPUT
SECURE TAKEOVER
GLOW PLUGS STATUS
RAP SHUTDOWN CTRL
DODGE
Dart STD key (Tip-Start) AT 13-14 1 • • • • • • • • • • • •
RAM
1500 STD key (Tip-Start) AT 13-15 2 • • • • • • • • • • •
1500 Diesel STD key (Tip-Start) AT 14-15 2 • • • • • • • • • • • •
2500 / 3500 STD key (Tip-Start) AT 13-15 2 • • • • • • • • • • •
2500 / 3500 Diesel STD key (Tip-Start) AT 14-15 2 • • • • • • • • • • • •
NOTE
I WARNING: All vehicle doors must be
closed and locked prior to remote start
sequence.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH8AKXCH7EN
PAGE 2 OF 20
• 20150123
DOC.: #20226
U.S. Patent No. 8,856,780
BOX CONTENTS - 1 OF 1
VS2VS2
VS1VS1
MS1MS1
MS2MS2
3
6
4
1
2
5
C
B
A
F
G
E
D
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
7
9
3
10
8
11
12
6
4
1
2
5
2
1
3
7
9
3
10
8
6
4
12
5
2
1
3
4
2
1
3
4
BOX CONTENTS
T-HARNESS 1
AFTERMARKET HOOD SWITCH AND CABLE
WARNING STICKER
10 PIN CONNECTOR
12 PIN CONNECTOR
BLUE
PROGRAMMING
BUTTON
LED 2
LED 1
MODULE
BLACK
BLACK
BLACK
RF PORT/
WEBLINK PORT
BLACK
BLUE
TELEMATIC
PORT
WHITE
WEBLINK CABLE (required accessory sold separately)
WEBLINK CABLE
COMPUTER
USB PORT
4 PIN BLACK CABLE
MODULE
WEBLINK PORT
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH8AKXCH7EN
PAGE 3 OF 20
• 20150123
DOC.: #20226
U.S. Patent No. 8,856,780
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH8AKXCH7EN
PAGE 4 OF 20
• 20150123
COMPATIBLE ACCESSORIES - 1 OF 1
RF KIT
RF KIT (Visit our website to see if this accessory is included with your product)
ANTENNA
FLASH RF DECODER
BEFORE INSTALLATION
RF DECODERBLUE CABLE BLACK CABLE
(NC) RED
(NC) BLACK
BLACK
BLUE
MODULE
RF PORT
TELEMATIC KIT (accessories sold separately)
(NC)
(NC)
(NC)
DIRECTED SMARTSTART
ADS-HRN(RS)-SM01
MODULE
TELEMATIC PORT
DOC.: #20226
U.S. Patent No. 8,856,780
TYPE 1 - WIRE CHART - 1 OF 1
MAKE
MODEL
YEAR
WIRE
DESCRIPTION
CONNECTOR
NAME
CONNECTOR
COLOR
CONNECTOR
TYPE
POSITION
WIRE
COLOR
POLARITY
MODULE
LOCATION
COMPONENT
LOCATOR
DODGE
Dart
STD key
AT
13-14
CanH ~ Black 16 pin 06 Gray/White (DATA) OBDII connector ~
CanL ~ Black 16 pin 14 Yellow (DATA) OBDII connector ~
Parking Light ~ Black 06 pin 03 White/Brown (MUX) Parking light switch A
Rap Shutdown ~ ~ ~ ~ Purple (-) Driver kick panel harness B
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH8AKXCH7EN
PAGE 5 OF 20
• 20150123
DOC.: #20226
U.S. Patent No. 8,856,780
MS1MS1
MS2MS2
A
B
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
3
6
4
1
2
5
C
7
9
3
10
8
11
12
6
4
1
2
5
OBDII
C
10 11 12 13 14 15 16
1234567 8
9
VS2VS2
VS1VS1
A1
A2
B
12
3456
D
7
9
3
10
8
6
4
1
2
5
C
B
A
F
G
E
D
CANL - 14
PARKING LIGHT (MUX) - 03
RAP SHUTDOWN (-)
HORN (-)
CANH - 06
02 GRAY - RAP SHUTDOWN (-) OUTPUT
TYPE 1 - WIRING DIAGRAM - 1 OF 1
OBDII CONNECTOR
PARKING LIGHT SWITCHPARKING LIGHT SWITCH
MODULE
11 GRAY/GREEN - HORN (-) OUTPUT
OPTIONAL
BROWN/RED
BROWN/YELLOW
WHITE/BLACK (NC)
WHITE/BROWN
WHITE/RED (NC)
WHITE (NC)
DRIVER KICK PANEL
HARNESS
BLACK
IGNITION CONNECTOR
IGNITION HARNESS
IGNITION NODE
AFTERMARKET HOOD SWITCH (-)
04 GRAY/WHITE - HOOD STATUS (-) INPUT
WITHOUT OEM HOOD SWITCH:
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
TELEMATIC PORT
RF PORT/WEBLINK PORT
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH8AKXCH7EN
PAGE 6 OF 20
• 20150123
DOC.: #20226
U.S. Patent No. 8,856,780
TYPE 2 - WIRE CHART - 1 OF 1
MAKE
MODEL
YEAR
WIRE
DESCRIPTION
CONNECTOR
NAME
CONNECTOR
COLOR
CONNECTOR
TYPE
POSITION
WIRE
COLOR
POLARITY
MODULE
LOCATION
COMPONENT
LOCATOR
RAM
1500 /
1500 Diesel
STD key
AT
13-15
CanH D7405A Black 16 pin 06 Gray/White (DATA) OBDII connector ~
CanL D7405A Black 16 pin 14 Yellow (DATA) OBDII connector ~
Parking Light D2242A Black 10 pin 01 White/Brown (MUX) Parking light switch A
Rap Shutdown ~ ~ ~ ~ Purple (-) Driver kick panel harness B
2500 /
2500 Diesel /
3500 /
3500 Diesel
13-15
CanH D7405A Black 16 pin 06 Gray/White (DATA) OBDII connector ~
CanL D7405A Black 16 pin 14 Yellow (DATA) OBDII connector ~
Parking Light D2242A Black 10 pin 01 White/Brown (MUX) Parking light switch A
Rap Shutdown ~ ~ ~ ~ Purple (-) Driver kick panel harness B
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH8AKXCH7EN
PAGE 7 OF 20
• 20150123
DOC.: #20226
U.S. Patent No. 8,856,780
MS1MS1
MS2MS2
A
B
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
3
6
4
1
2
5
C
7
9
3
10
8
11
12
6
4
1
2
5
OBDII
C
10 11 12 13 14 15 16
1234567 8
9
VS2VS2
VS1VS1
A1
A2
12345
6 7 8 9 10
B
D
7
9
3
10
8
6
4
1
2
5
C
B
A
F
G
E
D
CANL - 14
PARKING LIGHT (MUX) - 01
RAP SHUTDOWN (-)
HORN (-)
CANH - 06
02 GRAY - RAP SHUTDOWN (-) OUTPUT
TYPE 2 - WIRING DIAGRAM - 1 OF 1
OBDII CONNECTOR
PARKING LIGHT SWITCHPARKING LIGHT SWITCH
MODULE
11 GRAY/GREEN - HORN (-) OUTPUT
OPTIONAL
BROWN/RED
BROWN/YELLOW
WHITE/BLACK (NC)
WHITE/BROWN
WHITE/RED (NC)
WHITE (NC)
BLACK
DRIVER KICK PANEL
HARNESS
IGNITION CONNECTOR
IGNITION HARNESS
IGNITION NODE
AFTERMARKET HOOD SWITCH (-)
04 GRAY/WHITE - HOOD STATUS (-) INPUT
WITHOUT OEM HOOD SWITCH:
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
TELEMATIC PORT
RF PORT/WEBLINK PORT
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH8AKXCH7EN
PAGE 8 OF 20
• 20150123
DOC.: #20226
U.S. Patent No. 8,856,780
01
02
03
04
OFF
ACC ON
START
05
06
OFF
ACC ON
START
07
OFF
ACC ON
START
08
OFF
ACC ON
START
09
OFF
ACC ON
START
10
11
OFF
ACC ON
START
12
13
14
15
OFF
ACC ON
START
16
17
OFF
ACC ON
START
18
OFF
ACC ON
START
MODULE PROGRAMMING PROCEDURE - 1 OF 2
Close driver door. Re-open driver door to wake
up data bus.
Press Unlock on OEM remote. If the vehicle is
not equipped with an OEM remote, press the
module programming button.
Wait, LED will flash GREEN once [1x]. If LED
does not flash GREEN, press Unlock on OEM
remote again.
Turn key to ON position.
Wait, LED will turn solid RED.
Turn key to OFF position.
Remove key.
Insert key into ignition.
Turn key to ON position.
Wait, LED will flash GREEN.
Turn key to OFF position.
WARNING: Disconnect power last. Disconnect
module from vehicle.
Connect module to computer and proceed
with extended programming.
WARNING: Do not press module programming
button. Connect power first. Connect module
to vehicle.
Turn key to ON position.
Wait, LED will turn solid GREEN for 2 seconds.
Turn key to OFF position.
Turn key to START position.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH8AKXCH7EN
PAGE 9 OF 20
• 20150123
DOC.: #20226
U.S. Patent No. 8,856,780
19
OFF
ACC ON
START
20
MODULE PROGRAMMING PROCEDURE - 2 OF 2
Turn key to OFF position.
Module Programming Procedure completed.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH8AKXCH7EN
PAGE 10 OF 20
• 20150123
DOC.: #20226
