Akai AR130WE Manual de usuario
Klokradio
ALD1915H
GB 2
DA 32
NL 12
FR 22
User manual
Gebruiksaanwijzing
Manuel de l’utilisateur
Brugsanvisning
AR130WE
Table of contents
Copyright notice
Design and specications are subject to change without notice.
1. Safety........................................................................... 3
1.1 Intended use ....................................................................3
1.2 Labels in this manual .......................................................3
1.3 General safety instructions ..............................................3
2. Preparations for use................................................... 4
2.1 Unpacking ........................................................................4
2.2 Package contents ............................................................4
3. Installation................................................................... 4
3.1 Connecting to the mains ..................................................5
3.2 Battery backup .................................................................5
4. Functions..................................................................... 6
5. Operation..................................................................... 7
5.1 Clock functions.................................................................7
5.2 Radio functions ................................................................8
5.3 Setting the SLEEP function ..............................................8
5.4 Alarm function ..................................................................8
6. Cleaning and maintenance ........................................ 9
7. Troubleshooting.......................................................... 9
8. Technical data........................................................... 10
9. Disposal of used electrical
and electronic equipment ........................................ 11
3
AR130WE
Safety1.
Intended use1.1
The Clockradio wakes you up with music from radio broadcast. The clock
function includes an alarm and sleep program. Read the manual carefully
before the rst use.
Labels in this manual1.2
!WARNING
A warning means that injury or death is possible if the instructions
are not obeyed.
!CAUTION
A caution means that damage to the equipment is possible.
i
A note gives additional information, e.g. for a procedure.
General safety instructions1.3
!WARNING
Do not put force on the appliance. The appliance can fall and can
cause serious injury.
!CAUTION
Do not spill any liquid on the appliance.
!WARNING
Do not insert any objects in the ventilation holes.
!CAUTION
Do not block the ventilation holes.
i This appliance is double insulated; therefore no earth wire is required.
Always check that the mains voltage corresponds to the voltage on
the rating plate.
4
Preparations for use2.
Unpacking2.1
● Unpack the appliance carefully.
● Check the package contents as described below. If any item is missing,
please contact your reseller.
● Remove the labels from the front panel carefully if present.
i We recommend that you retain the original carton and packing
materials in case it ever becomes necessary to return your product
for service. This is the only way to safely protect the product
against damage in transit. If you do dispose of the carton and the
packing materials, please remember to recycle with due care to the
environment.
Package contents2.2
The following items are included in the received package:
1 Clockradio
1 AC/DC adaptor + cable
1 Operator manual
i
If any item is missing, please contact your reseller.
Installation3.
● Put the appliance on a horizontal at surface.
● Connect the appliance to the mains.
Read the paragraph "Connecting to the mains".
!
CAUTION
● Do not put the appliance near a heat source.
● Do not expose the appliance to direct sunlight.
5
AR130WE
i This appliance is equipped with rubber feet to prevent it from moving.
The feet are made from non-migrating material specially formulated
to avoid leaving any marks or stains on furniture. However, certain
types of furniture polishes, wood preservatives or cleaning sprays
cause the rubber to soften and leave marks or a residue on the
furniture, and potentially risk the surface to become damaged.
To prevent damage to wooden surfaces, we recommend that you
apply self-adhesive pads to the bottom of the rubber feet before
installation.
Connecting to the mains3.1
● Connect the adaptor plug on the adaptor cable to the AC IN 7.5 V connection.
● Connect the mains plug to a wall socket.
Battery backup3.2
In case of a power failure, the appliance relies on battery backup. For this
purpose, the appliance uses one battery (9 V). The appliance remembers
the time, but does not display it.
i
● Batteries are not included with this appliance.
● Batteries are not necessary for normal operation.
Installing the battery
● Remove the battery cover.
● Insert the battery matching the (+) and (-) polarity markings.
● Re-install the battery cover.
!CAUTION
Incorrect installation can cause battery leakage and corrosion
which will damage the appliance. Corrosion, oxidation, battery
leakage and any other gradually acidic defect of this nature will
invalidate the guarantee.
6
Functions4.
4
5
2
15
1
3
6
7
9
10
11
8
12
14
13
1 AUTO-OFF-ON switch
2 TUNING dial
3 VOLUME dial
4 Battery compartment
5 FM antenna
6 AC IN 7.5 V connection
7 AUX connection
8 SNOOZE button
9 MIN button
10 HOUR button
11 AM/FM switch
12 Display
13 SLEEP button
14 TIME button
15 ALARM/OFF button
7
AR130WE
Operation5.
● To switch on the appliance, slide the AUTO-OFF-ON switch (1) to the ON
position. To switch off the appliance, slide the AUTO-OFF-ON switch (1) to
the OFF position.
● To adjust the volume level, turn the VOLUME dial (3) to the required
position.
Audio connections (input)
The AUX connection allows you to receive audio signal from a connected
MP3 or CD player. Suitable cables can be purchased at your reseller.
● To connect an external audio device, insert the cable plug in the AUX
receptacle (7).
● To switch on the appliance, slide the AUTO-OFF-ON switch (1) to the AUTO
position.
● Adjust volume to the desired level.
Clock functions5.1
Setting the current time
● Press and hold the TIME button (11).
● Press the HOUR button (10) or the MIN button (9) until the desired time is
set.
Setting the alarm time
● Press and hold the ALARM/OFF button (15).
● Press the HOUR button (10) or the MIN button (9) until the desired time is
set.
i During a power failure, or when unplugging the appliance, the time
settings are lost, unless backup batteries are installed.
8
Radio functions5.2
● To select the radio band, slide the AM/FM switch (11) to the AM or FM position.
● To select a frequency or radio station, turn the TUNING dial (2) until the
required frequency is set.
i To improve the reception of the FM frequency, extend the aerial
antenna. To improve the reception of the AM frequency, turn the
appliance.
Setting the SLEEP function5.3
● Slide the AUTO-OFF-ON switch (1) to the AUTO position.
● Select the desired radio station.
● Press the SLEEP button (13). The sleep time (59 min) ashes on the display.
● Press the HOUR button (10) or the MIN button (9) until the desired time is
set (1:59, 1:58, 1:57 .. 0:01).
The appliance stops playing after the chosen time has elapsed.
● To cancel the SLEEP function, press the SNOOZE button (8).
Alarm function5.4
This function is available in radio, AUX and tone mode.
● For radio alarm:
Switch on the appliance.•
Select the desired radio station.•
Adjust the volume.•
● For AUX alarm:
Connect the audio source to the appliance. Switch on the audio source.•
Switch on the appliance.•
Adjust the volume.•
● For tone alarm:
Turn the VOLUME dial (3) to the OFF position. The dial is locked in •
position when you hear a click.
● To activate the alarm, set the AUTO-OFF-ON switch (1) to the AUTO
position.
● To cancel the alarm, set the AUTO-OFF-ON switch (1) to the OFF position.
9
AR130WE
Snooze alarm
The default snooze time is: 9 minutes.
● To snooze the alarm, press the SNOOZE button (8) once. The alarm
sounds again after the snooze time has elapsed.
● To stop the alarm, press the ALARM/OFF button (15). The alarm is
automatically set for the next day.
Cleaning and maintenance6.
!WARNING
Before performing any cleaning or maintenance, switch off and
unplug the appliance.
● Clean the outside of the appliance with a soft cloth. When the appliance is
very dirty, dampen the cloth slightly with water and a neutral solution.
Troubleshooting7.
Trouble Action
No display Switch on the appliance.
Connect the appliance properly.
Select the correct function with the ON/OFF switch (1).
No sound Connect the appliance properly.
Adjust the volume.
Adjust the tuning control.
10
Technical data8.
Parameter Value
Voltage 230 VAC ~ 50 Hz
Backup voltage 9 V
Power consumption 2.040 W
Standby power consumption 1.039 W
Max power output 0.5 W
Radio bands FM
Dimensions (W x H x D) 153 x 114 x 76 mm
Weight 260 g
Frequency range
Parameter Value
AM radio 540 - 1600 kHz
FM radio 88 - 108 mHz
