Air Design SILVERADO 2014 + Manual de usuario
DATE: 26.05.2017 PG.
INSTALLATION MANUAL
1
GM - SILVERADO 2014 +
www.airdesignusa.com
1 pc
ITEM DESCRIPTION
AVHB TAPE
BPUSH PIN WURTH 46
C
DBUTTON HEAD ALLEN
STAINLESS SCREW M4 X 16
EWASHER 3/16
F
GGREASE PENCIL
AUTOMOTIVE ADHESION
PROMOTER
4 pcs
7 pcs
I
1 pc
4 pcs
4 pcs
ECO DOME
1 pc
1 set
Included in
the parts
DRL LED OSRAM PX-5
STAINLESS LOCK NUT M4
POLYURETHANE ADHESIVE
H
J
DRAWING AMOUNT
1 pc
PART # : 1107CNEUGM24A03
FRONT BUMPER GUARD SILVERADO 2014 +
TOOLS
CHECK LIST
*
*
*
*
We recommend 2 persons for installation
READ CAREFULLY BEFORE
INSTALLATION
*Already installed in the part
1”
1/4”
1/2”
DRIVE SLOWLY
25 mph max
DO NOT
WASH CAR
24 hrs
387
K
L
M
1 pc
1 pc
1 pc
FUSE TAPS
FUSE
INSULATED FEMALE CONNECTOR
In case the vehicle counts with
proximity sensors relocate them following
the instructions, otherwise continue with
the rest of the manual.
UNINSTALL SENSOR
IF THE VEHICLE HAS SENSORS FOLLOW STEPS 2 - 7
IF IT DOES NOT HAVE SENSORS GO TO STEP 8 .
DRL ELECTRICAL INSTALLATION DIAGRAM
HEAD LIGHTS
RED
ORANGE
GREEN
GREEN + YELLOW
CONTROL
BOX
BLACK
FUSE
FUSE BOX
- ORANGE: CABLE CONNECTED TO IGNITION
(+) POSITIVE(+) FEED ON FUSE BOX OR WIRE
- BLACK: BATTERY NEGATIVE(-)
- RED: BATTERY POSITIVE(+)
- GREEN: HEAD LIGHTS (+)
LOCATE FUSE SLOT WITH
(+) POSITIVE FEED WHEN
IGNITION IS ON.
TAP A CIRCUIT
FUSE
FUSE TAP
FEMALE
CONNECTOR
ORANGE
CABLE
APPLYPRESSURE
TO FEMALE
CONNECTOR
4
To connect green wire remove
right mud guard to access the
head light harness.
To reinstall mud guard use 4
push pins included.
HEAD LIGHT
DRIVER´S SIDE
PLUG
YELLOW
GREEN
CONTROL
BOX
If the DRL’s did not
turn on inmediatly
when the ignition is
on, please wait for a
few minutes until the
computer resets and
then the lights will
light up.
DATE: 26.05.2017 PG.
INSTALLATION MANUAL
2
GM - SILVERADO 2014 +
México 01 800 623 79 52 / USA 844 280 2775
DRILL FILING
DRILL
DATE: 26.05.2017 PG.
INSTALLATION MANUAL
3
GM - SILVERADO 2014 +
www.airdesignusa.com
1”
INNER VIEW
INNER VIEW INNER VIEW
INSTALL
SECURE 8
1/2”
1”
1”
REMOVE
MOUNT ON BUMPER
FIRST CLEAN ALL OVER THE APPLICATION AREA WITH ACETONE
DATE: 26.05.2017 PG.
INSTALLATION MANUAL
4
GM - SILVERADO 2014 +
México 01 800 623 79 52 / USA 844 280 2775
9
HASH MARKS
DRAW CENTER HASH MARK WITH GREASE PENCIL ON
FRONT BUMPER AND SHEET METAL, THIS WILL ENSURE
FRONT BUMPER WILL BE CENTERED TO GREASE PENCIL
OUTLINE.
LINER
LINER
Hold the liner out
PEEL OFF
WARM SURFACES WITH HEAT GUN IF SURFACE
TEMPERATURE IS TOO COLD.
“CLICK”
“CLICK”
APPLY ADHESIVE
DATE: 26.05.2017 PG.
INSTALLATION MANUAL
5
GM - SILVERADO 2014 +
www.airdesignusa.com
INNER VIEW
1/4”
USE ACETONE TO THROWLY
CLEAN ADHESIVE CHANNEL
PASS DRL CABLE
PASS DRL
CABLES
THROUGH
IF THE VEHICLE HAS SENSORS CONNECT THEM
PLACE
DATE: 26.05.2017 PG.
INSTALLATION MANUAL
6
GM - SILVERADO 2014 +
México 01 800 623 79 52 / USA 844 280 2775
8
9
A full surface contact between tape and
substrate is decisive for good adhesion
performance. Contact is achieved by applying
pressure. In practice a pressure between
40 and 50 N/cm² is usually needed and an
application temperature between 25 and 45
°C or 77 and 113 °F is also necessary. During
application, add-on parts and tapes must have
the similar temperature.
CONNECT
PLACE PUSH PINS
INSTALLED PART
CONNECT CABLES TO BATTERY
SECURE CABLES
CLEAN OFF GREASE PENCIL MARK
DRILL
DATE: 26.05.2017 PG.
INSTALLATION MANUAL
7
GM - SILVERADO 2014 +
www.airdesignusa.com
1/4”
PG.
INSTALLATION MANUAL
1
GM - SILVERADO 2014
www.airdesignusa.com
DATE: 08.01.2016
TOOLS
PART # : 1124NNEJGM24D04
DOOR ROCKER PANEL SET SILVERADO 2014 CREW CABCREW
CHECK LIST
*
ITEM DESCRIPTION
AVHB TAPE Included in
the parts
BGREASE PENCIL
C1 pc
ADHESION PROMOTER
DECO DOME
AMOUNTDRAWING
1 pc
*Already installed in the part
1 pc
We recommend 2 persons for installation
READ CAREFULLY BEFORE
INSTALLATION
DRIVE SLOWLY
25 mph max
DO NOT
WASH CAR
24 hrs
REAR
FRONT
1/8’’ 1/8’’
WASH WITH WATER, DETERGENT AND
SOFT CLOTH OR SPONGE FRONT & REAR ROCKER PANEL
Keep the indicated separation between
the panels and the edge of the doors as
shown in the picture.
FACTORY DOOR MOLDING HAVE
TO BE REMOVED BEFORE
INSTALLING DOOR ROCKER PANEL
PG.
INSTALLATION MANUAL
2
GM - SILVERADO 2014
DATE: 08.01.2016 México 01 800 623 79 52 / USA 844 280 2775
LINER
PEEL OFF
LINER
Hold the liner out
A full surface contact between tape
and substrate is decisive for good
adhesion performance. Contact is
achieved by applying pressure. In
practice a pressure between 40 and
50 N/cm² is usually needed and an
application temperature between 25
and 45 °C or 77 and 113 °F is also
necessary. During application, add-
on parts and tapes must have the
similar temperature.
PLACE
FIRST CLEAN ALL OVER THE APPLICATION AREA WITH ACETONE
WARM SURFACES WITH HEAT GUN IF SURFACE
TEMPERATURE IS TOO COLD.
DRAW CENTER HASH MARK WITH GREASE PENCIL
ON ROCKER PANEL AND SHEET METAL, THIS WILL
ENSURE ROCKER PANEL WILL BE CENTERED TO
GREASE PENCIL OUTLINE.
HASH MARKS
PG.
INSTALLATION MANUAL
3
GM - SILVERADO 2014
www.airdesignusa.com
DATE: 08.01.2016
