AGPTEK
User Manual
Model: W20
Kids Smart Watch
Thank you for purchasing this product. Please read this user manual carefully before use and
keep this instruction for future reference. If you have any problem about this product, please
Package Contents
Watch*1, User Manual*1, USB Cable*1, Transparent Film*1, 8GB Memory Card (Already
installed on the watch)
Product Diagram
Upward-facing Camera
Forward-facing Camera
Mic
Home Button
Reset Button
Micro SD
Card Slot
Micro USB Port
Charging
Remove the rubber protective cover on the USB charging port, and then connect the
Micro-USB end of USB charging cable to the watch and the other end to the USB charger.
*Charging Voltage≤5V-1A.
* After the charger is plugged to the power socket, the power icon at the top right of the screen
will start scrolling, which indicates that it is in charging mode. The power icon will stop
scrolling with a full battery icon when fully charged.
* Charging and data transmission options will appear when it is connected to computer for
charging. Select the charging option.
Support Micro SD Card
Lift up the rubber cover of the Micro USB interface on the left side of the watch, and you can
see that there is a slot for inserting the SD card. The 8GB memory card attached has been
installed on the watch before delivery.
Basic Operation
Power on: Long press the home button to turn on the watch.
Power off: When on Clock Interface, long press the home button to turn off the watch.
Light up screen/Return: Short press the home button
* If the device fails to turn on, this could be caused by low battery. Please try again after
recharging the device for 20 minutes.
Full Touch Screen: 1.54 Inch full touch screen, swipe left and right on the interface to turn
pages. Tap on the function icon to enter the function.
When on Clock Interface, swipe down the screen, tab the trumpet icon, and it will switch
to the mute mode.
Bright Screen Time: The bright screen time can be set in Settings, and there are 5 choices:
15s/30s/45s/60s/constant. When there is no operation, the screen will be dark, and press the
home button to brighten it.
Clock Display
When the home button is pressed, the clock will be displayed. Tap the center of the screen to
switch the clock interfaces between analog and digital. Swipe left or right on the screen to see
more clock interfaces. When the watch is on clock interface, press the home button to go
to the home menu for selecting different function.
The first three: Analog clock interfaces
The last three: Digital clock interfaces
Function Introduction
1. Camera
Tap to take a photo.
Tap to view the photos.
Tap to switch the upward-facing camera and forward-facing camera.
2. Video Recording
Tap to begin video recording and tap it again to end video. The video will be automatically
saved when completed.
Tap to view the videos.
Tap to switch the upward-facing camera and forward-facing camera.
3. Pictures
All image files can be viewed here. Tap the arrow icon on the screen to move to the previous or
next image. Tap on the screen to delete.
4. Videos
You can browse all video files here. Tap on the screen to move to the previous or next
video. Press and hold to fast reverse or fast forward. Tap on the screen to play the
video.
5. Voice Recorder
Tap to start voice recording.
Tap to save the recording.
Tap to play the recording.
Use the arrows to select previous or next recording.
6. Music
(Kindly Remind: Music Player will be workable after inserting SD card including Music)
To upload music to the watch, copy any MP3 music files to the watch folder "My Music" into the
SD Card. Then insert the SD Card into the watch.
Tap to begin playing.
Tap to stop music.
Tap to increase the volume.
Tap to decrease the volume.
Tap to move to the previous or next song. Press and hold to fast reverse or fast
forward.
Tap at the bottom of the screen to return to the menu.
How to operate the music accessory function:
Tap the bottom left icon to enter the music list. "Options":
1) Play: Start playing music.
2) Details: Check the detailed information of songs stored in the built-in memory card.
3) Refresh List: Playlist update. If not displayed in the music list after importing songs, tap
here.
4) Settings:
A - Priority list: Choose watch or memory card.
B - Create list automatically:
On: If you select “Watch'' in A item, the songs in the main unit will be automatically played as a
list. If you select "Memory card", the songs in "My Music" are automatically played as a list.
Off: Create your own "My Music" list (If you select OFF, tap "Save" at the bottom left to enter the
list management screen. Then tap "Options" to perform the following operations: ①Play: Start
play music. ②Details: the detailed information of song. ③Add: add song to list. ④Remove:
Remove this song. ⑤Remove All.
C - Repeat. Choose On or Off.
D - Shuffle. Choose On or Off.
E - Background Play. Choose On or Off.
7. Games
There are 5 built-in games on the smart watch. Swipe the screen to select, then tap one to play.
2048:
Swipe up, down, left or right to move the tiles across the board. The tiles will slide
in the swipe direction. Meanwhile, a new tile will emerge randomlyin the board.
When the tiles with the same number meet, they will merge into one tile.
Bee War:
Tap the screen left or right to move the fighter to shoot. Purple enemies need to
be hit twice. Score as many point as you can! You have a total of three
opportunities.
Ultimate Racing:
Game Instruction: Hold the car to move left and right to switch lanes. The car in
front may drop gold coins. Eat as many gold coins as possible. To avoid collision,
you have only one chance.
Basketball Shoot Master:
Game Instruction: Press the basketball to shoot. When the backboard is going to
move to the middle, control to shot.
Pinball Hit Bricks:
Game Instruction: Destroy all bricks to progress to the next level. White bricks
give a special 3-ball bonus. Blue bricks need to be hit 2 times. Score as many
points as you can !
