E6000C Mini-OTDR User’s Guide

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2E6000C Mini-OTDR User’s Guide, E0302

Notices

Technologies Deutschland GmbH.

All rights reser ed.

No part of this manual may be

reproduced in any form or by any

means (including electronic

storage and retrie al or

translation into a foreign

language) without prior agreement

and written consent from Agilent

Technologies, Inc. as go erned by

United States and international

Warranty

The material contained in this

document is subject to change

without notice. Agilent

Technologies makes no warranty

of any kind with regard to this

material, including, but not limited

to, the implied warranties of

merchantability and fitness for a

particular purpose. Agilent

Technologies shall not be liable for

errors contained herein or for

incidental or consequential

damages in connection with the

furnishing, performance, or use of

this material.

The battery is a consumable part

and is not subject to the E6000C

warranty.

Edition/Print Date

All Editions and Updates of this

manual and their creation dates

are listed below.

E6000-91031: E0302

First Edition ….......…… March 2002

Pre ious ersions ........ April 2001,

May 2001, No ember 2001

Assistance

Product maintenance agreements

and other customer assistance

agreements are a ailable for

Agilent Technologies products.

For any assistance, contact your

nearest Agilent Technologies Sales

and Ser ice Office (see “Service

and Support” on page 12).

ISO 9001 Certification

Produced to ISO 9001

international quality system

standard as part of Agilent

Technologies’ objecti e of

continually increasing customer

satisfaction through impro ed

process control.

Bellcore Certification of

Excellence

Agilent Technologies is officially

designated Bellcore Certification

Eligible, and is awarded Bellcore’s

Certification of Excellence for its

OTDR Data Format.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Safety Summary

E6000C Mini-OTDR User’s Guide, E0302 3

Safety Summary

The following general safety precautions must be

obser ed during all phases of operation of this

instrument. Failure to comply with these precautions or

with specific warnings elsewhere in this manual iolates

safety standards of design, manufacture, and intended

use of the instrument. Agilent Technologies assumes no

liability for the customer’s failure to comply with these

requirements.

GENERAL

This product is a Safety Class 3 instrument (pro ided

with a protecti e earth terminal). The protecti e features

of this product may be impaired if it is used in a manner

not specified in the operation instructions.

All Light Emitting Diodes (LEDs) used in this product are

Class 1 LEDs as per IEC 60825-1.

ENVIRONMENTAL CONDITIONS

This instrument (without AC Adapter) is intended for

outdoor use in an installation category II, pollution degree

2 en ironment. It is designed to operate at a maximum

relati e humidity of 95% and at altitudes of up to 2000

meters. Refer to the specifications tables and

“Temperature and Humidity” on page 179 for the ac

mains oltage requirements and ambient operating

temperature range.

BEFORE APPLYING POWER

Verify that the product is set to match the a ailable line

oltage, the correct fuse is installed, and all safety

precautions are taken. Note the instrument’s external

markings described under Symbols.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Safety Summary

4E6000C Mini-OTDR User’s Guide, E0302

FUSES

Only fuses with the required rated current, oltage, and

specified type (normal blow, time delay, etc.) should be

used. Do not use repaired fuses or short-circuited fuse

holders. To do so could cause a shock or fire hazard.

DO NOT OPERATE IN AN EXPLOSIVE

ATMOSPHERE

Do not operate the instrument in the presence of

flammable gases or fumes.

DO NOT REMOVE THE INSTRUMENT COVER

Operating personnel must not remo e instrument co ers.

Component replacement and internal adjustments must

be made only by qualified ser ice personnel.

Instruments that appear damaged or defecti e should be

made inoperati e and secured against unintended

operation until they can be repaired by qualified ser ice

personnel.

WARNING The WARNING sign denotes a hazard. It calls attention to

a procedure, practice, or the like, which, if not correctly

performed or adhered to, could result in personal injury.

Do not proceed beyond a WARNING sign until the

indicated conditions are fully understood and met.

CAUTION The CAUTION sign denotes a hazard. It calls attention to

an operating procedure, or the like, which, if not correctly

performed or adhered to, could result in damage to or

destruction of part or all of the product. Do not proceed

beyond a CAUTION sign until the indicated conditions are

fully understood and met.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Safety Summary

E6000C Mini-OTDR User’s Guide, E0302 5

Symbols

Caution, refer to accompanying documents

Hazardous laser radiation

Electromagnetic interference (EMI)

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Safety Summary

6E6000C Mini-OTDR User’s Guide, E0302

Initial Laser Safety Information

E6001A E6003A E6003B

Laser Type FP-Laser

InGaAsP

FP-Laser

InGaAsP

FP-Laser

InGaAsP

Laser Class

According to IEC 825 (Eu-

rope)

3A 3A 3A

According to 21 CFR 1040.10

(Canada, Japan, USA)

111

Output Power (Pulse Max) 50 mW 50 mW 50 mW

Pulse Duration (Max) 10 µs 10 µs20µs

Pulse Energy (Max) 500 nWs 500 nWs 500 nWs

Output Power (CW) 500 µW 500 µW500µW

Beam Waist Diameter 9 µm9µm9µm

Numerical Aperture 0.1 0.1 0.1

Wavelength 1310

±25nm

1310/1550

±25nm

1310/1550

±25nm

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Safety Summary

E6000C Mini-OTDR User’s Guide, E0302 7

E6004A E6007A E6008B

1310 nm 1550 nm

Laser Type FP-Laser

InGaAsP

MQW-Laser

AlGaInP

FP-Laser

InGaAsP

FP-Laser

InGaAsP

Laser Class

According to IEC 825 (Eu-

rope)

3A 2 3A 3A

According to 21 CFR 1040.10

(Canada, Japan, USA)

12 11

Output Power (Pulse Max) 50 mW n/a 120 mW 200 mW

Pulse Duration (Max) 10 µsn/a 20µs20µs

Pulse Energy (Max) 500 nWs n/a 2.4 µWs 4.0 µWs

Output Power (CW) 500 µW 500 µW 500 µW 500 µW

Beam Waist Diameter 9 µm9µm9µm9µm

Numerical Aperture 0.1 0.1 0.1 0.1

Wavelength 1310/

1550

±25nm

635 ±10nm 1310

±25nm

1550

±25nm

E6012A

1550 nm 1625 nm

Laser Type FP-Laser

InGaAsP

FP-Laser

InGaAsP

Laser Class

According to IEC 825 (Europe) 3A 3A

According to 21 CFR 1040.10

(Canada, Japan, USA)

Output Power (Pulse Max) 200 mW 200 mW

Pulse Duration (Max) 20 µs20µs

Pulse Energy (Max) 4.0 µWs 4.0 µWs

Output Power (CW) 500 µW 500 µW

Beam Waist Diameter 9 µm9µm

Numerical Aperture 0.1 0.1

Wavelength 1550 ±25nm 1625 ±20nm

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Safety Summary

8E6000C Mini-OTDR User’s Guide, E0302

Safety Labels

The following laser safety warning labels are fixed on the

panel of the Mini-OTDR modules (that is, all modules

except the E6006A and E6007A submodules):

USA

E6005A / E6009A

1300 nm 850 nm

Laser Type FP-Laser In-

GaAsP

MOCVD

GaAlAs

Laser Class

According to IEC 825 (Europe) 3A 3A

According to 21 CFR 1040.10

(Canada, Japan, USA)

Output Power (Pulse Max) typ ≤ 30 ns 20 mW 40 mW

Output Power (Pulse Max) typ > 30 ns 10 mW 20 mW

Pulse Duration (Max) 10 µs 100 ns

Pulse Energy (Max) 200 nWs 4 nWs

Output Power (CW) 50 µW 20 µW

Beam Waist Diameter 50 µm 62.5 µm

Numerical Aperture 0.2 0.27

Wavelength 1300 ±25nm 850 ±25nm

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Safety Summary

E6000C Mini-OTDR User’s Guide, E0302 9

Non-USA

The following symbol is fixed to the panel of the Mini-

OTDR modules, next to the laser output:

A sheet of laser safety warnings is included with the laser

module. You must stick the labels in the local language

onto the outside of the instrument, in a position where

they are clearly isible to anyone using the instrument.

The following laser safety labels should be fixed to the

E6007A submodule:

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Equipo de prueba de Agilent Technologies

Agilent Technologies

Agilent Technologies 1000B Series Manual de usuario

Agilent Technologies

Agilent Technologies 85105A Option 50 Manual de instalación y operación

Agilent Technologies

Agilent Technologies N5341A Manual de usuario

Agilent Technologies

Agilent Technologies 54853A Manual de usuario

Agilent Technologies

Agilent Technologies Infiniium 90000 A Manual de usuario

Agilent Technologies

Agilent Technologies InfiniiVision 7000B Series Manual de usuario

Agilent Technologies

Agilent Technologies 54830 Series Manual de usuario

Agilent Technologies

Agilent Technologies Infiniium Manual de usuario

Agilent Technologies

Agilent Technologies InfiniiVision 6000 Series Manual de usuario

Agilent Technologies

Agilent Technologies HP 10070A Manual de usuario

Agilent Technologies

Agilent Technologies 3070 Series Instrucciones de funcionamiento

Agilent Technologies

Agilent Technologies InfiniiVision 3000 X-Series Manual

Agilent Technologies

Agilent Technologies InfiniiVision 3000 X- Series Guía de configuración

Agilent Technologies

Agilent Technologies DSO-X-2024A Manual de usuario

Agilent Technologies

Agilent Technologies InfiniiVision 4000 X-Series Manual de usuario

Agilent Technologies

Agilent Technologies 8935 Series Manual de usuario

Agilent Technologies

Agilent Technologies InfiniiVision 4000 X Series Manual de usuario

Agilent Technologies

Agilent Technologies aurora Duet Manual de usuario

Agilent Technologies

Agilent Technologies E6630A Manual de usuario

Agilent Technologies

Agilent Technologies N3280A Manual de usuario

Agilent Technologies

Agilent Technologies HP 83711A Manual de usuario

Agilent Technologies

Agilent Technologies 54835A Manual de usuario

Agilent Technologies

Agilent Technologies InfiniiVision 5000 Series Manual

Agilent Technologies

Agilent Technologies 11644A Series Manual

Manuales populares de Equipo de prueba de otras marcas

SMART

SMART KANAAD SBT XTREME 3G Series Manual de usuario

Vernier

Vernier Go Direct Voltage Manual de usuario

Lifeloc

Lifeloc R.A.D.A.R. Manual de usuario

Fluke

Fluke T5-600 Instrucciones de funcionamiento e instalación

Mercury

Mercury TSL01 Manual de usuario

MAHA

MAHA MBT Series Manual de usuario

Fuji Electric

Fuji Electric P-61 Manual de usuario

ETC

ETC SealerAtor Manual de usuario

Skyfine

Skyfine ETHYWAY V2 Manual de usuario

Appion

Appion G5 Twin Manual de usuario

PCB Piezotronics

PCB Piezotronics 8159-0112A Manual de usuario

BW Technologies

BW Technologies MicroDock II Manual de usuario

Sun Nuclear

Sun Nuclear 1027 Manual de usuario

Biomark

Biomark HPR LITE READER Manual de usuario

Hioki

Hioki 3169-20 Manual de usuario

Ashcroft

Ashcroft ATE-100 Manual de usuario

Rohde & Schwarz

Rohde & Schwarz RTA4000 Manual de usuario

Ritmix

Ritmix RAT-701 Manual de usuario
