PRODUCT MANUAL

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

INTRODUCTION 2

Product and Technology 2

Key Features 2

Typical Applications 2

Product overview image 2

Installation 3

Installation Information 3

Mounting Location 3

Mounting Location Considerations 3

Physical Installation 4

343 Mounting Bracket Kit 4

Step 1 – Mount bracket to the pole 4

Step 2 – Mount bracket to the radar 4

Step 3 – Mount radar to the pole 5

Electrical Installation 6

Connections 6

343 Power/RS422 Cable Assembly 6

Table of Contents

safer, greener, more eicient

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

Introduction

PRODUCT & TECHNOLOGY

KEY FEATURES

• Flow monitoring solution for multi-lane real-time data

• Traffic Profiling and Incident Detection

• Ten lane highway capability

• Enforcement grade radar & techniques

• Identifies, tracks & measures speed, length, lane/direction of individual targets

• Multi-level incident detection mode

• Non-intrusive loop replacement

• Mounts on existing infrastructure

• Simple to install, setup and configure using AGD Align

The AGD 343 Highways Monitoring Radar is an easy-to-

integrate traic flow monitoring solution that provides

real-time data on multi-lane highways. Designed for traic

profiling and incident detection, the 343 dramatically

enhances highways safety, capability and eiciency.

AGD’s 343 employs proven enforcement-grade radar &

measurement techniques to quantify speed, range and

length of passing vehicles. Detailed traic information

- such as, ‘is traic free-moving, slowing or starting-to-

queue?’ - is available in all weather conditions to inform

control rooms and allow instant decision making.

AGD radar can replace intrusive high-maintenance loops,

mounting on existing roadside poles or gantries where

it ‘looks’ across the road at 30 degrees. The additional

capability to operate at a ≥ 2-metre oset, while

maintaining a 6-metre plus mounting height, ensures

reliable operation in managed motorway scenarios and

ALR (All Lanes Running) schemes. The 343 has been

designed to cope with the many diiculties

facing international road network installations.

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

Introduction

TYPICAL APPLICATIONS

Multi-Lane Highways Monitoring Radar

Caption Caption

Flange Mounting

Points

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

PRODUCT OVERVIEW

Power/RS422 Cable

Connector Port

X4 Fixing Points

Introduction

safer, greener, more eicient

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

INSTALLATION INFORMATION

The radar is designed to be mounted to various structures such as a dedicated column, gantry or sign.

To install the radar, the following parts will be required:

To provide power and communication interfaces the following parts will assist in detector integration:

Installation

No. Part No Description Notes

1 343-500-000 AGD 343 Highways Monitoring Radar

2 MS-246 343 Mounting Bracket Kit

3 CA-310 343 Power/RS422 Cable Assembly

4 MK343-05 Camera Setup Tool (this is removed upon setup)

No. Part No Description Notes

5 MK343-01 343 Interface Enclosure

6 MK343-03 343 Interface Enclosure (c/w 24Vdc PSU)

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

MOUNTING LOCATION

The AGD 343 has been designed to be mounted on a variety of structures, where it looks across the carriageway

at 30 degrees to provide highly accurate traic data.

The detector must be mounted at a minimum height of 6m above the carriageway and at an angle of

30 degrees. The AGD align set-up tool assists in accurate set up of the angle.

Mounting Location Considerations

The detector has been designed to monitor traic in inter-urban environments while maintaining resilience to

externl factors, however, care must be taken when choosing a mounting location.

Avoid where possible:

• Installing the detector where it points toward large reflective surfaces (such as signs, barriers and metal

retaining walls)

Installation

Offset Recommended Mounting Height Acceptable Mounting Height

2m 6m 6m

Oset: 2 metres

Height: 6 metres

Setup: AGD Align Visual

& Histogram

2 m

30º

CONFIGURATION:

6 m

Oset: 2 metres

Height: 6 metres

Setup: AGD Align Visual

& Histogram

2 m

30º

CONFIGURATION:

6 m

DIRECTION OF TRAVEL

Pole

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

PHYSICAL INSTALLATION

343 Mounting Bracket Kit

The AGD 343 bracket mounting kit (part number MS-246) consists of two brackets and all the required fixing

hardware.

BR-270 is the component of the bracket kit that BR-271 is the component of the bracket kit that

fits to the structure you are mounting to. fits to the rear of the radar.

Fixing hardware consists of:

7no. M5 x 10mm Torx T20 A2 Stainless Screws

7no. M5 External Shakeproof A2 Stainless Washers

Step 1 – Mount bracket to the pole

Installation

Attach BR-270 to the structure you are mounting too

using mounting straps (AGD recommends stainless

steel sign banding ½” thick).

The position of the bracket should be parallel to the

carriageway as in the image below, le. Do not install

the bracket as shown in the right hand image.

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

PHYSICAL INSTALLATION

Step 2 – Mount bracket to the radar

Fit the six torx screws and washers and

tighten to a torque of 1.2Nm.

Step 3 – Mount radar to the pole

Insert the M10 Mounting Bolt through

the hole in the bracket on the pole,

loosely tighten the M10 Nyloc Nut.

Position the radar at roughly

30 degrees to the road, the etched

marks on top of the bracket will help

with alignment.

Installation

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

AGD 343

HIGHWAYS MONITORING RADAR

CONNECTIONS

Pin No. Associated wire colour Function Additional Notes

1 White GND (0v)

2 Brown GND (0v)

3 Yellow Y (TX-)

4 Green Z (TX+)

5Grey B (RX-)

6 Pink A (RX+)

7 Blue Vin

8Red Vin

6 4

7 3

1 2

ELECTRICAL INSTALLATION

The detector is powered using a 24Vdc supply. The power is applied to the detector using the multi-pin mating

connector.

The product mating connector is shown above and is located on the bottom of the product.

343 Power/RS422 Cable Assembly

The cable assembly to connect power and comms to the radar is Part Number CA-310. This cable is supplied in

a 10m length and is shown below:

CA-310 has the same attributes as shown in the Connections table above.

Installation
