AES 7788F Manual de usuario

7788F

RF Subscriber Unit

Installation and Operation Manual

AES Corporation

285 Newbury Street

Peabody, MA 01960-1315 USA

Tel (978) 535-7310 •Fax (978) 535-7313

www.aes-intellinet.com

P/N 40-7788

Rev 6

August 30, 2016

;sdkpfo pijfpfpodkspfosd

AES 7788 Series RF Subscriber Unit ─Installation and Operation Manual

AES Corporation 2 40-7788, Rev 6, August 30, 2016

NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING

JURISDICTION, AND OTHER INVOLVED PARTIES

This product incorporates field-programmable software. In order for the product to comply

with the requirements in the Standard for Control Units and Accessories for Fire Alarm

Systems, UL 864, certain programming features or options must be limited to specific values or

not used at all as indicated below.

Program Permitted in Possible functional

Group Feature or Option UL 864 (Y/N) settings Settings permitted in UL 864

Timing Parameters

AC Fail Report Delay Y 0-60 Min or Random R (Random) or 0-60 (Minutes)

Reporting Delay Y 0 –80 Seconds 10 –20 Seconds

Zone Programming

Fire/Trouble PKT Y Y or N Y

Zone Programming Y S, F or B If zone is in use F

If not in use B

Restoral Y X or R R

Set Modes Enable Repeating Y Y or N Y

Suppress AC Fail N Y or N N

By Remote programming only

Acknowledge Delay * Y 60 –330 Seconds Not greater than 60 Seconds

* Acknowledge delay is used in detecting the existence of a functional antenna and therefore affectsantenna cut detection.

Note: UL and NFPA do not allow remote programming of an installed 7788F unless an

authorized person is present at the unit to temporarily enable this capability. Selecting

“Y” for Fire/Trouble PKT in Zone Programming function disables remote programming.

Entering one of the programming modes accessed with a directly attached programmer by

<Ctrl> <F1>, <Ctrl> <F2> or <Ctrl> <F3> enables remote programming for 10 minutes.

AES 7788 Series RF Subscriber Unit ─Installation and Operation Manual

AES Corporation 3 40-7788, Rev 6, August 30, 2016

TABLE OF CONTENTS

1AES 7788F RF Subscriber Unit........................................................................................... 5

1.1 Description...................................................................................................................... 6

1.2 Features........................................................................................................................... 6

1.3 Easy Installation.............................................................................................................. 6

1.4 Power Requirements....................................................................................................... 6

1.4.1 Battery Calculations.................................................................................................... 7

1.5 RF Module (Transceiver)................................................................................................ 7

1.6 Optional Accessories ...................................................................................................... 7

1.7 Safety Considerations ..................................................................................................... 7

1.8 Technical Specifications................................................................................................. 9

1.9 UHF Antenna Options:................................................................................................. 10

1.10 Coaxial Cable Options.................................................................................................. 10

1.11 Coaxial Cable and Antenna Installation Tips ............................................................... 11

2Commercial Fire and Burglary Installation Notes.......................................................... 12

2.1 Power Requirements: 16.5 VAC, 40VA/45VA............................................................ 13

2.2 Backup Battery requirement, Commercial Fire............................................................ 13

2.3 UL 681 .......................................................................................................................... 13

2.4 UL 1610/365................................................................................................................. 13

2.5 7788F EOL Inputs / Zones............................................................................................ 13

2.6 Local Trouble Output................................................................................................... 13

3Installation........................................................................................................................... 14

3.1 Overview....................................................................................................................... 14

3.2 Physical Installation...................................................................................................... 14

3.3 Antenna Grounding and Surge Protector...................................................................... 16

3.4 Wiring - General ........................................................................................................... 18

3.5 Wiring –Antenna Cut / Trouble Output (J4)................................................................ 19

3.6 Wiring - Zone Inputs..................................................................................................... 22

3.7 Power Up ...................................................................................................................... 25

3.8 SELF-TEST / STATUS ERROR CODES..................................................................... 26

3.9 Status (LED) Indicators ................................................................................................ 27

3.10 ALM LED Blink Pattern Chart..................................................................................... 27

4Programming....................................................................................................................... 28

4.1 Remote Programming Limitations (Enable/Disable).................................................... 28

4.2 Program ID # and System Cipher Code........................................................................ 29

4.3 Timing Parameters........................................................................................................ 29

4.4 Zone Programming ....................................................................................................... 31

4.5 Set Modes –Enable Repeating and Suppress AC Fail................................................. 33

4.6 Reset RAM.................................................................................................................... 33

4.7 Initializing the Subscriber Unit..................................................................................... 34

4.8 Local Status Check ....................................................................................................... 35

4.9 Monitor Transmitter Functions..................................................................................... 36

4.10 KEY TRANSMITTER ................................................................................................. 37

4.11 Display Zone Status...................................................................................................... 38

4.12 Display Routing Table.................................................................................................. 38

4.13 Text Messages............................................................................................................... 39

4.14 Handheld Programmer –Quick Command Guide........................................................ 40

4.15 Reconnect Cables after Programming .......................................................................... 40

4.16 Programming the Subscriber Unit from a PC............................................................... 40

AES 7788 Series RF Subscriber Unit ─Installation and Operation Manual

AES Corporation 4 40-7788, Rev 6, August 30, 2016

5Testing.................................................................................................................................. 41

5.1 Installation Site Checks................................................................................................. 41

5.2 Acknowledge delays..................................................................................................... 41

6Maintenance, Compliance, Warranty and Repair........................................................... 42

6.1 Troubleshooting............................................................................................................ 42

6.2 Parts List ....................................................................................................................... 42

6.3 Contact Information...................................................................................................... 42

6.4 Warranty and Service Procedure .................................................................................. 43

AES 7788 Series RF Subscriber Unit ─Installation and Operation Manual

AES Corporation 5 40-7788, Rev 6, August 30, 2016

1AES 7788F RF Subscriber Unit

Enclosure Cover Label

AES 7788 Series RF Subscriber Unit ─Installation and Operation Manual

AES Corporation 6 40-7788, Rev 6, August 30, 2016

1.1 Description

The 7788F Subscriber Unit is an AES-IntelliNet RF Communicator, which is typically

used to link an alarm panel to an alarm monitoring central station. This series unit is UL

Listed and NFPA compliant for commercial fire alarm monitoring. This unit has 8 wired

inputs. All 8 inputs are of the end of line resistor (EOL) type. For those that need or

want the reversing voltage inputs, there is another model –7744F that has four inputs of

the EOL type and four reversing voltage inputs.

1.2 Features

This section is included for those customers familiar with other AES IntelliNet UL

Subscriber products. Listed below are the new features incorporated into the unit.

Fail Secure Relay on board for Acknowledge Delay / Antenna Cut / Low Battery /

Charger Fail output. Formerly was a Fail Safe open collector output and only for

Antenna cut / Acknowledge Delay.

Separate power no longer required for the Zone Input Module as required on the

7750-F-4X4 and 7750-F-8.

AC Failure Random Reporting Delay. AC failure/restore messages are generated

when they exist continuously for 100 minutes. The actual transmission of the

generated message is delayed a random number of minutes between 0 and 60, but

can be set to a value by the user. The delay is set at the time the event is

generated. This setting has no effect on the time of detection of the failure. That

is hardcoded at 100 minutes.

Transceiver power PTC is added. It is installed in series with the power line to

the transceiver disconnecting power if the transceiver draws too much current.

Remote programming using software at the central station is disabled when

Trouble Packets are enabled. This can temporarily be enabled using a directly

attached programmer in the Programmer Jack. This is to comply with UL/NFPA

requirements. Trouble Packets are enabled when “Y” is the response to the

question “Fire/Fire Zones” in Zone Programming <Ctrl> + F3.

1.3 Easy Installation

The 7788F unit is housed in a rugged lockable steel box for long lasting protection and

easy installation. The alarm panel’s alarm outputs are connected to the 7788F Unit. A

supplied AES-IntelliNet tamper resistant 2.5 dB flexible antenna can be secured to the

subscriber enclosure in the provided hole, or use a remotely installed antenna, purchased

separately. Once powered and properly configured, the 7788F RF Subscriber self-enrolls

into the AES-IntelliNet wireless network, receives signals from the alarm panel and

transmits them via wireless mesh radio to the AES-IntelliNet central receiver.

1.4 Power Requirements

The steady state DC current draw is only 150mA (210mA with optional accessories).

The peak current draw of 1.2A (1.3A with optional accessories) for RF power output

levels of 2W, is only for a very short transmit duration of less than 1/3 second.

AES 7788 Series RF Subscriber Unit ─Installation and Operation Manual

AES Corporation 7 40-7788, Rev 6, August 30, 2016

1.4.1 Battery Calculations

Description

Current

Battery Size Required

7788F

See 7788F Installation and

Operation Manual

7.5 Ah

7788F + 7794

See 7788F & 7794 Installation

and Operation Manuals

7.5 Ah

7788F + 7794 +7762 + 7740

See 7788F, 7794 & 7762

Installation and Operation

Manuals. For 7740 refer to

Sec. 3.5 –Fig. 4A and Fig. 4B

in this manual.

12 Ah

7788F +7762 + 7740

See 7788F & 7762 Installation

and Operation Manuals. For

7740 refer to Sec. 3.5 –Fig.

4A and Fig. 4B in this manual.

12 Ah

1.5 RF Module (Transceiver)

Each 7788F Unit includes an RF Module known as a transceiver along with a standard

tamper resistant 2.5 dB flexible omni-directional antenna. The standard antenna supplied

is for the frequency range of 450-480MHz. Contact AES for additional information on

available Models for use with other Non-UL frequencies and antennas.

See UHF Antenna Options in Section 1.9

1.6 Optional Accessories

7041 –Hand Held Subscriber Programmer

7043E –Programming Cable for PC or laptop to E Family subscribers with

Modular programming Jack and 7794 IntelliPro Fire

7794 –AES IntelliPro Fire, Dialer Capture Module

7067 –AES IntelliTap II, Dialer Capture Module

7770 –AES FireTap Serial Data Module

7762 –AES Hardware Supervisor

1.7 Safety Considerations

All equipment must be installed in accordance with National Electric Code,

NFPA 70, National Fire Code NFPA 72 and local building codes.

It is unlawful to operate this equipment in the USA without a valid FCC radio

station license. Other countries most likely require licensing through appropriate

authorities as well.

Be certain to properly ground the antenna, 7788F enclosure and any surge

protection devices to help dissipate surges away from the equipment and

personnel. The grounding of the antenna and surge protector is for your safety

and the safety of your equipment and should not be neglected.

If the antenna or cables connected to this equipment come in contact with

electrical power lines, DEATH or SERIOUS INJURY may result.

AES 7788 Series RF Subscriber Unit ─Installation and Operation Manual

AES Corporation 8 40-7788, Rev 6, August 30, 2016

Test this system periodically for proper operation. AES assumes no responsibility

for this equipment's failure to operate. AES' sole responsibility is to repair or

replace any AES device found to be defective during the warranty period.

Exposure to extreme cold below 0ºC or extreme hot above 50ºC could damage

any Gel battery used in the installation of this product. Extreme temperatures can

also cause unexpected operation of the electronics.

Exposure of the electronics to excessive water or moisture (such as a rain, shower,

bath, pool, sauna, etc.) could cause damage and unexpected operation.

Avoid dropping or other physical impact to the unit, which could damage the

enclosure or internal components.

AES 7788 Series RF Subscriber Unit ─Installation and Operation Manual

AES Corporation 9 40-7788, Rev 6, August 30, 2016

1.8 Technical Specifications

SIZE: 13.25”h X 8.5”w X 4.3”d (34 cm X 21.5 cm X 11 cm) excluding antenna

WEIGHT: 5.8 pounds (2.6 kilograms) Without Battery (Add 6 pounds with Battery)

TRANSFORMER SECONDARY POWER INPUT: 16.5VAC, 40V / 45VA class 2 (dry)

source only

VOLTAGE: 12VDC nominal

MAINS INPUT CURRENT: 150 mA standby; 1.2A transmit

MAINS INPUT CURRENT with optional accessories: 210 mA standby; 1.3 A transmit

(2 Watt Transceiver)

OPERATING TEMPERATURE RANGE: 0° to 49° C (32° to 120°F)

STORAGE TEMPERATURE RANGE: -10° to 60° C (14° to 140°F)

RELATIVE HUMIDITY RANGE: 0 to 93% RHC, Non Condensing

BACK-UP BATTERY: 12V, 7.5AH –12 AH (24 Hour standby), 1.2A Max.

(Min), lead acid gel type; required for all installations

BATTERY FUSE: Onboard self-resetting fuse. Not serviceable

ALARM SIGNAL INPUTS: 8 Supervised individually programmable Zones:

All 8 are EOL type with, Trouble & Restore

LOW BATTERY REPORTING: Below 11V. 22.5 Minute Test Cycle (approx..)

AC FAILURE REPORTING: AC Fail messages are queued for transmission to central

station after approximately 100 continuous minutes without AC power. Transmission to

central station is then delayed randomly between 0 to 60 minutes. Restore is similar with

Restore message queued for transmission after approximately 100 continuous minutes

with AC power restored. AC Fail/Restore messages will be sent between 100 and 160

minutes after the failure or restore occurs that remains for 100 minutes. See Section 4.3 -

Timing Parameters for additional information and programming options.

ANTENNA CUT / LOW BATTERY / CHARGER FAIL LOCAL REPORTING: Form

C Fail Secure Relay contact. Engaged for normal operation. Disengages on Reset,

Antenna Cut/Acknowledge Delay, total power loss condition, low battery or charger fail.

Contact rating –24VDC 1-Amp max, Not Supervised

RESET BUTTON: Located on the PCB.

TRANSCEIVER:

Standard UHF Frequency Ranges (410-440MHz, 440-470MHz, 470-512MHz)

TRANSCEIVER FUSE: 400 milliamp PTC, Not serviceable

STANDARD RF OUTPUT POWER: 2 Watts

Zones 1-8: dry contact supervised with 2.2K EOL resistor

GROUND FAULT: A ground fault as tested by UL, is when an isolated ground terminal

of a Supervised zone labeled “G” is less than 0.1 Ohm impedance to Earth Ground. A

zone 10 Trouble is transmitted for this fault. The CID code generated at alarm automation

for a Ground Fault is E370 C010.

AES 7788 Series RF Subscriber Unit ─Installation and Operation Manual

AES Corporation 10 40-7788, Rev 6, August 30, 2016

1.9 UHF Antenna Options:

(450-480 MHz; contact factory for other frequencies)

Antenna db

Construction

Usage

Length

P/N

2.5 db Case Top Flex Tamper Resistant (1 & 2)

Vinyl Clad

Indoor

11 in

7214

3 db Stealth (Not shown below) (3)

Vinyl Clad

Indoor

1.5 ft

7211

3 db Standard Gain(4 & 5)

Steel Mast

Indoor

1.5 ft

7210-3-UM

5 db High Gain (4 & 5)

Steel Mast

Indoor

3 ft

7210-5-UM

6 db Rugged High Gain (4)

Fiberglass Mast

In/Outdoor

4.5 ft

7210-6-UC

7 db Rugged Higher Gain (4)

Fiberglass Mast

In/Outdoor

6 ft

7210-7-US

9 db Central Station High Gain (4)

Fiberglass Mast

In/Outdoor

8 ft

7210-9-UC

1. These alternate antennas may be used with the 7788F Fire Subscriber unit.

2. Included standard Tamper Resistant antenna, mounts on Alarm Unit’s enclosure.

Includes cable.

3. Mounts in attics, vents, walls, behind drapes, etc. Includes 10-foot cable.

4. Requires cable (See Section 1.10). Usually requires user supplied mounting hardware

such as a pole with mounting brackets/hardware.

5. Antenna is intended for outdoor use, supplied mount is intended for indoor use as coax

connection is exposed. To use outdoors, connection must be sealed with a suitable

product such as a self-fusing tape to protect against moisture.

The antenna must be installed in accordance with National Electric Code and local electric

code. A surge protector, AES P/N 7230 or (52-0054), must be installed in line with any type

of remotely installed antenna. Refer to remote antenna diagram in Section 3.3 for installation

details.

1.10 Coaxial Cable Options

CABLES w/CONNECTORS, BNC ↔ N, for all AES Subscriber Units, high

performance, low loss cables for all -UM, -UC

and -US antennas above.

● 10 Ft RG-58 Cable, P/N 7220-10-N

● 25 Ft RG-58 Cable, P/N 7220-25-N

● BNC Plug/connector (male) crimp style for

RG-58 Coax, P/N 12-0102

● 100 Ft. RG-8 W/1 N male (on spool),

P/N 13-0345-100 - this coax is available for longer

runs, cut to length and installer terminated.

● Loose connectors required to complete RG-8

assembly, P/N 12-0101

● Crimp tool required for 12-0101, P/N 7244

● Cable Assembly; 18” RG-58 (N female, bulkhead ↔ BNC male) Used to connect

RG-8 with N male to Enclosure body, P/N 13-0346

Notes:

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Puerta de AES

AES

AES 7788F-C Manual de usuario

AES

AES 7007 Manual de usuario

Manuales populares de Puerta de otras marcas

LST

LST M500RFE-AS Manual de usuario

Kinnex

Kinnex Media Gateway Manual de usuario

2N Telekomunikace

2N Telekomunikace 2N StarGate Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manual de usuario

Telsey

Telsey CPVA 500 - SIP Manual de usuario

RTA

RTA 460A-NNA4 Hoja de especificaciones

Shaw

Shaw Gateway HDPVR Manual de usuario

ABB

ABB VSN900 Guía de inicio rápido

Commander

Commander Pulse Manual de usuario

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manual de usuario

NETGEAR

NETGEAR C6300BD Manual de usuario

Amit

Amit CDW531AM Manual de usuario

HMS

HMS Netbiter EasyConnect EC150 Manual de usuario

Huawei

Huawei EchoLife HG620 Manual de usuario

AT&T

AT&T U-verse 3801 Manual de uso y cuidado

Logic IO

Logic IO RTCU MX2 turbo Manual de usuario

Suttle

Suttle MediaMAX MXM-521 Manual de usuario
