AES global Praetorian Guard Instrucciones de montaje
1 | P a g e
Installation & User Instructions
Praetorian Guard IP Intercom
(with 4G access Point)
PROFESSIONAL INSTALL ONLY
Manual Version 1.1
Tip: Site Survey BEFORE you begin.
See page 4
2 | P a g e
Index
Section
Pages
PHASE 1 –SITE SURVEY
3-4
Site Survey (4G Router)
4
PHASE 2 –PRODUCT OVERVIEW
5-23
Overview of Call Points
6-9
Overview of Optional Extra Devices
10
More Detail….
11-17
PCB Module Overview
18-19
Technical Specifications
20-23
PHASE 3 –SETUP 4G
24-45
PHASE 3a –SETUP 4G (Router Separate)
25-29
PHASE 3b –SETUP 4G (Router Integrated)
30-35
PHASE 3 –SETUP 4G (Continued)
36-45
4G Setup Intercom on App
37-41
Time Sync & Testing
42-43
Answering on Android
44
Answering on iOS (Apple)
45
PHASE 4 - INSTALLATION
46-55
How to Achieve & Maintain IP55 Rating
47
Power & Antenna
48
Solar Power
49
Wiring Example
50
Connecting Slave Devices
51
Adding Additional APP Users
52
Sound, Volumes and Speech / Intercom & Device Sound Options
53
Using Keypad Codes
54
PHASE 5 –ADVANCED SETUP
55-71
Feature Shortcuts & Settings Overview
56
Standard Features
57
Edit Intercom Details / Add a New Device ID
58
Ringtones of In-app Call / Check APP version
59
Check Intercom Firmware / Add, Edit or Delete Users & Logins
60
Adjust Relay Trigger Times / Adjust Intercom Time
61
Wi-Fi Settings / Adjust Maximum Monitoring Time
62
Adjust Maximum Talking Time / Adjust Maximum Calling Time
63
Reboot Intercom / Simplex / Duplex Audio Selection
64
Advanced Feature Overview / Notifications
65
Auto Relay Times / Camera Stream Resolution
66
Activity Log
67
Keypad Codes
68
PROX Cards/Tag IDs
69
Voicemail Option for missed Callers / Motion Detection Option
70
Troubleshooting
71-72
App Updates / Firmware Updates / Extra Resources
73
Intercom Maintenance / Environmental Information / Ingress
74
Warranty
75
Regulatory Compliance / Declaration of Conformity
76
3 | P a g e
PHASE 1
Site Survey
4 | P a g e
Mbs
Slow Fast
Site Survey (4G Router)
YES!
I have 4G signal at the gate with my phone! If
not, STOP. You will need some! Try a different
network provider.
Upload Speed
I have at least 1.5 Mb UPLOAD speed. If not
STOP! This system may operate intermittently
remotely or have delayed PUSH notifications.
The Praetorian Guard is specially designed to transmit the video and audio stream using on
average 400 KBit/sec (peaking to 1Mbps). This loosely translates to requiring a minimum of
1.5mbps UPLOAD speed on the network that the intercom is connected to. The higher the
upload speed the better quality of image up to approx. 4mbps.
If you have a good GSM signal for the network being used you can expect to have an upload
speed of up to 10mbps.
Note: When using our 4G access point the upload speed will be influenced by the GSM signal
being received. With a high signal level the access point can pull approx. 10mbps upload.
5 | P a g e
PHASE 2
Product Overview
6 | P a g e
Overview of Call Points(Modular Design)
Separate 4G Router
Overview of Call Points(Modular Design)
Integrated 4G Router
PRAE-4GXX-MOD
PRAE-4GXX-MOD-KP
PRAE-4GXX-MOD-PX
PRAE-4GXX-MOD-PX-KP
PRAE-4GXX-MOD-ROUTER
PRAE-4GXX-MOD-KP-ROUTER
PRAE-4GXX-MOD-PX-ROUTER
PRAE-4GXX-MOD-PX-KP-ROUTER
7 | P a g e
Overview of Call Points(Architecture Design)
Separate 4G Router
PRAE-4GXX-AB
PRAE-4GXX-AS
PRAE-4GXX-ABK
PRAE-4GXX-ASK
PRAE-4GXX-PX-ABK
PRAE-4GXX-PX-ASK
8 | P a g e
Overview of Call Points(Portrait Flush Design)
Separate 4G Router
PRAE-4GXX-FB
PRAE-4GXX/FS
PRAE-4GXX/FBK
PRAE-4GXX/FSK
PRAE-4GXX-F-PX-ABK
PRAE-4GXX-F-PX-ASK
9 | P a g e
Overview of Call Points (Pedestal Design)
Integrated 4G Router & Antenna
Overview of Call Points (Pedestal Flush Design)
Integrated 4G Router
PRAE-4GXX-PED
PRAE-4GXX-KP-PED
PRAE-4GXX-PX-PED
PRAE-4GXX-PX-KP-PED
PRAE-4GXX-PED-F
PRAE-4GXX-PED-F-KP
10 | P a g e
Overview of Optional Extra Devices
MON-11
POWER CONDITIONING MODULE
TBC (future addition late 2021)
TBC (future addition late 2021)
