AES global 603 DECT Manual de usuario
―2 relay outputs, control 2 entrances with 1 handset.
―Up to 4 handsets / indoor units per system.
―Built in voicemail feature to record missed callers at your door or gate (playback
from handset).
―Intercall between handsets.
―2 year warranty.
―Demo kits for testing available.
―Contact us for details on a free site survey.
Cordless
handset
option
Handsfree wall/desk
mount option
High quality
speech panel
options
S i m p l e W i r e l e s s A c c e s s !
Transmitter
Digital Enhanced Cordless
Telecommunications
D.E.C.T 603
Voicemail Feature
for Missed Callers!
Charging Dock
Digital Wireless Signal
for Clear Voice
2x
Relays
Transmitter
Illuminated Call
Button
Illuminated Optional
Keypad
Outdoor Unit Indoor Unit
Relays 2Power Supply Charging Base = 5v dc.
Wall Unit = 12v dc.
Construction Marine Stainless & Powder
Coated Aluminium
Volume Adjust Yes
Keypad Relays 3Voicemail Capacity 16
Power Supply 24v DC (included) Calling Between
Handsets
Yes
Current
Consumption
65mA Standby, 400mA
Calling
Digital Enhanced Cordless
Telecommunications
D.E.C.T 603
Technical Specification
603 Range
Intercom
Transmitter
Up to 200m
expected working
range*
Digital
*Range varies according to
building construction, obstacles,
shrubs, trees, height of transmitter,
etc.
Perimeter wall/fence
Digital Enhanced Cordless
Telecommunications
D.E.C.T 603
Sleek, all black call point, constructed from marine grade stainless steel, powder
coated aluminium hood and gloss black toughened acrylic faceplate trim. Also
available with wall mount monitor *603-HF-IMP / 603-HF-IMPK
603-IMP 603-IMPK
Pedestal mountable, high volume call point, constructed from marine grade stainless
steel, powder coated aluminium hood and gloss black toughened acrylic faceplate
trim. Also available with wall mount monitor *603-HF-IMP-PED / 603-HF-IMPK-PED
603-IMP-PED 603-IMPK-PED
Stylish, modern curved profile call point with wall backlighting effect in neon
blue. Constructed from 100% marine grade stainless steel and toughened acrylic
face trim. Also available with wall mount monitor *603-HF-AB / 603-HF-ABK
603-AB 603-ABK
100% BS316 marine grade stainless steel, in modern curved profile with wall back lighting
effect in cool white. Also available with wall mount monitor *603-HF-AS / 603-HF-ASK
603-AS 603-ASK
603-IMP CALL PANEL 603-IMPK CALL PANEL
603-AB/AS CALL PANEL 603-ABK/ASK CALL PANEL
603-IMP-PED CALL PANEL
603-IMPK-PED CALL PANEL
Additional handsets (up to total of 4 max per intercom, which can be
a mix and match of both styles.)
603-EH
Additional handsets (up to total of 4 max per intercom, which can be
a mix and match of both styles.) Can be wall or desk mounted.
603-HF-EH
Range boosting antenna which can be added to transmitter at gate
and also optionally to the handsfree monitor type. One antenna can
boost range by 30%. Comes with 2 metre antenna cable
(RG174 with SMA male connector).
603-WIFIA
Up to 4 603
Handsets
MULTIP2
Multiplexor
DECT
Transmitter
M u l t i - c a l l S t a t i o n S y s t e m
Speech
Panel
Speech
Panel
Speech
Panel
Speech
Panel
MULTIP2
Multiplexor
603-TX
(Transmitter & 1
Handset Kit)
MULTIP2
Multiplexor
IMP-CP
IMPK-CP
IMP-
PED-CP
IMPK-PED-CP
ABK-CP AB-CP ASK-CP AS-CP
Call Panel Options
8 METRES MAX 4 METRES MAX
Speech Panel Multiplexor DECT Transmitter
Maximum distances
Connect 2-4 call panels to 1 DECT transmitter
―Digital D.E.C.T wireless intercom system for flats, apartments or shared gate
entrances.
―Up to 4 call buttons, each button calling a different handset.
―Working range of 100 metres through concrete (up to 500 metres open field).
―1 handset per property or apartment.
―Simple setup and install.
―Keypad option for coded access.
―Built in voicemail feature for missed callers, user can listen to messages on handset.
―2 year manufacturers warranty.
Voicemail
Feature for
Missed
Callers!
Charging Dock
Digital Wireless Signal
for Clear Voice
2x
Relays
Transmitter
Illuminated
Call
Buttons
Illuminated Optional
Keypad
MULTI BUTTON
D.E.C.T 703
Handsfree
Wall/Desk Mount
Available
