AEMC PowerPad 8335 Guía de configuración



QUICK START

USER GUIDE

8335

PowerPad®

IMPORTANT WARRANTY NOTE:

By registering online within 30 days from the date of

purchase, your warranty will be extended to 3 years

Statement of Compliance

Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments

certiﬁes that this instrument has been calibrated

using standards and instruments traceable to

international standards.

We guarantee that at the time of shipping your

instrument has met its published speciﬁcations.

An NIST traceable certiﬁcate may be

requested at the time of purchase, or obtained

by returning the instrument to our repair and

calibration facility, for a nominal charge.

The recommended calibration interval for this

instrument is 12 months and begins on the date of

receipt by the customer. For recalibration, please

use our calibration services. Refer to our repair

and calibration section at www.aemc.com.

Serial #: ________________________________

Catalog #: ______________________________

Model #: 8335

Please ﬁll in the appropriate date as indicated:

Date Received: _________________________________

Date Calibration Due: _______________________

Chauvin Arnoux®, Inc.

d.b.a AEMC®Instruments

www.aemc.com

PRODUCT PACKAGING

Shipping Contents:

USB STICK: DataView®software and complete user manual for the Model 8335

can be located on the USB stick supplied with the instrument.

(1) PowerPad®Model 8335

Cat. #2136.20

(1) Large Classic Tool Bag

Cat. #2133.73

(12) ID Markers

Cat. #2140.45

Also Included:

4 GB USB Stick (DataView/User Manual)

NiMh Battery - installed

Kits will also include (order dependent):

(4) MN93-BK current probes

(4) MN193-BK current probes

(4) SR193-BK current probes

(4) AmpFlex®193-24-BK (24") current sensors

(4) AmpFlex®193-36-BK (36") current sensors

(4) MR193-BK current probes

(4) MiniFlex®MA193-10-BK current sensors

(3) AmpFlex®193-24-BK and (1) MN193-BK

(1) 5 ft USB Cable

Cat. #2140.46

(1) Power Adapter 110/240V w/ Power Cord

Cat. #5000.19

(5) Black Test Leads and Alligator Clips

Cat. #2140.43

(1) Soft Carrying Pouch

Cat. #2140.15

Charging the Battery

Fully charge the battery before the ﬁrst use.

The batteries automatically begin recharging when the instrument is connected to AC power.

Only use the supplied AC power adapter to recharge the batteries.

NOTE: A full recharge of a completely discharged battery takes 5 hours approx.

120V ± 10%, 60Hz

230V ± 10%, 50Hz

To recharge the battery:

• Connect the supplied power

cord to the instrument and AC

power.

• The button lights and will

go out when the power cord is

disconnected.

Button Functions

BUTTON DESCRIPTION

Return to the choice of measurement view.

Conﬁgure the PowerPad®(SET-UP).

Take a snapshot of the current screen or access screens already stored in the memory.

Record associated waveform and power measurement data.

Get help on the current display functions, in the language chosen by the user.

Transients or Inrush Current:

• Sets and views transient and inrush current waveforms associated with rapid changes in input

Harmonics Mode:

• Displays the harmonics in percent and value ratios for voltage, current and power for each

harmonic through the 50th

• Determines harmonic current produced by non-linear loads

• Analyzes the problems caused by harmonics according to their order

(heating of neutrals, conductors, motors, etc)

Waveforms Mode:

• Displays voltage and current waveforms or vector representation

• Identiﬁes signal distortion signatures

• Displays of amplitude and phase unbalance for voltage and current

• Checks connections for correct phase order

Alarm Events:

• Provides a list of the alarms recorded according to the thresholds programmed during

conﬁguration

• Logs interruption with half-cycle resolution

• Determines energy consumption exceedances

• Stores value, duration, date, time and set point for up to 4096 events

Trend Mode:

• Lists all recording trends and views them on the display

(Urms, Vrms, Arms, etc)

Power / Energy:

• Displays power levels and the associated parameters (power factor, displacement and tangent)

• Energy monitoring

• Four quadrant measurement to discern produced/consumed active energies and inductive/capaci-

tive reactive energies

Control Features

PowerPad

1. Over molded protective housing

2. LCD Display

3. Six function buttons (yellow)

4. Four function buttons (see chart, left)

5. ON/OFF button

6. Four current inputs and ﬁve voltage

inputs

7. USB port

8. Input for external power supply

and battery charging

9. Conﬁrm/Enter button

10. Navigation buttons

11. Six mode buttons (see chart, left)

Connection Terminals

1. Four (4) current inputs on the top of

the instrument to enable the use of

current sensors (MN, SR, AmpFlex®,

MiniFlex®, and MR probes).

2. Five (5) voltage inputs.

3. Insertion locations for the current and

voltage color-coded ID markers

Instrument Conﬁguration

NOTE: The instrument conﬁgurations can also be modiﬁed through the DataView®software.

NOTE: The instrument must be conﬁgured the ﬁrst time it is used. The conﬁguration is

saved in memory when the instrument is turned OFF.

Press the button to conﬁgure the unit. The following sub-menus appear:

• Set the display language by pressing the yellow button corresponding to the screen

language icons.

• The parameter that is ready to be conﬁgured will be highlighted in yellow. To move to a

different parameter, use the ▲ and ▼ buttons.

• Press the Enter button to select a parameter.

• Use the ◄ and ► buttons to change a value or setting.

• When ﬁnished, return to the Conﬁguration menu by pressing the button.

PARAMETER FUNCTION

Date / Time Sets the date and time format

Display Adjusts the contrast and brightness of the display;

Deﬁnes the color of the voltage and current curves

Calculation Methods Determines if harmonics are used or not used in calculations of reactive quantities

(power and energy)

• With harmonics: Harmonics are taken into account when calculating reactive

parameters.

• Without harmonics: Only the fundamental part is used for the calculation of

reactive parameters

Electrical Connection Determines the type of connection to the network

• Single-Phase

• Split-Phase

• 3-Phase 4-Wire

• 3-Phase 5-Wire

Sensors & Ratios Deﬁnes the type of current probe to connect

• MN93: 200A

• MN193: 100A or 5A (with variable ratio)

• SR193: 1000A

• SL261: 10A and 100A range

• AmpFlex®Sensors: 3000A (measures up to 6500Arms)

• MiniFlex®Sensors: 1000A

• MR193: 1000AAC/1200ADC

• 5A three-phase adapter (3-channel only)

Transient Mode Conﬁgures the voltage and current thresholds

Trend (Recording) Mode Selects the parameters to record (up to 4 conﬁgurations)

Alarm Mode Deﬁnes the parameters of an alarm

Erase Memory Deletes conﬁgurations, alarm settings, snapshots and recordings

About Displays the serial number, software and hardware version

Getting Started

NOTE: Make sure the PowerPad®is fully charged before use.

Connecting:

• Start the instrument by pressing the button.

• Conﬁgure the instrument to obtain the required results and type of network.

• Connect the current leads and sensors to the PowerPad®.

• Connect the ground and/or neutral lead to the network ground and/or neutral (when

distributed), as well as the corresponding current sensor.

• Connect the L1 phase lead to the network L1 phase, as well as the corresponding

current sensor.

• Repeat the procedure for phases L2, L3 and N.

Disconnecting:

• Proceed in the reverse order to connecting, always ﬁnishing by disconnecting the

ground and/or neutral (when distributed).

• Disconnect the leads and press the button to turn the instrument off.

• Recharge the battery, if necessary.

Installation of the Leads and Current Sensors

Twelve sets of color-coded rings and inserts are supplied with the PowerPad®. Use these ID

markers to identify the leads and input terminals.

• Detach the appropriate inserts from the color-coded marker and place them in the holes

provided under the terminals (larger inserts for current terminals, smaller inserts for volt-

age terminals).

• Clip the rings of the same color to the ends of the lead you will be connecting to the

terminal.

Installing DataView®

DO NOT CONNECT THE INSTRUMENT TO THE PC BEFORE INSTALLING THE

SOFTWARE AND DRIVERS.

1. Insert the USB stick into an available USB port (wait for driver to be installed).

2. If Autorun is enabled, an AutoPlay window should appear. If Autorun is disabled, it will be

necessary to open Windows Explorer, then locate and open the USB stick drive labeled

“DataView” to view the ﬁles on the drive.

3. In the AutoPlay window, select “Open folder to view ﬁles”.

4. Double-click on Setup.exe from the opened folder view to launch the Dataview®setup

program.

NOTE: For more information on using DataView®, refer to the Model 8335 user manual that is

supplied on the USB stick.

Updating Software & Firmware

To provide our customers the best possible service in terms of performance and technical upgrades,

AEMC®offers free software and ﬁrmware updates on our website.

• Visit us at: www.aemc.com

• Click on the Tech Info tab and choose the desired software or ﬁrmware download.

DataView®can also be updated by selecting “Update” from the Help menu within the soft-

ware.

WARNING: Updating the ﬁrmware will erase all stored data in the instrument. It is

recommended to download all stored data before performing any ﬁrmware updates.

Repair and Calibration

To ensure that your instrument meets factory speciﬁcations, we recommend that it

be scheduled back to our factory Service Center at one-year intervals for recalibra-

tion, or as required by other standards or internal procedures.

For instrument repair and calibration:

You must contact our Service Center for a Customer Service Authorization Number

(CSA#). This will ensure that when your instrument arrives, it will be tracked and

processed promptly. Please write the CSA# on the outside of the shipping container.

If the instrument is returned for calibration, we need to know if you want a standard

calibration, or a calibration traceable to N.I.S.T. (Includes calibration certiﬁcate plus

recorded calibration data).

Ship To: Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments

15 Faraday Drive

Dover, NH 03820 USA

Phone: (800) 945-2362 (Ext. 360)

(603) 749-6434 (Ext. 360)

Fax: (603) 742-2346 or (603) 749-6309

E-mail: [email protected]

(Or contact your authorized distributor)

Costs for repair, standard calibration, and calibration traceable to N.I.S.T. are

available.

NOTE: You must obtain a CSA# before returning any instrument.

Technical and Sales Assistance

If you are experiencing any technical problems, or require any assistance with the

proper operation or application of your instrument, please call, mail, fax or e-mail

our technical support team:

Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments

200 Foxborough Boulevard

Foxborough, MA 02035 USA

Phone: (800) 343-1391

(508) 698-2115

Fax: (508) 698-2118

E-mail: [email protected]

www.aemc.com

NOTE: Do not ship Instruments to our Foxborough, MA address.

Limited Warranty

The Model 8335 is warranted to the owner for a period of one year from the date

of original purchase against defects in manufacture. This limited warranty is given

by AEMC®Instruments, not by the distributor from whom it was purchased. This

warranty is void if the unit has been tampered with, abused or if the defect is related

to service not performed by AEMC®Instruments.

Full warranty coverage and registration is available on our website:

www.aemc.com/warranty.html.

IMPORTANT WARRANTY NOTE:

By registering online within 30 days from the date of

purchase, your warranty will be extended to 3 years

Please print the online Warranty Coverage Information for your records.

What AEMC®Instruments will do:

If a malfunction occurs within the one-year period, you may return the instrument

to us for repair, provided we have your warranty registration information on ﬁle or

a proof of purchase. AEMC®Instruments will, at its option, repair or replace the

faulty material.

Warranty Repairs

What you must do to return an Instrument for Warranty Repair:

First, request a Customer Service Authorization Number (CSA#) by phone or by fax

from our Service Department (see address below), then return the instrument along

with the signed CSA Form. Please write the CSA# on the outside of the shipping

container. Return the instrument, postage or shipment pre-paid to:

Ship To: Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments

15 Faraday Drive

Dover, NH 03820 USA

Phone: (800) 945-2362 (Ext. 360)

(603) 749-6434 (Ext. 360)

Fax: (603) 742-2346 or (603) 749-6309

E-mail: [email protected]

Caution: To protect yourself against in-transit loss, we recommend you insure your

returned material.

You must obtain a CSA# before returning any instrument.

Otros manuales para PowerPad 8335

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Instrumento de medición de AEMC

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
