CONTENTS EN

Contents

1 INTRODUCTION ........................................................................................................................ 5

2 DESCRIPTION AND USE OF THE CONTROLS.................................................................. 7

2.1 Front panel................................................................................................................................... 7

2.2 Setting the washing program and switching on and o............................................ 8

2.2.1 Switching on .............................................................................................................................10

2.2.2 Selecting and starting the program.................................................................................10

2.2.3 End of program........................................................................................................................11

2.2.4 Interrupting a program.........................................................................................................11

2.2.5 Changing the current program..........................................................................................11

2.2.6 Canceling the current program..........................................................................................12

2.2.7 Options .......................................................................................................................................12

2.2.8 Switching o.............................................................................................................................14

2.3 Additional functions...............................................................................................................14

2.3.1 Adjusting the water softener..............................................................................................14

3 ENERGY SAVING AND ENVIRONMENTAL RESPECT ..................................................16

3.1 Reducing the consumption of detergent and respecting the environment.....16

4 REMOVING THE DISHES.......................................................................................................17

5 TROUBLESHOOTING .............................................................................................................18

4 Rev 0.0

Rev 0.0 5

INTRODUCTION EN

1 INTRODUCTION

Thank you for choosing one of our products. To use this dishwasher cor-

rectly and safely, please read this manual carefully. The manual is divided

into sections giving you a step-by-step guide to all your appliance’s func-

tions. The texts are easy to understand and are complete with detailed

illustrations. This user-friendly manual will provide answers to all your

questions about use of the dishwasher.

Before using this dishwasher, carefully read chapter 2 “Use and safety

warnings” of the attached general manual.

For any other information about use and maintenance of the dishwasher,

read the enclosed general manual carefully.

This manual comprises the following sections:

INTRODUCTION: general information about the manual.

USER INSTRUCTIONS: advice on using the washing programs and infor-

mation about all the dishwasher functions.

Nomenclature of gures and tables:

The progressive number of each gure is shown in the bottom right-hand

corner of the relative box. An example of a progressive number is “Fig.

4-01”, where the rst number (4) indicates the section to which the gure

belongs, while the second number (01) indicates the progressive number

of the gure in section 4 (Fig. 4-01 is the rst gure in section 4). The tables

are numbered in the same way, bearing in mind that “Tab.” is used instead

of “Fig.” (e.g.: Tab. 4-01 is the rst table in section 4). If a table occupies

more than one page, a letter is added after the progressive number (e.g.:

“Tab. 4-01a”, Tab. 4-01b”).

6 Rev 0.0

INTRODUCTION

Symbols used in this manual (see tab. 1-01)

DANGER. This symbol highlights information and warnings which, if not

observed, may compromise personal safety or damage the appliance.

This symbol highlights general information and warnings.

Tab. 1-01

Rev 0.0 7

USER INSTRUCTIONS EN

2 DESCRIPTION AND USE OF THE CONTROLS

2.1 Front panel

All the dishwasher controls are grouped on the front panel (see g. 2-01).

A brief description (see tab. 2-01) of the various elements on the front panel is

given below.

1326

SANITIZED

3h 6h 9h END

1 On/O button

2 Start/Pause button

3 Program selection button

4Program indicator lights

5Sanitation indicator light

6Program delay button

7Program delay indicator lights

8Recessed door handle

Tab. 2-01

Fig. 2-01

8 Rev 0.0

USER INSTRUCTIONS

Fig. 2-02

2.2 Setting the washing program and switching on

and o

The dishwasher is equipped with a control panel (see g. 2-02) which is used to

program the appliance and switch it on and o.

1326

SANITIZED

3h 6h 9h END

To select the most suitable program for the dishes to wash, consult the following

tables which specify the most appropriate type of washing sequence depending

on the kind of dishes and how dirty they are (see tab. 2-02).

Rev 0.0 9

USER INSTRUCTIONS EN

PROGRAM NUMBER

AND SYMBOL

DISHES AND

CUTLERY

PROGRAM

SEQUENCE

TIME CONSUMPTION

MINUTES

(1)

WATER POWER

KWh (1)

RINSE

PANS AND

DISHES WAITING

FOR THE

LOAD TO BE

COMPLETED

Cold pre-wash. 16’ 6.5 l

1.64 gal. 0.03

CRISTAL SLIGHTLY DIRTY

DISHES

Wash at 45°C

(113°F).

Cold rinse.

Rinse at 69°C

(156.2°F).

Dry.

66’ 13.7 l

3.62 gal. 0.6

NORMAL

SLIGHTLY DIRTY

PANS AND

DISHES BUT

WITH DRIED-ON

RESIDUE

Wash at 50°C

(122°F).

Cold rinse.

Rinse at 68°C

(154.4°F).

Dry.

110’ 14 l

3.67 gal. 0.8

DAILY

WASH

DIRTY PANS

AND DISHES

WITH DRIED-ON

RESIDUE

Cold pre-wash.

Wash at 65°C

(149°F).

Cold rinse.

Rinse at 69°C

(156.2°F).

Dry.

100’ 18.2 l

4.8 gal. 0.85

EXTREME

WASH

ETL SANITATION

LISTED

VERY DIRTY

PANS AND

DISHES WITH

DRIED-ON

RESIDUE

Pre-wash at 45°C

(113°F).

Wash at 70°C

(158°F).

2 cold rinses.

Rinse at 70°C

(158°F).

Dry.

117’ 22 l

5.8 gal. 0.98

Tab. 2-02

(1) The cycle times listed in the use and care manual are based on normal soil loads and 120°F (49°C)

incoming water and will vary based on your actual conditions.

- Only “EXTREME WASH” program conform to NSF std 184 and is certied by INTERTEK with the ETL

SANITATION LISTED.

- When the “Sanitized” light shine it means that the dishwasher and its contents have been sanitized

according to the requirements of the National Sanitation Foundation (NSF).

10 Rev 0.0

USER INSTRUCTIONS

Only run a soak program with half loads.

After using the above table to choose the most suitable washing cycle, program

the appliance.

Before starting a washing program, make sure that:

The water supply tap is• open.

There is regenerating salt• in the water softener tank (to add salt,

see the instructions in the general manual).

The correct amount of detergent• has been added to the dispens-

er (to add detergent, see the instructions in the general manual).

The spray arms are able to rotate• freely and without obstruction.

The racks have been• correctly loaded (see the instructions in the

general manual).

The dishwasher door• is securely closed.

2.2.1 Switching on

Press on/o (ref. 1 g. 2-02) to start the dishwasher; the indicator lights show the

“status”of the dishwasher.

2.2.2 Selecting and starting the program

Programming operations can only be performed with the door closed.

With the door open, the program indicator lights (ref. 4 g. 2-02) remain

o.

Press the program• selection button (ref. 3 g. 2-02) several times until the indi-

cator light corresponding to the required program turns on (ref. 4 g. 2-02);

if necessary, press the relative buttons to select the complementary functions•

you wish to use (e.g.“Programming delay”);

to start the dishwasher, press the• start/pause button (ref. 2 g. 2-02) for a few

seconds until the indicator light of the selected program starts ashing (con-

rmation beep);

Program status is indicated by the indicator light ashing throughout the•

cycle.

If the door of the dishwasher has not been closed or has been incorrectly

closed, the washing cycle will not begin.
