User Guide
ARE H9
Full-ISO
Pocket Reader
---------------------------------------------------------------2/36-------------------------------------------------------------
1 INTRODUCTION 4
2 ELEMENTS OF THE ARE H9 5
3 OPERATION GUIDE 6
3.1 Installat on of the battery 6
3.2 Power on / off 6
3.3 Read ng a transponder n standard mode 7
3.4 Read ng Range 8
4 DATABASE 9
5 MENU FUNCTIONS 9
5.1 Nav gat ng the trough the menu funct on 9
5.2 Overv ew of the menu funct ons 10
5.3 Set Attr bute 11
5.4 Operat ng mode 12
5.4.1 Standard mode 12
5.4.2 Online/USB **) or Online/B *) mode 12
5.4.3 Online/USB H or Online/B H*) mode – handshake mode 14
5.4.4 Database/USB or Database/B *) mode. 15
5.5 Set Interface /Bluetooth Select on (only w th opt onal Bluetooth-module) 16
5.5.1 Interface USB **) 16
5.5.2 Set Interface to Bluetooth Slave 17
5.5.3 Set Interface to Bluetooth Master 18
5.5.4 Bluetooth Disconnect 20
5.6 Lock Up Reader 20
5.7 Set Code Format 21
5.8 Erase Memory 22
5.9 Read ng t me 23
5.10 Turn-off t me 23
---------------------------------------------------------------3/36-------------------------------------------------------------
5.11 Turn-on delay 24
5.12 Keyboard Sound 24
5.13 Set T me (ava lable only w th Real-T me-Clock module expans on) 25
5.14 Set Date (ava lable only w th Real-T me-Clock module expans on) 26
5.15 Language/Sprache – select d splay language 27
5.16 Reader-Vers on 27
6 USB DRIVER INSTALLATION *) ***) 27
6.1 V rtual RS232 Com Port 30
6.2 COM Port Setup w th W ndows Dev ce Manager 30
7 USB INTERFACE CONFIGURATION USED IN ONLINE AND DATABASE
MODE 33
8 RS232 INTERFACE SETTINGS **) 33
9 CONTROL CHARACTERS USED IN THE ONLINE MODE 33
10 TECHNICAL SPECIFICATIONS 34
11 OPERATION WITH OTHER RF ID EQUIPMENT 34
12 SAFETY INSTRUCTION 35
13 FCC INFORMATION 35
14 NOTIFICATION OF CHANGES 36
15 CONTACTS 36
---------------------------------------------------------------4/36-------------------------------------------------------------
1Introduction
he ARE H9 is a RFID Pocket Reader designed to read passive Read-Only- ransponder. It has the ability to
store the ransponder-Codes in its internal database.
his Pocket Reader is equipped with a USB Interface **), which allows transmitting single transponder codes
or its entire database to a computer.
It is especially suitable for animal identification, logistics and asset tracking
he ARE H9 Full-ISO is capable to read the following transponder types:
•FDX-B Read-Only(according to ISO 11784/11785)
•HDX-B Read-Only(according to ISO 11784/11785)
•rovan
•PSK1
•ASK64bit
he ARE H9 does not synchronize with other RFID readers operating in close vicinity.
Before the initial use of this ARE H9 reader please study this manual carefully.
**) RS232 Interface in Rs232 version
---------------------------------------------------------------5/36-------------------------------------------------------------
2Elements of the ARE H9
2x16 Character
LCD-Display
Menu Options Buttons
(left, menu, right)
USB Connector **)
Main Button
(read, select)
Battery
Compartment
Antenna
Position
**) RS232 cable in Rs232 version
---------------------------------------------------------------6/36-------------------------------------------------------------
3Operation Guide
3.1 Installation of the battery
Slide door of the battery compartment to open it.
Attach the Battery to the connector inside. Put the Battery into the compartment.
9V Block
Battery
Battery-clip
-
+
Slide the door back to close it. Use only 9V E-Block alkaline Batteries of the ype 6LR61.
3.2 Power on / off
he Pocket Reader is switched on by pressing the main button for 0,5s (default). he reader starts
in reading mode.
he ARE H9 will switch off automatically after 20s (default) when no button has been pressed
within this time.
---------------------------------------------------------------7/36-------------------------------------------------------------
3.3 Reading a transponder in standard mode
Press the main button to start the reading process.
he ARE H9 starts the reading process and the display shows:
0 of 2016
Scanning Nr. 1
actual
count
maximum
count
Approach a transponder within the readers reading range.
he reader emits a beep when the transponder has been read successfully, and the transponder
code is shown on the display:
969 0000000001024
1 12
Country-Code ID
Retagging Counter and User Information
For ISO ransponder additional the retagging counter and the user information field are displayed
in the second row of the display.
In case no transponder has been read within the given time frame, the reader stops its reading
process and the display shows:
--- No Tag ---
For further reading processes release the main button and press it again for each attempt.
---------------------------------------------------------------8/36-------------------------------------------------------------
3.4 Reading Range
he reading range and distance depends on the transponder, its packaging and orientation to the
reader. he following diagram shows the typical area where a glass transponder should be read:
he ARE H 9 is not capable to read two or more transponders which are at the same time in the
antenna field.
---------------------------------------------------------------9/36-------------------------------------------------------------
4Database
When a reading had been accomplished successfully, in the standard operating mode, the ARE H9
internal database will be checked whether this transponder code is already stored.
If the new code, in combination with the attribute, is not found in the database, it will be stored as
a new record. his record is composed of the ID-code, the transponder type, the selected attribute.
With the optional real time clock module date and time of reading will be also stored.
If the new code is already stored in the database, it will be not stored again. In this case the reader
emits 2 successive beeps.
he database is capable to store up to 2016 transponder codes. When the maximum of the storage
is reached no further new code is stored. o store new codes in this case the database has to be
erased.
he database of the ARE H9 with all its actual records could be transmitted to a PC; also it is
possible to receive a new database from a PC. his is done in the Database/USB mode described in
chapter 5.4.4. On Power Loss the ARE H9 will keep its database data.
Menu Functions
5.1 Navigating the trough the menu function
By pressing the menu button it can be chosen between the different menu function.
If the menu button is pressed again the ARE H9 cyclic changes to the next menu function.
Inside a menu function the setting for the function could be changed with the arrow buttons.
With the main button the actual menu function setting is selected and the ARE H9 changes back to
the transponder reading mode.
---------------------------------------------------------------10/36-------------------------------------------------------------
5.2 Overview of the menu functions
Press both arrow
buttons to erase
database memory
+ 0.5 s
- 0.5 s
+ 5 s
- 5 s
+ 0.5 s
- 0.5 s
Press the main
button to select
actual menu option
... ...
Set Code Format
ISO Animal
Set Code Format
ISO Industry
Set Code Format
BDE-Format
Lock Up Reader
Lock
Lock Up Reader
Unlocked
Operating Mode
Standard
Operating Mode
Online/USB
Operating Mode
Datenbank/USB
Set Attribute
#
Set Attribute
A
Set Attribute
Z
--- No Tag ---
Erase DB-Memory
Confirm ?
Reading Time
2.0 s
Turn-Off Time
20 s
Turn-On Delay
0.5 s
Keyboard Sound
Off
Keyboard Sound
On
Set Time
12:00:00
Set Date
01 Jan '10
01 Jan '10
12:00:00
ava lable only w th
Real-T me-Clock
module
ava lable only w th Real-
T me-Clock module
Set Code Format
ISO Attributs
Set Code Format
Hexadecimal
AEG ID - ARE H9
V3.00200
Language/Sprache
Deutsch
Language/Sprache
English
ava lable only w th
opt onal Bluetooth
module
Operating Mode
Online/USB H
Set Interface
USB
Set Interface
Bluet. Slave
Set Interface
Bluet. Master
