Montage- und Gebrauchsanweisung

Installatie- en gebruiksaanwijzing

Notice d utilisation et d installation

Operating and Installation Instructions

Contents

Safety warnings ..............................................................................64

For the user ......................................................................................64

For the installer ................................................................................. 65

Description of the Appliance .........................................................67

Extraction mode ...............................................................................67

Recirculation mode ...........................................................................67

Control Panel DD 8990 ............................................................68 71

Control Panel DD 8861 8891 8821 ..........................................70 71

Control Panel DD 8695 8665 8625 .........................................72 73

Maintenance and Care ...................................................................74

Cleaning the hood ............................................................................ 74

Metal grease filter .............................................................................74

Charcoal filter ...................................................................................75

Changing the light bulb .....................................................................76

What to do if ...................................................................................77

Special accessories........................................................................77

Technical assistance service .........................................................78

Service and Spare Parts ................................................................... 78

Customer Care Department .............................................................79

Technical Details ............................................................................79

Mounting accessories included.........................................................79

Electrical connection .....................................................................80

Wall unit mounting ............................................................................81

Safety warnings

For the user

 The cooker hood is designed to extract unpleasant odours from the

kitchen, it will not extract steam.

 Always cover lighted elements, to prevent excess heat from

damaging the appliance. In the case of oil, gas and coal fired

cookers it is essential to avoid open flames.

 Also, when frying, keep the deep frying pan on the cooker top/

cooker under careful control.

 The hot oil in the frying pan might ignite due to overheating.

 The risk of self-ignition increases when the oil being used is dirty.

 It is extremely important to note that overheating can cause a fire.

Never carry out any flambé cooking under the hood.

Always disconnect the unit from the power supply before

carrying out any work on the hood, including replacing the light

bulb (take the cartridge fuse out of the fuse holder or switch off the

automatic circuit breaker).

It is very important to clean the hood and replace the filter at

the recommended intervals. Failure to do so could cause

grease deposits to build up, resulting in a fire hazard.

 The appliance is not intended for use by young children or infirm

persons without supervision.

 Older children must be supervised if using the appliance.

 Young children should be supervised to ensure that they do not play

with the appliance.

 WARNING Ensure that the appliance is switched off before

replacing the lamp to avoid the possibility of electric shock.

This appliance is marked according to the European directive 2002/96/

EC on Waste Electrical and Electronic Equipment (WEEE).

By ensuring this product is disposed of correctly, you will help prevent

potential negative consequences for the environment and human

health, which could otherwise be caused by inappropriate waste

handling of this product.

The symbol on the product, or on the documents accompanying

the product, indicates that this appliance may not be treated as

household waste. Instead it shall be handed over to the applicable

collection point for the recycling of electrical and electronic equipment.

Disposal must be carried out in accordance with local environmental

regulations for waste disposal.

For more detailed information about treatment, recovery and recycling

of this product, please contact your local city office, your household

waste disposal service or the shop where you purchased the product.

For the insta er

 When used as an extractor unit, the hood must be fitted with a

150mm diameter hose.

 Should there already be a pipe of diameter 125 or 120 mm that

ducts to the outside through the walls, it is possible to use the 150/

125-120 mm reduction flange provided.

In this case the hood will be slightly noisier.

 When installing the hood, make sure you observe the following

minimum distance from the top edge of the cooking hob/ring

surfaces:

electric cookers 500 mm

gas cookers 650 mm

If the instructions for installation for the gas hob specify a greater

distance, this must be adhered to.

 The national Standard on fuel-burning systems specifies a maximum

depression of 0.04 mbar in such rooms.

 The air outlet must not be connected to chimney flues or combustion

gas ducts. The air outlet must under no circumstances be connected

to ventilation ducts for rooms in which fuel-burning appliances are

installed.

 The air outlet installation must comply with the regulations laid down

by the relevant local authorities.

 When the unit is used in extraction mode, a sufficiently large

ventilation hole must be provided, with dimensions that are approxi-

mately the same as the outlet hole.

 National and regional building regulations impose a number of

restrictions on using hoods and fuel-burning appliances connected

to a chimney, such as coal or oil room-heaters and gas fires, in the

same room.

 Hoods can only be used safely with appliances connected to a

chimney if the room and/or flat (air/environment combination) is

ventilated from outside using a suitable ventilation hole approxi-

mately 500-600 cm2 large to avoid the possibility of a depression

being created during operation of the hood.

 If you have any doubts, contact the relevant controlling authority or

building inspectors office.

 Since the rule for rooms with fuel burning appliances is outlet hole

of the same size as the ventilation hole, a hole of 500-600 cm2,

which is to say a larger hole, could reduce the performance of the

extractor hood.

 If the hood is used in its recirculation mode, it will operate simply and

safely in the above conditions without the need for any of the

aforementioned measures.

 When the hood is used in its extraction mode, the following rules

must be followed to obtain optimal operation:

- short and straight outlet hose

- keep bends in outlet hose to a minimum

- never install the hoses with an acute angle, they must always

follow a gentle curve.

- keep the hose as large as possible (preferably the same diameter

as the outlet hole).

- the length should be no more than:

3 metres with one 90° bend

2 metres with two 90° bends

Bends of more than 90° will reduce the efficiency of the hood and

reduce the airflow.

 Failure to observe these basic instructions will drastically reduce the

performance and increase the noise levels of the extractor hood.

Fig. 1

Description of the Appliance

The cooker hood is designed to extract unpleasant odours from

the kitchen, it will not extract steam.

 The hood is supplied as an extractor unit and can also be used with

a recirculation mode by fitting a charcoal filter.

 In some models the charcoal filter is supplied. The hood, therefore,

can be used immediately in the recirculation mode. We advise

removing the charcoal filter to use the hood in the extraction mode.

Extraction mode

 In this mode fumes are extracted to the outside via a hose

connected to the coupling ring A. Fig. 1.

 In order to obtain the best performance the hose should have a

diameter equal to the outlet hole.

Should there already be a pipe of diameter 125 or 120 mm that

ducts to the outside through the walls, it is possible to use the 150/

125-120 mm reduction flange provided.

In this case the hood will be slightly noisier.

Recircu ation mode

 The air is filtered through a charcoal filter and returned to the

kitchen.

 You will need an original charcoal filter for the recirculation mode.

(See Special Accessories).

Control Panel

- DD 8990

 Best results are obtained by using a low speed for normal conditions

and a high speed when odours are more concentrated.

Turn the hood on a few minutes before you start cooking.

The hood should be left on after cooking for about 15 minutes or

until all the odours have disappeared.

The control switches are located on the hoods front panel:

1- ON (stand-by - illuminated key) / OFF switch.

Press once or more to obtain the function desired:

Stand-by (dot "b" on the display is illuminated): the hood is ready

to function, the safety procedure is activated (see next page 

Safety procedure).

OFF: all the functions are switched off except the illumination.

2- Light ON/OFF

3- Display

4-Manual(stand by)/Automatic (sensors Led S will illuminate).

Press once to switch ON the Automatic mode, press again to

switch OFF (stand-by / Manual mode).

Automatic function:

The hood switch ON (extraction) on the basis of the change in the

normal environmental conditions that the hood notices through

its sensors (see next page  Sensor test) .

The leds of the display will turn on alternatively in proportion to the

suction power setting.

Attention! The hood is equipped with an automatic system that

establishes what the normal environmental conditions are.

In the case of abnormal operation, calibration can be carried out

automatically or manually (see next page  Automatic

calibration and Manual calibration).

5- Start and choice of motor speed 1-2-3-1-2.........

6- Intensive speed on/off. The Intensive speed runs for 5 minutes:

If the hood is on when the Intensive speed is activated, the hood

will revert to previous speed after 5 minutes.

If the hood is off when the Intensive speed is activated, the hood

12 6

Fig. 2

will automatically turn off after 5 minutes.

To interrupt the Intensive speed, press button 1 or 6.

The letter P appears on the display and the remaining time (the

point a is flashing), if interrupted an acoustic signal is heard.

7- Self-Timer: times all the speed levels (the point b is flashing),

and then the cooker hood switches off:

The self-timer is set as follows:

1st speed level 20 minutes

2nd speed level 15 minutes

3rd speed level 10 minutes

P (intensive) speed level: 5 minutes

The display shows the remaining operation time, at the end of the

time an acoustic signal is heard. Depressing the push-button

again exits the function.

Automatic Sensor calibration:

The automatic calibration is carried on by the hood itself every 30

minutes.

When the hood is installed for the first time or the power is cut off

for many hours or days, please wait 30 minutes before the use or

make a manual calibration.

Manual Sensor calibration

Carry out calibration with the hob off, at normal ambient room

temperature and in the absence of an appreciable amount of

steam:

- press switch 4 for about 3secs , then press switch 1, the hood

emits a sound signal to indicate calibration taking place.

Sensors test

When functioning in Automatic mode, the system continuously

tests the efficiency of the sensors. In case of a fault the display

shows 88. Contact your local Service Force Centre.

In this situation the hood can, in any case, be used in the manual

mode.

Safety procedure

Self-activation of Automatic (SAFETY) mode:

if the sensors reveal an excessive increase in temperature,

even if the hood is in Manual mode, the system self selects the

Automatic mode and the hood selects the necessary speed.

The hood can be turned off by pressing push switch 1.

Should the hood or the controls fail to operate: disconnect the power

supply for at least 5 seconds.

After reconnecting the power supply wait 15 seconds and then check

that the cooker hood is now operating correctly.

Control Panel

- DD 8861-8891-8821

 Best results are obtained by using a low speed for normal conditions

and a high speed when odours are more concentrated.

Turn the hood on a few minutes before you start cooking.

The hood should be left on after cooking for about 15 minutes or

until all the odours have disappeared.

The control switches are located on the hoods front panel:

1- Mains switch, ON/OFF

Press for less than 1 1/2 seconds and the cooker hood goes into

the "stand by" position (point "b" is illuminated).

Press for more than 1 1/2 seconds and the cooker hood turns off,

ALL the controls (except the light push button) are disabled (the

display is off).

Press again for more than 1 1/2 seconds to reset the cooker

hood to "stand by".

2- Light ON/OFF

3- Display

4- Start and choice of motor speed 1-2-3-1-2.........

5- Intensive speed on/off. The Intensive speed runs for 5 minutes:

If the hood is on when the Intensive speed is activated, the hood

will revert to previous speed after 5 minutes.

If the hood is off when the Intensive speed is activated, the hood

will automatically turn off after 5 minutes.

To interrupt the Intensive speed, press button 1 or 5.

The letter P appears on the display and the remaining time (the

point a is flashing), if interrupted an acoustic signal is heard.

6- Self-Timer: times all the speed levels (the point b is flashing),

and then the cooker hood switches off:

The self-timer is set as follows: 1st speed level 20 minutes

2nd speed level 15 minutes

3rd speed level 10 minutes

The display shows the remaining operation time, at the end of the

time an acoustic signal is heard. Depressing the push-button

again exits the function.

Should the hood or the controls fail to operate: disconnect the power

supply for at least 5 seconds. After reconnecting the power supply wait

15 seconds and then check that the cooker hood is now operating

correctly.

123 456

Fig. 3

Grease and charcoa fi ter maintenance

indicator - DD 8990 - 8861 - 8891 - 8821

This hood is fitted with a device that indicates when it is necessary to

clean the grease filter or the charcoal filter (if the hood is used in the

recirculation version with a charcoal filter).

On delivery, the hood is not supplied with a charcoal filter, so the

saturation indicator will be disabled.

If the hood is to be used with a charcoal filter, the saturation

indicator light must be enabled as follows:

DD 8990 only: Set the hood in OFF.

Press buttons 4 and 5 simultaneously and hold them for 3 seconds. At

first only the grease filter LED F will light up, but when the charcoal

filter LED C lights up the saturation indicator will be enabled.

To disable it: Press buttons 4 and 5 again simultaneously and hold

them for 3 seconds, until the charcoal filter LED goes out.

Grease fi ter LED (F)

LED F will start to flash when it is time to clean the grease filter.

Cleaning will be necessary after 40 working hours. Always comply

with the maintenance instructions for the grease filter.

Charcoa fi ter LED (C)

The charcoal filter LED C will start to flash when the charcoal filter

needs to be replaced.

This operation is necessary after approximately 160 working hours.

Resetting the saturation indicator

After cleaning or replacing the filters, press button 1 for 3 seconds until

the grease filter LED F or the charcoal filter LED C stops flashing.

Este manual sirve para los siguientes modelos

Otros manuales de Campana de ventilación de AEG Electrolux

AEG Electrolux

AEG Electrolux DD6460-M Manual de usuario

AEG Electrolux

AEG Electrolux DD6660-M Manual de usuario

AEG Electrolux

AEG Electrolux DD 9864 Manual de usuario

AEG Electrolux

AEG Electrolux 502 D Hoja de especificaciones

AEG Electrolux

AEG Electrolux DD 8625 Manual de usuario

AEG Electrolux

AEG Electrolux HI 8610 Hoja de especificaciones

AEG Electrolux

AEG Electrolux DF7190 Manual de usuario

AEG Electrolux

AEG Electrolux DD 8696 Hoja de especificaciones

AEG Electrolux

AEG Electrolux Cooker hood Manual de usuario

AEG Electrolux

AEG Electrolux DI9814 Manual de usuario

AEG Electrolux

AEG Electrolux HD 8795 Hoja de especificaciones

AEG Electrolux

AEG Electrolux HC 3360 Guía del producto

AEG Electrolux

AEG Electrolux DD9996-B Manual de usuario

AEG Electrolux

AEG Electrolux DL8560-M Manual de usuario

AEG Electrolux

AEG Electrolux HE 3160 Hoja de especificaciones

AEG Electrolux

AEG Electrolux DU 4561 Hoja de especificaciones

AEG Electrolux

AEG Electrolux DI9611-M Manual de usuario

AEG Electrolux

AEG Electrolux DD 8793 Hoja de especificaciones

AEG Electrolux

AEG Electrolux DF7460 Hoja de especificaciones

AEG Electrolux

AEG Electrolux DD 8697 Hoja de especificaciones

AEG Electrolux

AEG Electrolux DU 4561 Manual de usuario

AEG Electrolux

AEG Electrolux DM8600 Manual de usuario

AEG Electrolux

AEG Electrolux DD8623 Hoja de especificaciones

Manuales populares de Campana de ventilación de otras marcas

emmeti

emmeti RECUPA MED A-140 Guía

Nibe

Nibe F135 Manual de usuario

Kuppersberg

Kuppersberg INTRO 60 Instrucciones de instalación y mantenimiento

Zephyr

Zephyr Spruce AK9834BS Guía de instalación

Hisense

Hisense MH6INBG Manual de usuario

Miele

Miele DA 1255 Manual de usuario

Broan

Broan 46000 Manual de usuario

GE Profile PV977 Instrucciones originales

FALMEC

FALMEC FFRIA24W5FS Manual de usuario

Whirlpool

Whirlpool RH2600XL-1 SERIES Manual de usuario

Küppersbusch

Küppersbusch DX ISLA Manual de usuario

ETNA

ETNA AV360RVS Manual de usuario

JUNO

JUNO JDF603E6 Manual de usuario

Miele

Miele DA 6708 D Manual de usuario

Tricity Bendix

Tricity Bendix LE 150 Manual

AEG

AEG X68163BV1 Manual de usuario

AEG

AEG 125 D Manual de usuario

Smeg

Smeg KSEV97X Manual de usuario
