Owner’s Manual

iFly 700™

Contents

Overview

Package Contents ................................................. 3

Features ................................................................ 3

Warnings .......................................................... 4

GPS and Source Data Notes ........................... 4

General Notes .................................................. 4

Mounting on a Windscreen ............................ 6

Connecting to Power ....................................... 6

Powering On ................................................... 6

Updating your iFly 700 ......................................... 7

Main Display ........................................................ 8

Using the Touch-Screen ........................................ 9

Panning ........................................................... 9

Activating Buttons .......................................... 9

Button Fading ............................................ 9

Switching Sectionals ...................................... 9

Markers ........................................................... 9

Menus and Screens

Main Menu .......................................................... 10

Find Nearest... Menu ..................................... 10

Setup Menu .....................................................11

Instrument Setup Form ............................ 13

Custom Locations Menu ............................... 13

Custom Locations Form ........................... 13

About Menu ................................................... 14

GPS Overview Screen .............................. 14

Mode Menu ......................................................... 15

Possible Actions Menu ....................................... 16

Airport Information Screen ................................ 17

Plate Viewer Screen ....................................... 18

Flight Planning

Flight Planning Options ..................................... 19

Option #1: Create a point-to-point plan by

touching the screen ...................................... 20

Option #2: Find an airport by code or

keyword .......................................................... 21

Fly Direct To Screen .................................. 21

Option #3: Use the Flight Planner ................ 22

Option #4: Rubber-band route

modiﬁcation ................................................... 24

Airspace Info Form ........................................ 25

Airspace Display Levels ........................... 25

Altitude Planning ........................................... 26

Airspace Alerts .............................................. 27

Extra Features

Using the Remote Control ................................. 28

System Menu ...................................................... 29

Transferring Media Files to Your iFly 700 ..... 30

Video Player Optimal Settings ................. 30

Transferring Audio and Video Files to

the Play List ............................................... 31

Using the Multimedia Player ........................ 32

Using the Video Player .................................. 33

Using the Image Viewer ................................ 33

Changing Conﬁguration Settings ................. 34

Using the Clock .............................................. 35

Using the Text Viewer .................................... 35

Using the Memo Screen ............................... 36

Using the Calculator ...................................... 36

Playing the Card Game ................................. 37

Using an External Audio/Video (AV) Device ... 37

Using an External Camera ............................ 38

Using NMEA Output ...................................... 38

Additional Information

Frequently Asked Questions .............................. 39

Speciﬁcations ...................................................... 40

FCC Information .................................................. 40

Limited Warranty................................................. 41

Features

Interface

Extensive zoom levels from 2 to 100 NM per inch

Touch-n-drag scrolling, works even in turbulence

Single-touch zoom in/out

Center and auto-track with a single touch

“View Charts” button switches between

bordering sectionals at a single touch

Night Mode darkens and inverts colors at night

Plug-and-ﬂy autopilot capability

Spatial Awareness

Pre-loaded with FAA published sectionals, charts,

plates and more

Critical and important airspaces are highlighted

and shaded

Reference distance and bearing to any point on

the chart with a single touch of the screen

“Find Airport” button shows a list of the nearest

airports with immediate navigational aids such as

distance, turn, and ETE

Distance rings around your current position

FAA published TFRs on all sectionals and charts

FAA Charts

Includes all sectionals, low enroute charts,

approach, and departure plates

Explore charts with touch-sensitive panning and

zooming

Reference actual FAA airport taxi diagrams;

includes alpha-numerics for cutoffs and parallels

“History” button toggles between charts,

previously viewed airport details, and plates

Sectionals and plates include all of the “Border”

and “Legend” data as shown on FAA charts

Simple update process at www.iﬂyGPS.com

Flight Planning

“Direct-to” ﬂight planning

Easily create multi-leg ﬂight plans directly from

the sectional or ﬂight planner

“Rubber-band” route line modiﬁcations (touch

and drag a route line to bend it around an

airspace)

Vertical speed to target for custom waypoints

with speciﬁc altitudes (a 3-D ﬂight plan)

Save/load/reverse ﬂight plans

Flight plan is automatically saved and restored

between power cycles

Search for airports by code, airport name, or city

name

Airport Information

Geographical data

Public and private airports

Attendance schedule

Communication information

Full runway information, including a thumbnail

with quick reference numbers

Trafﬁc patterns with pattern altitude (if published)

Available IFR equipment

Obstructions

Additional FAA remarks

Data Updates

Unlimited updates from any internet-connected

computer (with a low-cost annual data

subscription)

Quickly update the latest TFR and Metar data

prior to your ﬂight

Download software updates at www.iﬂyGPS.com

and always have the latest new features

Package Contents

iFly 700

Carrying Case

Window Mount

Remote Control

AC Adapter

Cigarette Lighter Adapter

SD Card

Quick Start Guide

Overview

Warnings

Carefully review this Owner’s Manual and make sure you thoroughly understand iFly 700’s functionality and

operation before attempting to use the unit during actual ﬂight.

Do not install the iFly 700 where it obstructs the pilot’s ﬁeld of view or interferes with operating controls.

The ﬂight indicators shown on the iFly 700 are based on GPS-derived data and may differ from the aircraft’s

instruments.

The altitude shown on the iFly 700 is geometric height above Mean Sea Level and may differ from the altitude

displayed by pressure altimeters. Always use the pressure altitude displayed by your aircraft’s altimeter for

determining aircraft altitude.

While ﬂying, compare indicators from the iFly 700 with other available navigation sources, including the

information from cockpit gauges, other NAVAIDs, visual sightings, charts, etc. Although unlikely, it is

possible for erroneous operation to occur with the iFly 700. It is the responsibility of the pilot to resolve any

discrepancies before continuing navigation.

GPS and Source Data Notes

The United States government operates the Global Positioning System (GPS) and is solely responsible for

its accuracy and maintenance. The GPS system is subject to changes which could affect the accuracy and

performance of the iFly 700.

Interference from GPS repeaters operating inside nearby hangars can cause an intermittent loss of altitude

and heading displays while the aircraft is on the ground.

The data contained in the terrain and obstacle databases comes from government agencies. Adventure Pilot

cannot guarantee the accuracy and completeness of the data.

Temporary Flight Restriction (TFR) data is provided by the FAA and may not be updated outside of normal business

hours. Conﬁrm data currency through alternate sources and contact your local FSS for interpretation of TFR.

Do not use outdated sectional maps. Sectionals must be updated regularly to ensure that the information is

accurate. Pilots using outdated sectionals do so at their own risk.

General Notes

Avoid using any chemical or abrasive cleaners on the touchscreen and/or plastic casing. Clean the

touchscreen with a soft, clean, lint-free cloth. Use water, isopropyl alcohol, or eyeglass cleaner, if needed.

The iFly 700 does not contain any user-serviceable parts. Repairs should only be made by an authorized

service center. Unauthorized repairs or modiﬁcations could void both the warranty and the pilot’s authority to

operate this device under FAA/FCC regulations.

All visual depictions contained within this document, including screen images, are subject to change and may

not reﬂect the most current iFly 700 GPS receiver. Depictions may differ slightly from the actual unit.

Use of polarized eye wear may cause the ﬂight displays to appear dim or blank.

Only use the power adapters provided with the iFly 700 or recommended by Adventure Pilot LLC.

Do not leave the iFly 700 in extremely high or low temperatures. Do not use in a humid environment or

submerge in water.

Do not place near magnets or large speakers. Do not put gold, metallic objects, or electric wave emitting

objects around the iFly 700.

Overview

Power Jack

Connect Cigarette Lighter Adapter or

AC Adapter

USB Port

Connect USB memory storage device

SD/MMC Memory Card Slot

• Included 4G SD card contains iFly 700

applications and data

• Card must be inserted for unit to

operate

• Do not remove or modify ﬁles

Headphone Jack

AV In – Connect external video or audio device

Camera – Connect an external camera (not provided)

(on back)

External GPS

Connector

Connect an external

GPS antenna (optional,

not included)

Unit Overview

Overview

Mounting on a Windscreen

1. Secure the suction cup to your aircraft’s windscreen.

2. Insert the end of the mounting arm into the keyhole slot on the back of the unit.

3. Tighten the knob closest to the keyhole clockwise until secure.

4. Tighten the next knob clockwise to further secure the unit from vibrating loose.

5. Loosen the two arm adjustment knobs, position the unit as desired, and re-tighten the arm adjustment knobs.

Notes:

• Do not install the iFly 700 where it obstructs your ﬁeld of view or interferes with operating controls.

• After installation, make sure the unit is ﬁrmly secured.

Connecting to Power

For use in your aircraft, connect the barrel end of the

included cigarette lighter adapter into the jack of the

iFly 700. Plug the other end into a DC 12–28V cigarette

lighter (accessory power port).

For use indoors, connect the barrel end of the included

AC adapter into the DC-12V jack of the iFly 700. Plug

the other end into a standard household outlet.

Powering On

1. The unit automatically turns on when connected to

power.

2. The Home Screen is displayed during

initialization while the iFly 700 collects

satellite data and establishes its present

location.

3. After initialization, a dialog box appears

containing safety warnings, and if

applicable, TFR and sectional expiration.

Touch “More info on expired sectionals”

to view the Sectional Information dialog

box.

Touch”I have read and understand these

warnings” to continue.

4. The sectional map of your location is

displayed with an icon representing

your aircraft shown in the center of the

screen.

-or -

Overview

Updating your iFly 700

The iFly 700 software, databases, and charts can be updated through the iFly 700 website. To perform the update

you will need: 1) a USB Flash Drive, 2) a login to the website, and 3) a valid update subscription.

The website is http://www.iFlyGPS.com.

If you do not have a login, create one by clicking the “Register” button at the top of the screen. Be sure to keep

your login and password in a safe location. Once registered, it will be necessary to link your new iFly 700 with

your account.

If your purchase included a free trial subscription, activate it by selecting the “Updates / Active Free Trial” option

and entering your iFly 700 serial number and the activation code included with your purchase.

If your purchase did not include a free trial, you will need to purchase a subscription through the online store.

Performing the Update

1. Click the “Updates / Create Update Package” menu option on the website.

2. Insert a USB Flash Drive into your computer.

3. Using the checkboxes on the Updates page, select the items you would like to update.

Notes:

• It is not necessary to update every chart that expires; we recommend you only update data that is relative

to your ﬂights. (If you are planning a cross country trip that takes you into areas you don’t usually ﬂy, you

can download that data at any time prior to your ﬂight.)

• The ﬁrst three checkboxes in the list: “TFRs & METARS,” “Airport & Navaid Database, and “Software”

should always be updated when available.

4. Click the “Create Update Package” to create your update package. Depending on what you have selected,

this may take a few seconds or more than a minute.

5. When the package is created, you will be able to download the resulting ﬁle (called iFlyUpdatePackage.zip) to

your USB Flash Drive.

Note: This step varies greatly based on your computer’s hardware, operating system (OS) (Windows or

MAC), speciﬁc OS versions, USB Flash Drive type, and the browser you are using. Please consult your OS or

browser documentation to learn how to download ﬁles.

6. Eject or stop the USB Flash Drive.

Note: Do not pull the USB Flash Drive out of your computer without ﬁrst ejecting or stopping it. Consult

your OS documentation for information on how to eject or stop your USB Flash Drive. If this step is not

accomplished, the ﬁle may not be completely copied, and the update process will fail.

7. Insert the USB Flash Drive into the iFly 700, then select Menu  Check for Update File. The update

process will commence. Do not disconnect power or attempt to do anything else with the iFly 700 until the

update is complete.

Overview

Speed

Use Menu  Setup to toggle

between Miles, Kilometers,

and Nautical Miles

Track

The direction your aircraft

is moving relative to true

North

Altitude

Your altitude in feet

above sea level

calculated by GPS

Warning: Always

use your aircraft’s

pressure altimeter

to determine your

exact altitude

Opens the Main

Menu (see page 10)

Zoom In

Zoom in to read

map details

Zoom Out

Zoom out to view

surrounding areas

and airspaces

Follow Plane

Reposition your current location in

the center of the screen

Location Icon

Indicates your

current location on

the sectional

Mode

Select the map

mode (see page 15)

Find Airport

Shows a list of nearby

airports

Flight Plan

Shows the ﬂight planning

form (see page 22)

Navigation Instruments

Available when a ﬂight plan is active

(see page 19)

Main Display

North-up

Toggles the map display between North-up

and Track-up

• In North-up mode, the chart is always

oriented so that North is up.

• In Track-up mode, the chart is oriented so

that the plane is located at the bottom/

center of the map facing straight up and

the map will rotate as the airplane turns.

Note: If you pan the map, the orientation

will freeze. When you touch Follow

Plane to resume tracking the airplane,

the map will again rotate to maintain

track-up orientation.

History

Shows a list of

Manuales populares de GPS de otras marcas

Raven

Raven Cruizer II Manual

Hama

Hama 53118 Manual de usuario

Garmin

Garmin SOUNDER 125 Manual de usuario

Garmin

Garmin DEZL 580 Manual de usuario

Jigabot

Jigabot EX Manual de usuario

Pointer

Pointer Cellocator CelloTrack XT LTE Guía de instalación

Queclink

Queclink GV55LITE Manual de usuario

Voxson

Voxson Voxtrack GPS500 Manual de instrucciones

Garmin

Garmin ECHOMAP PLUS Manual de usuario

Starcom Systems

Starcom Systems Kylos Compact Manual de usuario

Garmin

Garmin 15 H Series Manual de usuario

Cobra

Cobra Marine MC 600Ci Manual de usuario

Cellocator

Cellocator CelloTrack T Manual de usuario

Enfora

Enfora Mini-MT GSM2228UG001 Manual de usuario

Magellan

Magellan eXplorist 100 Manual de usuario

LTE

LTE G50B Manual de usuario

Garmin

Garmin DEZL OTR500 Manual de usuario

SkyGolf

SkyGolf SkyCaddie SG1 Manual de usuario

Adventure Pilot iFly 700 Manual de usuario

Manuales populares de GPS de otras marcas
