Advantech AIMB-270 Manual de instalación y operación

AIMB-270 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

AIMB-270 Intel®Core™ i7/i5/Celeron®μFC-PGA989

Mini-ITX motherboard

SATA HDD cable x 2

SATA Power cable x 2

CPU cooler x1

Cable kit for 4 serial ports x 1

I/O port bracket x 1

Startup manual x 1

Driver CD x 1

Warranty card x 1

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF ﬁle.

Acrobat Reader can be downloaded at:

www.adobe.com/Prodindex/acrobat/readstep.html (Acrobat

is a trademark of Adobe).

AIMB-270 (Intel

Core™ i7/i5/Celeron

μFC-PGA989

Mini-ITX with VGA/2DVI/LVDS, 6 COM, Dual LAN,

PCIe x 16)

Startup Manual

Standard SBC functions

CPU: Supports Intel®Core™ i7/i5/Celeron®μFC-PGA989

CPU

BIOS: AMI EFI 64 Mbit SPI

Chipset: Intel®QM57 Chipset

System memory: Up to 8 GB in two 204-pin SODIMM

sockets. Supports DDR3 800/1066 SDRAM.

Note: Due to the inherent limitations of PC architecture, the

system may not fully detect 8 GB RAM when 8

GB RAM is installed.

SATA2 Interface: Four on-board Serial ATA2 connec-

tors with a data transmission rate of up to 300 MB/s

supporting Advanced Host Controller Interface (AHCI)

technology

Serial ports: Six serial ports

Keyboard/mouse connector: Supports standard PS/2

keyboard and mouse

Watchdog timer: 1~255 level timer intervals

USB 2.0: Supports up to eight USB 2.0 ports

Graphic Interface

Chipset: Supports Intel®HD Graphics, Intel mobile

Core™i7-600, Core™i5-500 and Celeron®CPUs are

embedded with integrated graphics

Display Memory: 1GB maximum shared memory with

2GB and above system memory installed

Resolution: Supports DVI up to resolution 1920 x 1200

@ 60Hz refresh rate Supports VGA up to resolution

2048 x 1536 @ 75Hz refresh rate and single channel

18/24-bit/Dual channel 36/48-bit LVDS, supports max

resolution 1920 x 1200

Ethernet Interface

Interface: 10/100/1000 Mbps

Controller: LAN1: Intel 82577LM; LAN2: Intel®82583V

Mechanical and Environmental

Dimensions (L x W): 170 x 170 mm

Power supply voltage: +3.3 V, +5 V, ±12 V, 5 Vsb

Power requirements:

Intel®Core i5-520M 2.4 GHz, 3 MB L2 cache, 2 pcs 4 GB

DDR3 1066 MHz, +5 V @ 3.42 A, +3.3 V @ 1.1 A, +12 V

@ 1.19 A, 5 VSB @ 0.5 A, -12 V @ 0 A

Measure the maximum current value which system under

maximum load (CPU: Top speed, RAM & Graphic: Full

loading)

Operating temperature: 0 ~ 60° C

Weight: 0.365 kg (weight of board)

•

Specications

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://www.advantech.com/support

This manual is for the AIMB-270 series Rev.A1.

Part No. 2002027011

Printed in China

2nd Edition,

November 2010

2 AIMB-270 Startup Manual

The board has a number of connectors and jumpers that

help conﬁgure the system to suit your application require-

ments. The tables below list the functions of the connectors

and jumpers.

Label Function

JFP1 Power switch/HDD LED/SMBus/

Speaker

JFP2 Power LED and Keyboard lock

CMOS1 CMOS clear ( Default 1-2 )

PSON1 AT(1-2) / ATX(2-3) ( Default 2-3 )

JWDT1+JOBS1 Watchdog Reset and OBS Alarm

JCASE1 Case Open pin header

JLVDS1 Voltage 3.3 V / 5 V selector for LVDS1

connector(Default 1-2, 3.3 V)

JLVDS2 Voltage 12 V selector for LVDS1 and

LVDS2 connector

LVDS1 LVDS1 connector

INV1 LVDS1 inverter connector

JLVDS_CLT1 Brightness control selector for Analog

or Digital (Default 1-2, Analog)

JWE1 Jumper for update BIOS ME mode

COM3456 Serials port connector (RS-232)

USB56 USB port 5, 6 (on board)

USB78 USB port 7, 8 (on board)

VGA1+DVI1 VGA and DVI connector

COM12 Serial port connector(RS232)

KBMS1 PS/2 Keyboard and Mouse connector

CPUFAN1 CPU FAN connector(4-pin)

SYSFAN1 System FAN1 connector(4-pin)

SYSFAN2 System FAN2 connector(4-pin)

LAN1_USB12 LAN1 / USB port 1, 2

LAN2_USB34 LAN2 / USB port 3, 4

AUDIO1 Audio connector

SPDIF_OUT1 SPDIF Audio out pin header

FPAUD1 HD Audio Front Panel Pin Header

PCIEX16_1 PCIe x16 Slot

SATA1 Serial ATA data connector 1

SATA2 Serial ATA data connector 2

SATA3 Serial ATA data connector 3

SATA4 Serial ATA data connector 4

DIMM1 Memory connector channel

DIMM2 Memory connector channel

SPI_CN1 SPI ﬂash update connector

GPIO1 GPIO header

EATXPWR2 ATX 12 V Auxiliary power connector

(for CPU)

EATXPWR1 ATX 20 Pin Main power connector (for

System)

CMOS1: Clear CMOS

Pins Result

1-2*

Keep CMOS data*

2-3 Clear CMOS data

* Default

PSON1: ATX, AT Mode Selector

Closed Pins Result

1-2

AT Mode

2-3* ATX Mode*

* Default

AT Mode ATX Mode

1-2 closed 2-3 closed

JWDT1: Watchdog Timer Output Option

Closed Pins Result

1-2

NC (Watchdog Timer Disabled)

2-3* System reset* (Reset System when Watch-

dog Timer Triggered)

* Default

Keep CMOS data Clear CMOS

Jumpers and Connectors

NC 1-2 Closed System Reset 2-3 Closed

3 6 9 12

2 5 8 11

1 4 7 10

1 2 3 4 5

AIMB-270 Startup Manual 3

JLVDS1 and JLVDS2: Voltage 3.3 V / 5 V / 12 V selec-

tor connector

Closed Pins Result

JLVDS1

1-2* For 3.3 V LVDS Panel

2-3

For 5 V LVDS Panel

JLVDS1 and JLVDS2

2-2

For 12 V LVDS Panel

* Default

JFP1+JFP2

Pin.3

#PWR_SW

Pin.6 GND

Pin.9

#RST_SW

Pin.12 GND

*Power button pins are numbers 3 & 6 of front panel con-

nector.

Installation Note

Software Installation

CAUTION

Jumpers and Connectors

Declaration of Conformity

The device complies with the requirements in Part 15 of

the FCC rules. Operation is subject to the following two

conditions:

This device may not cause harmful interference;

This device must accept any interference received,

including interference that may cause undesired opera-

tion.

The CD disc contains a driver installer program that will lead

you through the installation as various device drivers are

needed to take full advantage of your motherboard.

The computer is supplied with a battery-powered real-time

clock circuit. There is a danger of explosion if the battery is

incorrectly replaced. Replace only with same or equivalent

type recommended by the manufacturer. Discard used bat-

teries according to manufacturer’s instructions.

JLVDS2

JLVDS1

JLVDS2

JLVDS1

JLVDS2

JLVDS1

for 3.3V LVDS panel

for 5V LVDS panel

for 12V LVDS panel

JFP1

JFP2

1 53

COM3456

DIMM1 DIMM2

GPIO1

JCASE1

EATXPWR1

LVDS1

JLVDS2

JFP1

JFP2

CMOS1

JWE1

SPI_CN1

JWDT1 + JOBS1

JLVDS_CLT1

JLVDS1

INV1

USB78

CPUFAN1

SYSFAN1

SYSFAN2

EATXPWR2

PCIEX16_1

SATA3

SATA4

SATA2 SATA1

FPAUD1

USB56

SPDIF_OUT1

PSON1

AUDIO1

LAN2

USB34

VGA1

DVI1

LAN1

USB12 COM12 KBMS1

JFP1

JFP2

JFP1

JFP2

3 6 9 12

PWRSW RESET

12345

2 5 8 11

1 4 7 10

KEYLOCK & PWRLED

SPEAKER

HDDLED SM_BUS

4 AIMB-270 Startup Manual

Board Diagram
