Adtech ADTECH4 CNC Series Manual de usuario

ADTECH4 Series

CNC Maintenance Manual

ADTECH4 SeriesCNC Maintenance Manual

Basic Information

This Manual is written by Adtech (Shenzhen) Technology Co., Ltd.

This Manual is mainly written by: Tang Xiaobing

This Manual was first released onAugust 27, 2013, with version No. A0101 and item number BZ001B092A.

The property rights of all the parts of the manual belong to Adtech (Shenzhen) Technology Co., Ltd. (Adtech for short), and

any form of imitation, copying, transcription or translation by any company or individual without the permission is

prohibited. This manual does not include any form of assurance, standpoint expression, or other intimations. Adtech and the

stuffs have no responsibility for any direct or indirect disclosure of the information, benefit loss or business termination of

this manual of the quoted product information. In addition, the product and the information mentioned in this manual are for

reference only, and the content is subject to change without notice.

Adtech (Shenzhen) Technology Co., Ltd.

ADTECH4 SeriesCNC Maintenance Manual

Precautions and Explanations

※Transport and storage:

Do not stack product package more than six layers;

Do not climb, stand on or place heavy stuff on the product package;

Do not pull the cable still connecting with machine to move product.

Forbid impact and scratch on the panel and display;

Prevent the product package from humidity, sun exposure, and rain.

※Open-box inspection:

Open the package to confirm the product to be purchased by you.

Check damages situation after transportation;

Confirm the integrity of parts comparing with the parts list or damages situation;

Contact our company promptly for discrepant models, shortage accessories, or transport damages.

※Wiring

Ensure the persons involved into wiring and inspecting are specialized staff;

Guarantee the product is grounded with less than 4Ω grounding resistance. Do not use neutral line (N) to substitute earth

wire.

Ensure grounding to be correct and solid, in order to avoid product failures or unexpected consequences;

Connect the surge absorption diodes to the product in the required direction, otherwise, the product will be damaged;

Ensure the power switch is OFF before inserting or removing plug, or disassembling chassis.

※Overhauling

Ensure the power is OFF before overhauling or components replacement;

Make sure to check failures after short circuit or overloading, and then restart the machine after troubleshooting

Do not allow to frequently connect and disconnect the power, and at least one minute interval between power-on and

power-off.

※Miscellaneous

Do not open housing without permission;

Keep power OFF if not in use for a long time;

Pay close attention to keep dust and ferrous powder away from control;

Fix freewheel diode on relay coil in parallel if non-solid state relay is used as output relay. Check whether power supply

meets the requirement to ensure not burning the control.

Install cooling fan if processing field is in high temperature, due to close relationship between service life of the control

and environmental temperature. Keep proper operative temperature range for the control: 0℃~ 60℃.

Avoid using the product in the overheating, humid, dusty, or corrosive environments;

ADTECH4 SeriesCNC Maintenance Manual

Add rubber rails as cushion on the place with strong vibration.

※Maintenance:

Please implement routine inspection and regular check upon the following items, under the general usage conditions (i.e.

environmental condition: daily average 30℃, load rate: 80%, and operating rate: 12 hours/ day)

Routine

Inspecti

Routine

Confirm environmental temperature, humidity, dust, or foreign objects.

Confirm abnormal vibration and noise;

Check whether vents are blocked by yarn etc.

Regular

Check

One

year

Check whether solid components are loose

Confirm whether terminal block is damaged

ADTECH4 SeriesCNC Maintenance Manual
