ADLINK Technology PCIS-8580-4S Manual de usuario
Advance Technologies; Automate the World.
Manual Rev. 2.01
Revision Date: December 21, 2006
Part No: 50-15054-1000
PCIS-8580-4S
PCIS-8580-13S
User’s Manual
Copyright 2006 ADLINK TECHNOLOGY INC.
All Rights Reserved.
The information in this document is subject to change without prior
notice in order to improve reliability, design, and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, spe-
cial, incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of
the possibility of such damages.
This document contains proprietary information protected by copy-
right. All rights are reserved. No part of this manual may be repro-
duced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Trademarks
NuDAQ, NuIPC, DAQBench are registered trademarks of ADLINK
TECHNOLOGY INC.
Product names mentioned herein are used for identification pur-
poses only and may be trademarks and/or registered trademarks
of their respective companies.
Getting Service from ADLINK
Customer Satisfaction is top priority for ADLINK Technology Inc.
Please contact us should you require any service or assistance.
ADLINK TECHNOLOGY INC.
Web Site: http://www.adlinktech.com
TEL: +886-2-82265877
FAX: +886-2-82265717
Address: 9F, No. 166, Jian Yi Road, Chungho City,
Taipei, 235 Taiwan
Please email or FAX this completed service form for prompt and
satisfactory service.
Company Information
Company/Organization
Contact Person
E-mail Address
Address
Country
TEL FAX:
Web Site
Product Information
Product Model
Environment
OS:
M/B: CPU:
Chipset: BIOS:
Please give a detailed description of the problem(s):
Table of Contents i
Table of Contents
Table of Contents..................................................................... i
List of Tables.......................................................................... iii
List of Figures ........................................................................ iv
1 Introduction ........................................................................ 1
1.1 Features............................................................................... 2
PCIS-8580-4S ................................................................. 2
PCIS-8580-13S ............................................................... 2
1.2 Applications ......................................................................... 2
1.3 Specifications....................................................................... 3
LPCI-8575 PCI-PCI Extension Card ............................... 3
RK-8005 Extension chassis ............................................ 4
RK-8014 Extension chassis ............................................ 5
ACL-PCIEXT-2 Cable ..................................................... 5
General ........................................................................... 5
2 Installation .......................................................................... 7
2.1 Content of package.............................................................. 7
2.2 Unpacking............................................................................ 8
2.3 Getting Start......................................................................... 8
Install PCI Extension Card into your Host System .......... 8
Driver Installation ............................................................ 9
Install your PCI Card into the Extension Chassis ......... 10
Connect to Extension Chassis ...................................... 12
Power-on Sequence ..................................................... 12
3 Hardware Overview.......................................................... 15
3.1 System Architecture........................................................... 15
Operation Theory ......................................................... 15
3.2 LPCI-8575 PCI Extension Card ......................................... 16
Functional Block ........................................................... 16
Jumper Settings for LPCI-8575 .................................... 17
3.3 BP-8005............................................................................. 21
Backplane Architecture ................................................. 21
Jumpers and Connectors .............................................. 24
Jumpers and connectors on the bottom side ................ 24
ii Table of Contents
3.4 RK-8005............................................................................. 25
Mechanical Drawing of RK-8005 .................................. 25
3.5 BP-8014 ............................................................................. 26
Backplane Architecture ................................................. 26
Jumpers and Connectors .............................................. 27
Remote Power-on Function .......................................... 27
3.6 RK-8014............................................................................. 29
Mechanical Drawing of RK-8014 .................................. 29
3.7 ACL-PCIEXT-2................................................................... 30
Pin Assignment of ACL-PCIEXT-2 ............................... 30
Warranty Policy ..................................................................... 31
List of Tables iii
List of Tables
Table 1-1: Power requirements ................................................. 3
Table 3-1: Jumpers and connectors on the LPCI-8575 ........... 17
Table 3-2: JP1 Settings ........................................................... 18
Table 3-3: JP2 Settings ........................................................... 18
Table 3-4: JP3 Settings ........................................................... 19
Table 3-5: D2 Display .............................................................. 20
Table 3-6: Top side jumpers and connectors .......................... 24
Table 3-7: Bottom side jumpers and connectors ..................... 24
Table 3-8: BP-8014 jumpers and connectors .......................... 27
Table 3-9: Remote Power-on Function .................................... 27
Table 3-10: Pin Assignment of ACL-PCIEXT-2 ......................... 30
iv List of Figures
List of Figures
Figure 2-1: Install the PCI extension card into your host system . 9
Figure 2-2: Installing the driver for PCI extension card .............. 10
Figure 2-3: Install your PCI cards into the extension chassis (using
the PCIS-8580-4S as an example) .......................... 11
Figure 2-4: Connect you host computer and extension chassis (using
the PCIS-8580-4S as an example) .......................... 12
Figure 3-1: Operation theory of PCIS-8580 PCI-to-PCI extension
system ..................................................................... 15
Figure 3-2: Concept of the serialized PCI bridge ....................... 16
Figure 3-3: Jumpers and connectors on the LPCI-8575 ............ 17
Figure 3-4: Top view of BP-8005 backplane .............................. 22
Figure 3-5: Bottom view of BP-8005 backplane......................... 23
Figure 3-6: Mechanical drawing of RK-8005.............................. 25
Figure 3-7: Top view of BP-8014 backplane .............................. 26
Figure 3-8: Mechanical drawing of RK-8014.............................. 29
Figure 3-9: DVI Connector pins and dimensions ....................... 30
Introduction 1
1 Introduction
The ADLINK PCIS-8580 is the PCI-to-PCI extension systems for
extending your PCI buses of the host computers. With the state-
of-art StarFabric high-speed serial link technology, you can extend
your PCI bus of the host computer to an external chassis, which
accommodates 4 (PCIS-8580-4S) or 13 (PCIS-8580-13S) addi-
tional PCI slots. This advanced technology provides full 32-bit/
33MHz PCI bandwidth (132MB/s) and maximal 10m distance
between host computer and extension chassis. In addition,
ADLINK PCI-to-PCI extension system utilizes the concept of “seri-
alized bridge” to provide complete hardware and software trans-
parency to your host system. Any hardware installed in the
extension chassis works as it’s inside the host system without any
driver/software effort.
The ADLINK PCIS-8580 PCI-to-PCI extension system is com-
posed of three major components: a PCI extension card (LPCI-
8575), an extension chassis (RK-8005 for PCIS-8580-4S or RK-
8014 for PCIS-8580-13S), and a cable (ACL-PCIEXT-2). The PCI
extension card is the core of this system. It acts as a PCI bridge
with the capability to serialize the PCI signals and maintain a
5Gbps serial link between the host system and the extension
chassis. The extension chassis, which is a 4-slot wall-mount chas-
sis (RK-8005) or a 13-slot rack-mount chassis (RK-8014), is the
platform to accommodate PCI slots. It contains a backplane, a
power supply, and a pre-installed PCI extension card. The cable,
which consists of DVI-D connector and shielding twisted pairs,
provides robust connectivity and satisfying signal quality between
the host computer and the extension chassis.
2Introduction
1.1 Features
PCIS-8580-4S
XPCI local bus specification Rev 2.2 compliant
XPCI bridge architecture specification Rev 1.2 compliant
XProvides 4 extended PCI slots
XFull 32-bit/33MHz PCI bandwidth extension (132MB/s)
XMaximal 10m extension distance
XComplete hardware and software transparency
X24-pin DVI-D connector for robust connectivity
XShoebox size wall-mount chassis with built-in 200W power
supply
PCIS-8580-13S
XPCI local bus specification Rev 2.2 compliant
XPCI bridge architecture specification Rev 1.2 compliant
XProvides 13 extended PCI slots
XFull 32-bit/33MHz PCI bandwidth extension (132MB/s)
XMaximum 10m extension distance
XComplete hardware and software transparency
X24-pin DVI-D connector for robust connectivity
X19” rack-mound chassis with built-in 400W power supply
1.2 Applications
XIndustrial automation/control
XElectronics manufacturing test
XMilitary/aerospace
XVideo capture
XRemote test and measurement
