ADLINK Technology NuPRO-598 Series Manual de usuario

NuPRO-598 Series

Half Size Socket7 ISA Bus Low Power Pentium SBC

With VGA/LCD/Ethernet/WOL Interface

User’s Guide

Recycled Paper

Manual Rev 1.00: Nov 8, 2001

Part No:

This publication is protected by copyright and all rights are reserved. No

part of it may be reproduced or transmitted by any means or in any form,

without prior consent of the original manufacturer.

The information in this document has been carefully checked and is

believed to be accurate. However, the original manufacturer assumes no

responsibility for any inaccuracies that may appear in this manual. In no

event will the original manufacturer be liable for direct, indirect, special,

exemplary, incidental, incidental or consequential damages resulting from

any defect or omission in this manual, even ifadvised of possibility of such

damages. The material contained herein is for informational purposes only.

Acknowledgments

Award is a registered trademark of Award Software International, Inc.

IBM and PS/2 are trademarks of International Business Machines

Corporation.

C&T is a trademark of Chips and Technologies Inc.

Intel and Pentium are registered trademarks of Intel Corporation.

Microsoft Windows is a registered trademark of Microsoft Corporation.

All other product names or trademarks are properties of their respective

owners.

Getting service from ADLINK

•Customer Satisfaction is always the most important thing for ADLINK

Tech Inc. If you need any help or service, please contact us and get it.

ADLINK Technology Inc.

Web Site http://www.adlink.com.tw

Sales & Service

[email protected]

NuDAQ + USBDAQ [email protected]

NuDAM [email protected]

NuIPC [email protected]

NuPRO [email protected]

Software [email protected]

Technical

Support

AMB [email protected]

TEL +886-2-82265877 FAX +886-2-82265717

Address 9F, No. 166, Jian Yi Road, Chungho City, Taipei, 235 Taiwan, R.O.C.

•Please inform or FAX us of your detailed information for a prompt,

satisfactory and constant service.

Detailed Company Information

Company/Organization

Contact Person

E-mail Address

Address

Country

TEL FAX

Web Site Questions

Product Model

OS :

Computer Brand :Environment to Use M/B : CPU :

Chipset : BIOS :

Video Card :

Network Interface Card :

Other :

Challenge Description

Suggestions for ADLINKk

NuPRO-598 Series Comparison Table

Model NuPRO-598

Processor

Intel Pentium

AMD K6-2, K6-3

Cyrix MII

Processor Socket Socket7

Chipset Intel 430TX

BIOS Award

L2 cache 512KB

Max. SDRAM 128MB

Memory Sockets 1 x DIMM

VGA CRT/LCD C&T 69000

Watchdog Timer 0~255 seconds or minutes

PC/104 Connector NO

Multi I/O Chip Winbond83977EF

Enhanced IDE yes

2S/1P yes

USB yes

Ethernet

(10/100Mbps) Intel 82559

H/W Monitoring Winbond W83781D

Board Size 185mm x 122mm

Table of Contents•i

Table of Contents

Chapter 1 Introduction............................................................1

1.1 Checklist.......................................................................2

1.2 Description ...................................................................2

1.3 Features .......................................................................3

1.4 Specifications................................................................4

1.5 Intelligence ...................................................................7

Chapter 2 Installations ..........................................................10

2.1 CPU Installation..........................................................11

2.2 Memory Installation.....................................................11

2.3 Jumpers on the NuPRO-598 ........................................11

2.4 Connectors on the NuPRO-598....................................18

2.5 Watchdog Timer Configuration.....................................30

2.6 Disk On Chip Address .................................................32

Chapter 3 BIOS Configuration..............................................33

3.1 BIOS Introduction........................................................33

3.2 BIOS Setup.................................................................34

Chapter 4 Intel PIIX Bus Master IDE Driver Installation....62

4.1 System Requirements .................................................63

4.2 Installing the Software .................................................64

Chapter 5 VGA Driver Installation........................................66

5.1 Installing the Drivers for Windows 95 ............................66

5.2 Installing the Drivers for Windows 98 ............................67

5.3 Installing the Drivers for Windows NT 4.0......................67

Chapter 6 LAN Driver Installation Guide.............................69

6.1 Introduction.................................................................69

6.2 Features .....................................................................69

6.3 Software Drivers Support .............................................70

6.4 Running Diagnostics....................................................70

6.5 Driver Installation on Windows 98.................................74

6.6 Driver Installation on Windows NT................................75

6.7 Driver Installation on Windows 2000.............................76

Chapter 7 Hardware Doctor Utility.......................................77

ii •Table of Contents

Product Warranty/Service.....................................................82

Introduction •1

Introduction

This manual is designed to give you information on the NuPRO-598 CPU

board.

The topics covered in this chapter are as follows:

♦Checklist

♦Description

♦Features

♦Specifications

♦Intelligence

♦Layout of Key Components and Dimensions

2•Introduction

1.1 Checklist

Please check that your package is complete and contains the items below.

If you discover damaged or missing items, please contact your dealer.

•The NuPRO-598 Industrial CPU Board

•This User’s Manual

•1 IDE Ribbon Cable

•1 Floppy Ribbon Connector

•2 Serial Port Ribbon Cable and 1 Parallel Port Attached to a

Mounting Bracket

•1 Optional 2-port

•1 CD Containing Intel PCI IDE Driver, Flash Memory Utility, C&T

69000 VGA Driver, Intel 82559 LAN Driver and Hardware Monitor

utility

1.2 Description

The NuPRO-598 is a Pentium Industrial CPU board based on the Intel

430TX chipset and is fully designed for harsh industrial environment. It

features a Socket7 processor connector that is compatible with Intel

Pentium MMX, AMD K6-2, K6-3 and Cyrix MII processors. This board

accommodates up to 128MB SDRAM configuration.

The NuPRO-598 comes with Winbond’s W83781D hardware monitoring

device that monitors system and CPU temperature, system voltages, and

CPU and chassis fan speeds to prevent system crashes by warning the

user of adverse conditions. NuPRO598 also has a case-open indicator for

security.
