ADLINK Technology ETX-EV133 Manual de usuario

ETX

ETX-EV133

User’s Manual

ver. 1.2

ETX-EV133 User’s ManualPage 2

Manual Rev. 1.2 Nov 1, 2005

The information in this document is subject to change without prior notice in order to improve

reliability, design, and function and does not represent a commitment on the part of the manufac-

turer.

In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential

damages arising out of the use or inability to use the product or documentation, even if advised

of the possibility of such damages.

This document contains proprietary information protected by copyright laws. All rights are re-

served. No part of this manual may be reproduced by any mechanical, electronic, or other means

in any form without prior written permission of the manufacturer.

Trademarks

PC is a registered trademark of International Business Machines Corporation. Intel is a registered

trademark of Intel Corporation. AWARD is a registered trademark of Award Software Interna-

tional, Inc. Other product names mentioned herein are used for identification purposes only and

may be trademarks and/or registered trademarks of their respective companies.

Page 3ETX-EV133 User’s Manual

Revision History

Release Date Initials Change

1.0 9/6/2004 JC Initial release

1.1 10/12/2004 JC - changed all reference to Audio Codec AL201A to VT1616

- added shared FDD support

- updated SMB/I2C parapgraph

- added Appendix A : Heatspreader

1.2 11/1/2005 HB - changed I2C addresses for onboard devices

ETX-EV133 User’s ManualPage 4

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.2 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.3 Multi I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.4 Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.5 LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.6 Mechanical and Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3 Function diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

4 Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

5 Watchdog Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

6 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

6.1 Connector Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

6.2 Pin-Out Compatibillity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

6.3 X1 Connector : PCI-bus, USB and Audio . . . . . . . . . . . . . . . . . . . . . . . . . . 14

6.4 X2 Connector : ISA Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

6.4 X3 Connector : CRT, LCD, Video, COM1/2, LPT1/FDD,. . . . . . . . . . . . . . . . . .

IrDA, Mouse, Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

6.5 X4 Connector : IDE1, IDE2, Ethernet, Miscellaneous . . . . . . . . . . . . . . . . . . 17

7 System Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

7.1 Interrupt Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

7.2 PCI Bus Arbitration Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

7.3 PCI Interrupt Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

7.4 Memory Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

7.5 Direct Memory Access Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

7.6 I/O Adddres Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

7.7 System Management Bus (I2C) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Page 5ETX-EV133 User’s Manual

8 Phoenix Award BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

8.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

8.2 Main Menu Setup Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

8.3 Standard CMOS Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

8.4 Advanced BIOS Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

8.5 Advanced Chipset Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

8.6 Integrated Peripherals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

8.7 Power Management Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

8.8 PnP/PCI Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

8.9 PC Health Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

8.10 BIOS POST Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Appendix A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . :

Heatspreader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

A.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

A.1 Heatspreader Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

ETX-EV133 User’s ManualPage 6

Page 7ETX-EV133 User’s Manual

1Introduction

1.1 Description

ETX-EV133 is an ETX compatible module specially designed to facilitate speedy development of

semi custom designs. ETX is an open standard that targets the market for embedded OEM

projects. An ETX core combined with a custom made carrier board represents a value solution

that allows OEM customers to get to the market fast. ETX Core modules are also know as COM

(Computer on module) or as SOM (System on Module).

ETX-EV133 is based on the VIA’s Eden ESP processor combined with VIA Apollo PLE133T and

VT82C686B chipsets. The onboard SODIMM socket supports 144-pin SODIMM type memory

modules that can accommodates up to 512MB non-ECC SDRAM modules. VIA Eden Processor

is available in the range of 400 Mhz up to 1 Ghz.

The VIA VT82C686B Southbridge incorporates a PCI/ISA bridge, a VGA AGP controller, an EIDE

controller supporting both PIO and UDMA modes, USB ports v1.1, two serial ports, one parallel

port (SPP/ECP/EPP), one PS2 keyboard/mouse interface, AC97 audio interface and power

management functionallity.

Additonally onboard are an 10/100Base-T Ethernet port, watchdog timer, an AC97 Audio Codec

and support for LVDS based Flat Panel displays.

ETX-EV133 User’s ManualPage 8

2Specifications

1.1 General

fCPU : VIA Eden ESP processor (eBGA package)

Standard : VIA Eden ESP 4000, 6000, 8000 or 10K Low Voltage CPU’s

with 133 MHz FSB and 64 KB L2 cache

fSystem Memory : 144-pin SODIMM socket for up 512 MB PC100/133 non-ECC SDRAM

fL2 Cache : integrated in CPU (see above)

fChipset : VIA Apollo PLE133T with VT8601T Northbridge and VT82C686B Southbridge

fEnhanced IDE : two ports and up to 4 ATAPI devices, supports Ultra DMA transfer rates of

up to 100 MB/sec

fBIOS : AWARD 2 Mb Flash BIOS with ACPI and APM 1.2 power management

with console redirection and CMOS backup in onboard EEPROM

fWatchdog Timer : 254-level timer generates RESET

fExpansion : 16-bit ISA and 32-bit PCI 2.1

1.2 Display

fChipset : integrated AGP2X Trident Blade 2D/3D Video Accelerator (VT8601T)

fMemory : up to 8 MB UMA Video RAM

fCRT : up to UXGA 1600 x 1200 @ 32bpp

fFlat Panel : supports TFT on single channel LVDS (18-bit )

1.3 Multi I/O

fSerial : 2 high speed RS-232C ports (COM1/COM2)

fParallel : SPP, EPP and ECP mode (pinout shared with FDD)

fFDD : one drive, (pinout shared with LPT1)

fIrDA : supports SIR IrDA 1.1 compliant

fUSB : supports up to 4 ports ver 1.1

fKeyboard & Mouse : one PS/2 keyboard and one PS/2 mouse

Page 9ETX-EV133 User’s Manual

1.4 Audio

fChipset : included in VT82C686B

fAudio Codec : VT1616 AC97 ver. 2.0

1.5 LAN

fChipset: Realtek 8139CL+

fEthernet Interface : 10/100 Mbps, Wake-on-LAN supported

1.6 Mechanical and Environmental

fPower Requirement (+5V only) :

10 Watt typical ; (VIA Eden 600 MHz with 256 MB SDRAM)

fOperating Temperature : 0 to 55°C (32 to 140°F)

fRelative Humidity : up to 90% @ 55°C

fETX Board Dimensions : 95 mm x 114 mm (3.7" x 4.5")

fWeight : 87 grams

ETX-EV133 User’s ManualPage 10

3Function diagram

Realtek

Ethernet

Mac/PHY

RT8139CL+

Realtek

Ethernet

Mac/PHY

RT8139CL+

LVDS Transm.

DS90C363AMTD

LVDS Transm.

DS90C363AMTD

Southbridge

VIA VT82C686B

Southbridge

VIA VT82C686B

CPU

VIA Eden ESP

400, 600, 800

CPU

VIA Eden ESP

400, 600, 800

Northbridge

VIA VT8601T

Northbridge

VIA VT8601T

FSB

66/100/133

Audio

USB 1.1

SDRAM

Memory

Controller

AGP

VGA

Controller

Keyboard

Mouse

FDD/LPT1

COM1

COM2

CRT

I2C

ATA100

RTC

EEPROM

CMOS

Backup

EEPROM

CMOS

Backup

SDRAM

SODIMM

Socket

SDRAM

SODIMM

Socket

ISA bus

ATA 100

Dual channel USB v1.1

VIA

AC'97 Codec

VT1616

VIA

AC'97 Codec

VT1616

BIOS

PCI to ISA

Bridge

Super I/O

PCI Bus

ISA Bus

Watchdog

Timer

Watchdog

Timer
