cExpress-KL

User’s Manual

COM Express Compact Size Type 6 Module with

Mobile 7th Gen Intel® Core™ and Celeron® Processor

Manual Rev.: 1.1

Revision Date: January 3, 2020

Part Number: 50-1J085-1010

ii Preface

Preface

This document contains proprietary information protected by copyright. All rights are reserved. No part of this

manual may be reproduced by any mechanical, electronic, or other means in any form without prior written

permission of the manufacturer.

Disclaimer

The information in this document is subject to change without prior notice in order to improve reliability, design, and

function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer

be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use

the product or documentation, even if advised of the possibility of such damages.

Environmental Responsibility

ADLINK is committed to fulfill its social responsibility to global environmental preservation through compliance with

the European Union's Restriction of Hazardous Substances (RoHS) directive and Waste Electrical and Electronic

Equipment (WEEE) directive. Environmental protection is a top priority for ADLINK. We have enforced measures to

ensure that our products, manufacturing processes, components, and raw materials have as little impact on the

environment as possible. When products are at their end of life, our customers are encouraged to dispose of them

in accordance with the product disposal and/or recovery programs prescribed by their nation or company.

California Proposition 65 Warning

WARNING: This product can expose you to chemicals including acrylamide, arsenic, benzene,

cadmium, Tris(1,3-dichloro-2-propyl)phosphate (TDCPP), 1,4-Dioxane, formaldehyde, lead, DEHP,

styrene, DINP, BBP, PVC, and vinyl materials, which are known to the State of California to cause

cancer, and acrylamide, benzene, cadmium, lead, mercury, phthalates, toluene, DEHP, DIDP, DnHP,

DBP, BBP, PVC, and vinyl materials, which are known to the State of California to cause birth defects or other

reproductive harm. For more information go to www.P65Warnings.ca.gov.

Trademarks

Product names mentioned herein are used for identification purposes only and may be trademarks and/or

registered trademarks of their respective companies.

Revision History

Revision Description Date By

1.0 Initial release 2019-07-03 JC

1.1 Update specifications, pin description, BIOS 2020-01-03 JC

cExpress-KL

Preface iii

Table of Contents

Preface................................................................................................................................ii

List of Figures ....................................................................................................................v

List of Tables.....................................................................................................................vi

1. Introduction................................................................................................................1

2. Specifications............................................................................................................3

2.1. Core System ...............................................................................................................3

2.2. Expansion Busses ......................................................................................................3

2.3. Video...........................................................................................................................4

2.4. Audio...........................................................................................................................4

2.5. LAN.............................................................................................................................4

2.6. Multi I/O and Storage..................................................................................................4

2.7. Serial I/O on Module (need BIOS RD help) ...............................................................5

2.8. Trusted Platform Module (TPM) .................................................................................5

2.9. SEMA Board Controller ..............................................................................................5

2.10. Debug......................................................................................................................5

2.11. Power Specifications ...............................................................................................6

2.12. Power Consumption ................................................................................................6

2.13. Operating Temperatures .........................................................................................6

2.14. Environmental .........................................................................................................6

2.15. Specification Compliance ........................................................................................6

2.16. Operating Systems..................................................................................................6

2.17. Functional Diagram .................................................................................................7

2.18. Mechanical Drawing ................................................................................................8

3. Pinouts and Signal Descriptions..............................................................................9

3.1. AB/CD Pin Definitions.................................................................................................9

3.2. Signal Description Terminology ................................................................................12

3.3. AB Signal Descriptions .............................................................................................13

3.4. CD Signal Descriptions.............................................................................................23

4. Connector Pinouts on Module................................................................................29

4.1. Connector, Switch and LED Locations .....................................................................29

4.2. 40-pin Debug Connector...........................................................................................30

4.3. Status LEDs..............................................................................................................31

4.4. XDP Debug Header .................................................................................................. 32

4.5. Fan Connector ..........................................................................................................33

iv Preface

4.6. BIOS Setup Defaults Reset Button...........................................................................34

4.7. Switch Settings .........................................................................................................35

5. Smart Embedded Management Agent (SEMA) .....................................................37

5.1. Board Specific SEMA Functions...............................................................................38

6. System Resources ..................................................................................................41

6.1. System Memory Map................................................................................................41

6.2. Direct Memory Access Channels..............................................................................41

6.3. I/O Map .....................................................................................................................41

6.4. Interrupt Request (IRQ) Lines...................................................................................43

6.5. PCI Configuration Space Map ..................................................................................44

6.6. PCI Interrupt Routing Map ........................................................................................46

6.7. SMBus Address Table ..............................................................................................46

7. BIOS Setup...............................................................................................................47

7.1. Menu Structure .........................................................................................................47

7.2. Main ..........................................................................................................................48

7.3. Advanced..................................................................................................................53

7.4. Security.....................................................................................................................71

7.5. Boot ..........................................................................................................................71

7.6. Save & Exit ...............................................................................................................74

8. BIOS Checkpoints, Beep Codes.............................................................................75

8.1. Status Code Ranges.................................................................................................76

8.2. Standard Status Codes.............................................................................................76

8.3. OEM-Reserved Checkpoint Ranges......................................................................... 83

9. Mechanical Information...........................................................................................85

9.1. Board-to-Board Connectors......................................................................................85

9.2. Thermal Solution.......................................................................................................86

9.3. Mounting Methods ....................................................................................................89

9.4. Standoff Types..........................................................................................................90

Safety Instructions...........................................................................................................91

Getting Service.................................................................................................................92

cExpress-KL

Preface v

List of Figures

Figure 1: cExpress-KL Functional Block Diagram....................................................................................7

Figure 1: cExpress-KL Mechanical Drawing ............................................................................................8

Figure 1: cExpress-KL Connector, Switch and LED Locations ............................................................. 29

Figure 1: cExpress-KL and the DB40 Debug Module ........................................................................... 29

Figure 1: cExpress Switch Locations .................................................................................................... 35

Figure 1: COM Express Mounting Methods ..........................................................................................89

Figure 1: COM Express Standoff Types................................................................................................ 90

vi Preface

List of Tables

Table 1: cExpress-KL AB/CD Pin Definitions ...........................................................................................9

Table 1: 40-pin Debug Connector Pin Definition ................................................................................... 30

Table 1: cExpress-KL LED Descriptions ............................................................................................... 31

Table 1: XDP Debug Header Pin Definition .......................................................................................... 32

Table 1: Fan Connector Pin Definition .................................................................................................. 33

Table 1: BIOS Select and Mode Configuration Switch Settings............................................................ 35

Table 1: SEMA Onboard Voltage Monitor ............................................................................................. 38

Table 1: SEMA BMC Status .................................................................................................................. 38

Table 1: SEMA Exception Codes .......................................................................................................... 39

Table 1: SEMA BMC Flags.................................................................................................................... 39

cExpress-KL

Introduction 1

1. Introduction

The cExpress-KL is a COM Express® COM.0 R2.1 Type 6 Compact size module featuring the 64-bit 7th

Generation Intel® Core™ i7/i5/i3 and Intel® Celeron® Ultra-Low TDP processors (formerly “Kaby Lake U”) with

CPU, memory controller, graphics processor and I/O hub on a single chip. Leveraging the benefits provided by the

7th generation Intel® Core™ and Celeron™ System-on-Chip, the cExpress-KL is specifically designed for

customers who need optimum processing and graphics performance with suitable power consumption using Intel’s

Configurable TDP in a long product life solution. The cExpress-KL’s Intel® processors support Intel® Hyper-

Threading Technology (up to 2 cores, 4 threads) and up to 32 GB of non-ECC DDR4 dual-channel memory at

1866/2133 MHz in dual stacked SODIMM sockets to provide excellent overall performance.

Integrated Intel® Generation 9 Low Power Graphics includes features such as OpenGL 4.4/4.3, DirectX 11.3/11,

Intel® Clear Video HD Technology, Advanced Scheduler 2.0, 1.0, XPDM support, and DirectX Video Acceleration

(DXVA2) support for AVC/VC1/MPEG2/HEVC/VP8/JPEG hardware decode and AVC/MPEG2/HEVC/VP8/JPEG

hardware encode. Graphics outputs include dual-channel 18/24-bit LVDS (eDP by build option), two DDI ports

supporting HDMI/DVI/DisplayPort and VGA (by build option, support by project basis). The cExpress-KL is

specifically designed for customers with high-performance processing graphics requirements who want to

outsource the custom core logic of their systems for reduced development time.

The cExpress-KL features a single onboard Gigabit Ethernet port, up to six PCIe Gen3 ports (build option), four

USB 3.0 ports, four USB 2.0 ports, and three SATA 6Gb/s ports. Support is provided for SMBus and I2C. The

module is equipped with SPI AMI EFI BIOS with CMOS backup, supporting embedded features such as remote

console, CMOS backup, hardware monitor, and watchdog timer.

2 Introduction

This page intentionally left blank.

cExpress-KL

Specifications 3

2. Specifications

2.1. Core System

CPU 7th Generation Intel® Core™ and Celeron® processor SoC (formerly “Kaby Lake U”)

•Intel® Core™ i7-7600U 2.8 GHz (3.9 GHz Turbo), 15W (cTDP support) (2C/GT2)

•Intel® Core™ i5-7300U 2.6 GHz (3.5 GHz Turbo), 15W (cTDP support) (2C/GT2)

•Intel® Core™ i3-7100U 2.4 GHz (no Turbo), 15W (cTDP support) (2C/GT2)

•Intel® Celeron® 3965U 2.2 GHz (no Turbo), 15W (cTDP support) (2C/GT1)

Supports: Intel® VT, Intel® TXT, Intel® SSE4.2, Intel® HT Technology, Intel® 64

Architecture, Execute Disable Bit, Intel® Turbo Boost Technology 2.0, Intel® AVX2, Intel®

AES-NI, PCLMULQDQ Instruction, Intel® Device Protection Technology with Intel®

Secure Key, Intel® TSXNI

Note: Availability of features may vary between processor SKUs.

L3 Cache 4MB for Core™ i7, 3MB for Core™ i5 and Core™ i3, 2MB for Celeron®

Memory Dual channel non-ECC 1866/2133 MHz DDR4 memory up to 32 GB in dual SODIMM

socket

BIOS AMI EFI with CMOS backup in 16MB SPI BIOS with Intel® AMT 11.0 support (AMT

supported on i7/i5 SKUs only)

Platform Controller Hub Integrated PCH-LP

2.2. Expansion Busses

PCI Express 5x PCI Express x1 Gen3 (AB):

Lanes 0/1/2/3/4, supports x4, x2, x1 configuration

(up to 6x PCI Express x1 Gen3 support by build option, in place of GbE)

Other •LPC bus

•SMBus (system)

•I2C (user)

4 Specifications

2.3. Video

Integrated on Processor Intel® Generation 9 Low Power Graphics core architecture (Intel® HD Graphics 620/610)

GPU Feature Support •3 independent and simultaneous display combinations of DisplayPort/HDMI/LVDS/VGA

monitors (eDP & VGA by build option, support by project basis)

•Encode/transcode HD content

•Playback of high definition content including Blu-ray Disc

•Playback of Blu-ray disc S3D content using HDMI (1.4a spec compliant with 3D)

•DirectX Video Acceleration (DXVA2) support for accelerated video processing

•AVC/VC1/MPEG2/HEVC/VP8/JPEG HW decode

•AVC/MPEG2/HEVC/VP8/JPEG HW encode

•Advanced Scheduler 2.0, 1.0, XPDM support

•DirectX 11.3, OpenGL 4.4, OpenGL ES 2.0 and OpenCL 2.0

•Multi Display Support: 3 independent displays

Note: Availability of features may vary between processor SKUs.

Display Types •Single/dual channel 18/24-bit LVDS via eDP-to-LVDS chip, supports DE mode and H/V-

Sync mode display. Resolution up to 1920x1200 with dual channel LVDS.

(eDP 4 lanes available as build option in place of LVDS)

•2x Digital Display Ports:

DDI1 supports DisplayPort/HDMI/DVI

DDI2 supports DisplayPort/HDMI/DVI

•VGA (build option) via DP-to-VGA chip. Resolution up to 1920x1200. in place of DDI 2

Note: Supports HDMI 1.4, DP 1.2 and eDP 1.3.

2.4. Audio

Integrated Intel® HD Audio integrated on SoC

Codec Located on carrier Express-BASE6 (ALC886 standard support)

2.5. LAN

Integrated MAC integrated on SoC

Intel PHY Intel® Ethernet Controller I219-LM or I219-V (only LM version support iAMT)

Interface 10/100/1000 Mbit/s connection

2.6. Multi I/O and Storage

I/O Hub Integrated on SoC

USB 4x USB 3.0 ports (USB0,1,2,3) and 4x USB 2.0 ports (USB4,5,6,7)

All USB support by XHCI controller.

SATA 3x SATA 6Gb/s ports, RAID 0/1/5 support

GPIO 4 GPO and 4 GPI, GPI with interrupt

Tabla de contenidos

Otros manuales de Hardware de computadora de ADLINK Technology

ADLINK Technology

ADLINK Technology EBP-13E2 Manual de usuario

ADLINK Technology

ADLINK Technology Com Express nanoX-BT Manual de usuario

ADLINK Technology

ADLINK Technology COM Express nanoX-TC Manual de usuario

ADLINK Technology

ADLINK Technology COM Express cExpress-BL Manual de usuario

ADLINK Technology

ADLINK Technology NuDAQ ACL-8216 Manual de usuario

ADLINK Technology

ADLINK Technology cPCI-6530 Series Manual de usuario

ADLINK Technology

ADLINK Technology NuPRO-840 DV Manual de usuario

ADLINK Technology

ADLINK Technology cPCI-6630 Series Manual de usuario

ADLINK Technology

ADLINK Technology Q7-AL Manual de usuario

ADLINK Technology

ADLINK Technology cPCIS-1100 Series Manual de usuario

ADLINK Technology

ADLINK Technology PCI-3488 Manual de usuario

ADLINK Technology

ADLINK Technology ETX-BT Manual de usuario

ADLINK Technology

ADLINK Technology cPCI-3520 Series Manual de usuario

ADLINK Technology

ADLINK Technology cPCI-A3525 Series Manual de usuario

ADLINK Technology

ADLINK Technology HDV62 Manual de usuario

ADLINK Technology

ADLINK Technology VPX3020 Series Manual de usuario

ADLINK Technology

ADLINK Technology DIN-1040 Manual de usuario

ADLINK Technology

ADLINK Technology arm AMPERE COM-HPC-ALT Manual de usuario

ADLINK Technology

ADLINK Technology cPCI-3510 Manual de usuario

ADLINK Technology

ADLINK Technology HPERC-KBL-MC Manual de usuario

ADLINK Technology

ADLINK Technology GEME-4000 Series Manual de usuario

ADLINK Technology

ADLINK Technology LEC-BASE MINI Manual de uso y cuidado

ADLINK Technology

ADLINK Technology COM Express cExpress-TL Manual de usuario

ADLINK Technology

ADLINK Technology MXM-P1000 Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario

ADLINK Technology cExpress-KL Manual de usuario

Manuales populares de Hardware de computadora de otras marcas
