User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 1 of 30
User Manual
Revision 1.000
English
IEC 61850 Server / Modbus Master - Converter
(Order Code: HD67733-2-A1 , HD67733-4-A1, HD67733-5-A1)
For Website information:
www.adfweb.com? roduct=HD67733
For rice information:
www.adfweb.com? rice=HD67733-2-A1
www.adfweb.com? rice=HD67733-4-A1
www.adfweb.com? rice=HD67733-5-A1
Benefits and Main Features:
Very easy to configure
Triple Electrical isolation
Temperature range: -40°C/+85°C (-40°F/+185°F)
For other IEC 61850 products see also the following link:
Converter IEC 61850 Server to
www.adfweb.com? roduct=HD67734 (Modbus Slave
www.adfweb.com? roduct=HD67735 (Modbus TCP Master
www.adfweb.com? roduct=HD67736 (Modbus TCP Slave
Do you have your customer protocol? Then go to:
www.adfweb.com? roduct=HD67003
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
User Manual
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 2 of 30
INDEX:
age
INDEX 2
U DATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAM LE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 8
CONFIGURATION 8
OWER SU LY 9
FUNCTION MODES 10
LEDS 11
RS232 12
RS485 12
RS422 13
ETHERNET 13
USE OF COM OSITOR SW67733 14
NEW CONFIGURATION / O EN CONFIGURATION 15
SOFTWARE O TIONS 16
SET COMMUNICATION 18
IEC 61850 ACCESS 21
MODBUS SET ACCESS 22
TLS KNOWN CERTIFICATE 24
U DATE DEVICE 25
MECHANICAL DIMENSIONS 27
ORDERING INFORMATIONS 28
ACCESSORIES 28
DISCLAIMER 29
OTHER REGULATIONS AND STANDARDS 29
WARRANTIES AND TECHNICAL SU ORT 30
RETURN OLICY 30
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.
Revision
Date Author Chapter
Description
1.000 18/09/2018
Ff All First Release
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 3 of 30
SECURITY ALERT:
G
ENERAL
I
NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I
NTENDED
U
SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q
UALIFIED
P
ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R
ESIDUAL
R
ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE
CONFORMITY
The declaration is made by our company. You can send an email to [email protected] or give us a call if you need it.
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 4 of 30
EXAMPLES OF CONNECTION:
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 5 of 30
CONNECTION SCHEME:
Figure 1a: Connection scheme for HD67733- -A1
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 6 of 30
Figure 1b: Connection scheme for HD67733-4-A1
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 7 of 30
Figure 1c: Connection scheme for HD67733-5-A1
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 8 of 30
CHARACTERISTICS:
The HD67733-x-A1 are IEC 61850 / Modbus Master - Converters.
It allows for the following characteristics:
Up to 512 Modbus reading requests and 512 Modbus writing requests;
Triple isolation between RS232/RS485/RS422 - ower Supply, RS232/RS485/RS422 - Ethernet, Ethernet - ower Supply;
Two-directional information between IEC 61850 bus and Modbus bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67733 software on your C in order to perform the following:
Define the parameters of IEC 61850 line;
Define the parameters of Modbus line;
Define IEC 61850 variables that contains the data read from the Modbus slaves;
Define IEC 61850 variables that contains the data to send to the Modbus slaves;
Update the device.
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 9 of 30
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/VA]
HD67733-X-A1 3.5
HD67733-X-A1
Caution:
Do n
ot reverse the polarity power
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus Master
Document code: MN67733_ENG Revision 1.000 age 10 of 30
FUNCTION MODES:
The device has got two function modes depending on the position of the ‘Dip2 of Dip-Switch A’:
The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip2 of Dip-Switch A’ at “ON” position, is used for uploading the roject and/or Firmware.
For the operations to follow for the updating, see ‘U DATE DEVICE’ section.
According to the functioning mode, the LEDs will have specific functions, see ‘LEDS’ section.
Warning:
Dip1 of ‘Dip-Switch A’ must be at ON position to work even if the Ethernet cable is not inserted.
