ADF Web HD67D18-B2 Series Manual de usuario

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

LoRaWAN / Ethernet

Document code: MN67D18_ENG Revision 1.000 age 1 of 28

User Manual

Revision 1.000

English

LoRaWAN / Ethernet - Converter

(Order Code: HD67D18-B2-xxxMHz)

For Website information:

www.adfweb.com? roduct=HD67D18-B2

For rice information:

www.adfweb.com? rice=HD67D18-B2-868MHz

Benefits and Main Features:

Very easy to configure

ower Supply 18…35V DC and 8…24 V AC

Temperature range: -40°C/+85°C (-40°F/+185°F)

For others LoRaWAN products, see also the following links:

Converter LoRaWAN to

www.adfweb.com? roduct=HD67D01 (LoRaWAN)

www.adfweb.com? roduct=HD67D02 (LoRaWAN)

www.adfweb.com? roduct=HD67D03 (Modbus TC Master)

www.adfweb.com? roduct=HD67D04 (Modbus TC Slave)

www.adfweb.com? roduct=HD67D05 (Serial)

www.adfweb.com? roduct=HD67D15 (M-Bus)

www.adfweb.com? roduct=HD67D16 (BACnet Master)

www.adfweb.com? roduct=HD67D17 (BACnet Slave)

www.adfweb.com? roduct=HD67D19 (CAN)

www.adfweb.com? roduct=HD67D20 (CANopen)

www.adfweb.com? roduct=HD67D21 (DeviceNet Master)

www.adfweb.com? roduct=HD67D22 (DeviceNet Slave)

www.adfweb.com? roduct=HD67D23 (DMX)

www.adfweb.com? roduct=HD67D24 (EtherNet/I Master)

www.adfweb.com? roduct=HD67D25 (EtherNet/I Slave)

www.adfweb.com? roduct=HD67D26 (J1939)

www.adfweb.com? roduct=HD67D27 (KNX)

www.adfweb.com? roduct=HD67D28 (NMEA 0183)

www.adfweb.com? roduct=HD67D29 (NMEA 2000)

www.adfweb.com? roduct=HD67D30 ( ROFIBUS Master)

www.adfweb.com? roduct=HD67D31 ( ROFIBUS Slave)

www.adfweb.com? roduct=HD67D32 ( ROFINET Master)

www.adfweb.com? roduct=HD67D33 ( ROFINET Slave)

www.adfweb.com? roduct=HD67D34 (IEC61850 Client)

www.adfweb.com? roduct=HD67D35 (IEC61850 Server)

www.adfweb.com? roduct=HD67D36 (MQTT)

www.adfweb.com? roduct=HD67D37 (O C UA Client)

www.adfweb.com? roduct=HD67D38 (O C UA Server)

www.adfweb.com? roduct=HD67D39 (S7comm)

www.adfweb.com? roduct=HD67D40 (SNM Manager)

www.adfweb.com? roduct=HD67D41 (SNM Agent)

User Manual

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

LoRaWAN / Ethernet

Document code: MN67D18_ENG Revision 1.000 age 2 of 28

INDEX:

age

INDEX 2

U DATED DOCUMENTATION 2

REVISION LIST 2

WARNING 2

TRADEMARKS 2

SECURITY ALERT 3

EXAM LE OF CONNECTION 4

CONNECTION SCHEME 5

CHARACTERISTICS 6

CONFIGURATION 6

OWER SU LY 7

FUNCTION MODES 8

LEDS 9

LORAWAN 10

ETHERNET 11

USE OF COM OSITOR SW67D18 12

NEW CONFIGURATION / O EN CONFIGURATION 13

SOFTWARE O TIONS 14

SET COMMUNICATION 16

LORAWAN ACCESS 18

U DATE DEVICE 20

LORAWAN AYLOAD 22

ETHERNET ROTOCOL 23

MECHANICAL DIMENSIONS 25

ORDERING INFORMATIONS 26

ACCESSORIES 26

DISCLAIMER 27

OTHER REGULATIONS AND STANDARDS 27

WARRANTIES AND TECHNICAL SU ORT 28

RETURN OLICY 28

U DATED DOCUMENTATION:

Dear customer, we thank you for your attention and we remind you that

you need to check that the following document is:

Updated

Related to the product you own

To obtain the most recently updated document, note the “document code”

that appears at the top right-hand corner of each page of this document.

With this “Document Code” go to web page www.adfweb.com/download/

and search for the corresponding code on the page. Click on the proper

“Document Code” and download the updates.

REVISION LIST:

WARNING:

ADFweb.com reserves the right to change information in this manual about

our product without warning.

ADFweb.com is not responsible for any error this manual may contain.

TRADEMARKS:

All trademarks mentioned in this document belong to their respective

owners.

Revision

Date Author Chapter

Description

1.000 09/2/2023 Ln All First release version

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

LoRaWAN / Ethernet

Document code: MN67D18_ENG Revision 1.000 age 3 of 28

SECURITY ALERT:

ENERAL

NFORMATION

To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and

safety regulation are required for each individual application. The same applies also when using accessories.

NTENDED

Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.

independent limit switches, mechanical interlocks, etc.).

UALIFIED

ERSONNEL

The device can be used only by qualified personnel, strictly in accordance with the specifications.

Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and

who have appropriate qualifications for their job.

ESIDUAL

ISKS

The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and

operated by untrained personnel. These instructions refer to residual risks with the following symbol:

This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or

death and / or the possibility of damage.

CONFORMITY

The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

LoRaWAN / Ethernet

Document code: MN67D18_ENG Revision 1.000 age 4 of 28

EXAM LE OF CONNECTION:

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

LoRaWAN / Ethernet

Document code: MN67D18_ENG Revision 1.000 age 5 of 28

CONNECTION SCHEME:

Figure 1: Connection scheme for HD67D18-B -xxxMHz

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

LoRaWAN / Ethernet

Document code: MN67D18_ENG Revision 1.000 age 6 of 28

CHARACTERISTICS:

The HD67D18-B2 is a LoRaWAN / Ethernet Converter.

It allows the following characteristics:

Electrical isolation between LoRaWAN and ower Supply;

Mountable on 35mm Rail DIN;

Wide power supply input range: 12…35V DC and 8…24V AC;

Wide temperature range: -40°C / 85°C [-40°F / +185°F].

CONFIGURATION:

You need Compositor SW67D18 software on your C in order to perform the following:

Define the parameter of Ethernet line;

Define the parameter of LoRaWAN line;

Define the list of LoRaWAN messages in uplink and downlink to the LoRaWAN gateway;

Update the device.

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

LoRaWAN / Ethernet

Document code: MN67D18_ENG Revision 1.000 age 7 of 28

OWER SU LY:

The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.

VAC

VDC

Vmin Vmax Vmin Vmax

8V 24V 12V 35V

Consumption at 24V DC:

Device Consumption [W/VA]

HD67D18-B2-xxxMHz 3.5

HD67D18

xxxMHz

Caution: Not reverse the polarity power

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

LoRaWAN / Ethernet

Document code: MN67D18_ENG Revision 1.000 age 8 of 28

FUNCTION MODES:

The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’:

The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.

The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for upload the roject and/or Firmware.

For the operations to follow for the updating, see ‘U DATE DEVICE’ section.

According to the functioning mode, the LEDs will have specifics functions, see ‘LEDS’ section.

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

LoRaWAN / Ethernet

Document code: MN67D18_ENG Revision 1.000 age 9 of 28

LEDS:

The device has got four LEDs that are used to give information of the functioning status.

The various meanings of the LEDs are described in the table below.

LED Normal Mode Boot Mode

1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

2: LoRaWAN communication

(yellow) Blinks when LoRaWAN data is received Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

3: Ethernet communication

(yellow) Blinks when a Ethernet request is received Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

4: Error state (yellow) ON: An error in the communication busses occurs

OFF: No errors are present

Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

LoRaWAN / Ethernet

Document code: MN67D18_ENG Revision 1.000 age 10 of 28

LORAWAN:

The LoRaWAN® specification is a Low ower, Wide Area (L WA) networking protocol designed to

wirelessly connect battery operated ‘things’ to the internet in regional, national or global

networks, and targets key Internet of Things (IoT) requirements such as bi-directional

communication, end-to-end security, mobility and localization services.

LoRaWAN® network architecture is deployed in a star-of-stars topology in which gateways relay

messages between end-devices and a central network server.

The wireless communication takes advantage of the Long Range characteristics of the LoRa

physical layer, allowing a single-hop link between the end-device and one or many gateways. All

modes are capable of bi-directional communication, and there is support for multicast

addressing groups to make efficient use of spectrum during tasks such as Firmware Over-The-

Air (FOTA) upgrades or other mass distribution messages.

Converters from HD67D18 serie act as end-devices and they can communicate with one or more

LoRwaWAN Gateways.

The converters support all the standard datarates and they work both on public and private

networks.
