ADF Web HD67626-A1 Manual de usuario

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

S7comm /

SNMP Agent

Document code: MN67626_ENG Revision 1.000 age 1 of 27

User Manual

Revision 1.000

English

S7comm / SNMP Agent - Converter

(Order Code: HD67626-A1)

for Website information:

http://www.adfweb.com/? roduct=HD67626

for rice information:

http://www.adfweb.com/? rice=HD67626-A1

Benefits and Main Features:

Triple electrical isolation

Two Ethernet ports

Temperature range: -40°C/+85°C (-40°F/+185°F)

For others S7comm devices, see also the following links:

S7comm from/to …

www.adfweb.com? roduct=HD67618 (Modbus TCP S ave)

www.adfweb.com? roduct=HD67619 (PROFIBUS S ave)

www.adfweb.com? roduct=HD67620 (IEC61850 Server)

www.adfweb.com? roduct=HD67621 (Seria )

www.adfweb.com? roduct=HD67622 (Modbus S ave)

www.adfweb.com? roduct=HD67623 (CAN)

www.adfweb.com? roduct=HD67624 (CANopen)

www.adfweb.com? roduct=HD67625 (DeviceNet S ave)

www.adfweb.com? roduct=HD67627 (EtherNet/IP S ave)

www.adfweb.com? roduct=HD67628 (KNX)

www.adfweb.com? roduct=HD67629 (MQTT)

www.adfweb.com? roduct=HD67630 (BACnet S ave)

www.adfweb.com? roduct=HD67631 (Ethernet)

www.adfweb.com? roduct=HD67632 (OPC UA Server)

www.adfweb.com? roduct=HD67633 (PROFINET S ave)

www.adfweb.com? roduct=HD67D39 (LoRaWAN)

www.adfweb.com? roduct=HD67E28 (S7comm)

Do you have an your customer protocol?

See the following links:

www.adfweb.com? roduct=HD67003

Do you need to choose a device? do you want help?

Ask it to the following link:

www.adfweb.com?Cmd=helpme

Use

r Manual

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

S7comm /

SNMP Agent

Document code: MN67626_ENG Revision 1.000 age 2 of 27

INDEX:

age

INDEX 2

U DATED DOCUMENTATION 2

REVISION LIST 2

WARNING 2

TRADEMARKS 2

SECURITY ALERT 3

EXAM LE OF CONNECTION 4

CONNECTION SCHEME 5

CHARACTERISTICS 6

CONFIGURATION 6

OWER SU LY 7

FUNCTION MODES 8

LEDS 9

ETHERNET 10

USE OF COM OSITOR SW67626 11

NEW ROJECT / O EN ROJECT 12

SOFTWARE O TIONS 13

SET COMMUNICATION 15

S7COMM ACCESS 17

SET SNM ACCESS 20

MIB FILE 21

U DATE DEVICE 22

MECHANICAL DIMENSIONS 24

ORDERING INFORMATIONS 25

ACCESSORIES 25

DISCLAIMER 26

OTHER REGULATIONS AND STANDARDS 26

WARRANTIES AND TECHNICAL SU ORT 27

RETURN OLICY 27

Pagina 2 di 27

UPDATED DOCUMENTATION:

Dear customer, we thank you for your attention and we remind you that

you need to check that the following document is:

Updated

Related to the product you own

To obtain the most recently updated document, note the “document code”

that appears at the top right-hand corner of each page of this document.

With this “Document Code” go to web page www.adfweb.com/download/

and search for the corresponding code on the page. Click on the proper

“Document Code” and download the updates.

REVISION LIST:

Revision

Date Author

Chapter

Description

1.000 11/03/2021 Ff All First release version

WARNING:

ADFweb.com reserves the right to change information in this manual about

our product without warning.

ADFweb.com is not responsible for any error this manual may contain.

TRADEMARKS:

All trademarks mentioned in this document belong to their respective

owners.

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

S7comm /

SNMP Agent

Document code: MN67626_ENG Revision 1.000 age 3 of 27

SECURITY ALERT:

ENERAL

NFORMATION

To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and

safety regulation are required for each individual application. The same applies also when using accessories.

NTENDED

Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.

independent limit switches, mechanical interlocks, etc.).

UALIFIED

ERSONNEL

The device can be used only by qualified personnel, strictly in accordance with the specifications.

Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and

who have appropriate qualifications for their job.

ESIDUAL

ISKS

The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and

operated by untrained personnel. These instructions refer to residual risks with the following symbol:

This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or

death and / or the possibility of damage.

CONFORMITY

The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

S7comm /

SNMP Agent

Document code: MN67626_ENG Revision 1.000 age 4 of 27

EXAMPLE OF CONNECTION:

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

S7comm /

SNMP Agent

Document code: MN67626_ENG Revision 1.000 age 5 of 27

CONNECTION SCHEME:

Figure

: Connection scheme for HD67

626

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

S7comm /

SNMP Agent

Document code: MN67626_ENG Revision 1.000 age 6 of 27

CHARACTERISTICS:

The HD67626-A1 is a S7comm / SNM Agent Converter.

It allows the following characteristics:

Two-directional information between S7comm and SNM ;

Mountable on 35mm Rail DIN;

Wide power supply input range: 8…24V AC or 12…35V DC;

Wide temperature range: -40°C / 85°C [-40°F / +185°F].

CONFIGURATION:

You need Compositor SW67626 software on your C in order to perform the following:

Define the parameter of the SNM ;

Define the parameter of the S7comm;

Define the S7comm requests to send to the S7comm servers;

Define the SNM OIDs in read and write;

Export the MIB file;

Update the device.

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

S7comm /

SNMP Agent

Document code: MN67626_ENG Revision 1.000 age 7 of 27

POWER SUPPLY:

The devices can be powered between a wide range of tensions. For more details see the two tables below.

VAC

VDC

Vmin Vmax Vmin Vmax

HD67626-A1 8V 24V 12V 35V

Consumption at 24V DC:

Device W/VA

HD67626-A1 4

Caution: Not reverse the po arity power

HD67626-A1

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

S7comm /

SNMP Agent

Document code: MN67626_ENG Revision 1.000 age 8 of 27

FUNCTION MODES:

The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’:

The first, with Dip1 in Off position (factory setting), is used for the normal working of the device.

The second, with Dip1 in On position, is used for upload the roject/Firmware.

For the operations to follow for the updating (see ‘U DATE DEVICE’ section).

According to the functioning mode, the LEDs will have specifics functions (see ‘LEDS’ section).

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

S7comm /

SNMP Agent

Document code: MN67626_ENG Revision 1.000 age 9 of 27

LEDS:

The device has got six LEDs that are used to give information of the functioning status.

The various meanings of the LEDs are described in the table below.

LED Norma Mode Boot Mode

1: ON [supply voltage ]

(green)

ON: Device powered

OFF: Device not powered

ON: Device powered

OFF: Device not powered

2: Device State (green) Blinks slowly (~1Hz) B inks quick y: Boot state

B inks very s ow y (~0.5Hz): update in progress

3: SNM communication

(green) Blinks when a SNM response is received B inks quick y: Boot state

B inks very s ow y (~0.5Hz): update in progress

4: S7comm communication

(green) Blinks when a S7comm response is received B inks quick y: Boot state

B inks very s ow y (~0.5Hz): update in progress

5: Not used (green) OFF B inks quick y: Boot state

B inks very s ow y (~0.5Hz): update in progress

6: Not used (green) OFF B inks quick y: Boot state

B inks very s ow y (~0.5Hz): update in progress

Industrial Electronic Devices

ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31

User Manual

S7comm /

SNMP Agent

Document code: MN67626_ENG Revision 1.000 age 10 of 27

ETHERNET:

The Ethernet connection must be made using Connector3 or Connector4 of HD67626-A1 with at least a Category 5E cable. The maximum

length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To

connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a C/ LC/other is recommended

the use of a cross cable.
