ADDONICS TECHNOLOGIES

Model: RT5835HMEU

I. Installing drive into the RAID Tower V

Step 1

Use a Philips screwdriver to secure the 3.5”

SATA hard drive to the drive tray

Step 2

Slide the tray into the Disk Array drive bay.

Note: It is recommended to fill up the RAID

Tower V with SATA drives from right to left

and top to bottom. This is to help in identifying

which drives connect to which ports for easier

troubleshooting.

II. Connecting the power cable and RAID Tower V to the

computer

a. Connect the power cord provided from the wall outlet to the back of

the RAID Tower.

b. Make sure the power is off (power LED light should be off).

c. Connect either the provided USB or eSATA cable from the back of

the RAID Tower to the computer. We recommend connecting the

eSATA port for best performance if this port is available on your

computer.

III. Power on/off control

Turn on the power to the RAID Tower Mini by pressing the power

button on the front. The power LED light should lit indicating the power

is on.

IV. Setting RAID on the HPM

1. Attach the SATA hard drives (up to 4) to the SATA ports on the

Hardware Port Multiplier (HPM) using SATA cables. It is

recommended to connect drives to the SATA ports 1 to 4

successively.

2. Set the Rotary switch to the RAID mode required.

3. Push the RAID setting button with a ballpoint pen tip while the HPM

is turned off.

4. While holding the RAID setting button, turn on the HPM and SATA

hard drives and continue to hold button for at least 5 seconds.

Note: The onboard LED's for the eSATA and USB will start blinking

while holding down the raid setting button. Once the raid

setting button is released, the PM Health LED will blink 4-6

times.

If the PM Health LED stops blinking, the raid set is set

correctly. If the PM Health LED lights up as solid green, it is a

bad setup. You need to repeat setting up the raid again.

LED pins

Pin 1

SATA

Port 2

SATA

Port 4

SATA

Port 1

SATA

Port 3

Photo identifying SATA port s on HPM

Power LED

Power Switch

USB port

eSATA port

RAID config

rotary switch

RAID

setting

button

Power Connector

Power Switch

Use a ballpoint pen

tip to press the

RAID Setting Button

(LED 1) HPM Health

(LED 3) USB Status

(LED 2) eSATA Status

(LED 1) HPM Health

(LED 3) USB Status

(LED 2) eSATA Status

HPM 1 (Top disk array)

HPM 2 (Bottom disk array)

Set A (4-drive HPM)

Set B

(4-drive HPM)

Set B (4-drive HPM)

Set A (4-drive HPM)

ADDONICS TECHNOLOGIES

Model: RT5835HMEU

Instruction for Special RAID Modes:

BIG 2 - 2 Drives Spanned

o Note: Do not connect more than 2 SATA drives to the hardware port

multiplier. Doing so will hang the system when you configure the

raid.

o For SATA drives with different capacities, the hardware port

multiplier will use the smallest drive capacity of the 2 drives

connected to create the total partition size.

FAST 2 - 2 Drives Striped

o Note: Do not connect more than 2 SATA drives to the hardware port

multiplier. Doing so will hang the system when you configure the

raid.

Verify RAID Setting on the HPM

Note: Disconnect the HPM from host when verifying the RAID setting.

It is assumed that you have already connected the SATA drives and set

up the raid mode when verifying the raid setting.

1. Turn on the power for RAID tower mini.

2. Push the RAID setting button with the tool provided. Using the

table below, verify if the LEDs are lighting up. The selected

LEDs will light up for 2 seconds followed by a blink and cycles

back.

RAID Mode

LEDs

BIG 2

LEDs 1, 2 & 3 all OFF

BIG 4

3 ON, 2 & 1 OFF

FAST 2

2 ON, 3 & 1 OFF

FAST 4

1 ON, 3 & 2 OFF

SAFE FAST

3 & 2 ON, 1 OFF

SAFE 2

3 & 1 ON, 2 OFF

RAID 5

2 & 1 ON, 3 OFF

RAID 5 + S

3, 2 & 1 all ON

LED reference:

LED 1 - HPM Health

LED 2 - eSATA Status

LED 3 - USB Status

TECHNICAL SUPPORT

Phone: 408-453-6212

Hours: 8:30 am - 6:00 pm PST

Email: http://www.addonics.com/support/query/
