ADDER ALIF 2112T Manual de usuario

AdderLink Inﬁnity ALIF 2112T

Quick Start Guide

ALIF 2112T ALIF Receiver

The VNC port

Uses the standard Ethernet port on the left

side of the front panel and provides lower-

bandwidth image video feeds for use across

standard networks and the wider Internet.

The Inﬁnity port

Uses either the Gigabit Ethernet port, or an

optional ﬁbre optic module, on the right

side of the front panel and provides high

resolution DVI-D image and audio feeds.

The

ALIF 2112T

consists of two

distinct

Ûsections Ü

Inﬁnity port conﬁguration

• IfALIFTXandRXunitsaredirectlyconnected,noconguration

actionisrequired,providedthattheyhavetheirfactorydefault

settings in place. If the standard settings have been changed in a

previousinstallation,youmerelyneedtoperformafactoryreset

on each unit (see below).

• WhereALIFunitsareconnectedvianetworklinks,youwillneed

tospecifytheirnetworkaddressdetails.Thiscanbedoneby

connectingacomputersystemtemporarilytoeachALIFunit

andusingtheInnitybrowser-basedcongurationutility.This

congurationutilityalsoallowsnumerousothersettingstobe

altered.

Note: For basic one-to-one installations, the factory default

addresses may be acceptable for immediate use within your

network without the need to use a conﬁguration utility or change

their values: TX unit (169.254.1.33), RX unit (169.254.1.32).

Manual factory reset

Use to return an ALIF 2112T unit to its default conﬁguration.

1 RemovepowerfromtheALIFunit.

2 Locate the small hole on the front panel, next to the left-hand

Ethernet socket.

3 Push a narrow implement (e.g. a straightened-out paper clip) into

the hole and hold it in. Meanwhile, power on the unit.

 Afteraroundeightseconds,whenthefactoryresethas

completed, ﬁve of the front panel indicators will ﬂash for a period

of three seconds to indicate a successful reset operation.

4 Removetheimplementandthenre-applypowertostarttheunit

in its default conﬁguration.

ALIF 2112T - rear panel

AUX

COMPUTER

INDOOR

USE ONLY OPTIONS

DVI-D-1

5V 2.5A

DVI-D-2

IN OUT

Primary video

input

Audio

line

in/out

AUX

(serial)

port

USB

port

Conﬁguration

switches

Power

input

Secondary

video

input

ALIF 2112T - front panel

VNC port Inﬁnity portIndicators

• VNC On when a VNC viewer is connected.

• SER On when the serial port is enabled and active.

• AUD On when audio is enabled and active.

• USB On when USB is enabled and active.

• DVI On when DVI video is enabled and active.

• PWR Power indicator.

Browser-based conﬁguration utility

Tousethebrowser-basedcongurationutility,linkacomputervia

anetworkswitchtotheInnityportoftheALIFunitusingaGigabit

Ethernetconnection.Thiscongurationutilityallowsyoutoperform

all of the following functions:

• View/edittheIPnetworkaddressandnetmask,

• CongureseparateIPnetworkaddressesforvideo,audioandUSB,

• Congurevideobandwidthsettings(onTXunits),

• Viewthecurrentvideooutput(onTXunits),

• Performarmwareupgrade,

• Performafactoryreset.

To access the browser-based conﬁguration utility

1 ConnecttheInnityunitandacomputerviaanetwork.

2 RunawebbrowseronyourcomputerandentertheIPaddressof

theInnityunit,e.g.http://169.254.1.33

The default settings for the ALIF 2112T are as follows:

• TX unit - IP address: 169.254.1.33 Netmask: 255.255.255.0

Notes:

Where the address of a unit is not known, perform a manual

factory reset (see page 2) to restore the default address.

Your computer must be on the same subnet as the ALIF 2112T

unit.

TX (transmitter) unit conﬁguration

IntheALIFsystem,themostimportantcongurationdetailsare

dictatedbyRXunits.Thus,theTXunitsetupisconcernedonlywith

three main factors:

• ItsIPaddress,

• Thedatastreamstoenable/disable,and

• Videosignaloptimization.

In a Gigabit Ethernet network with sufﬁcient bandwidth, changes

to the Video Conﬁgurationpageshouldnotbenecessary.If

adjustmentsarerequired,pleaseseetheAdderLinkInnity2112T

full user guide for details.

For VNC port conﬁguration, please see the rear page

IMPORTANT:PleaseseethefullALIF2112T

userguideforsafety,warrantyandregulatory

information. The full user guide is available

from www.adder.com.

©2013AdderTechnologyLimited•Alltrademarksareacknowledged.

PartNo.MAN-ALIF2112-QS-ADDER•Release1.0a

Using the VNC viewer

1 On a network connected computer, locate and

select the VNC viewer icon 

A connection details dialoguewillbedisplayed:

Enter the ALIF 2112T

address here and

click OK

If required, select the

encryption mode

2 Inthe‘Server:’entry,typethenetworkaddressthathasbeen

conﬁgured for the VNC port of the ALIF 2112T unit.

3 ClicktheOKbutton.Theviewerwindowmayopenstraightaway

orthesystemmayrequireuserauthentication,inwhichcasean

authenticationdialoguewillbedisplayed:

4 EnteryourUsernameandPasswordandclicktheOKbutton.

The viewer window should now open.

VNC port conﬁguration

To download the VNC Viewer

1 Connect the ALIF 2112T VNC port to an IP network where a

suitable computer is available on the same subnet (please see

the Installation chapter of the ALIF 2112T full user guide for

connection details).

2 On that

computer, open

an internet

browser and enter

the default local

IPaddressusedby

the ALIF 2112T:

http://192.168.1.42

The ALIF 2112T

welcome screen

should be

displayed:

Web: www.adder.com

Contact: www.adder.com/contact-details

Support: forum.adder.com
