HRM-238 List 1 HiGain Retrofit Management Shelf
User Manual
LTPH-UM-1237-04
ii July 21, 2004 HRM-238 List 1
Revision History
To order copies of this manual, use document catalog number LTPH-UM-1237-04. (Copies of this publication
can be downloaded from the ADC website at www.adc.com. To order a hard copy, please contact your sales
representative.)
Copyright
July 21, 2004
© 2004 ADC Telecommunications, Inc. All rights reserved.
Trademark Information
ADC and HiGain are registered trademarks of ADC Telecommunications, Inc. No right, license, or interest to such trademarks
is granted hereunder, and you agree that no such right, license, or interest shall be asserted by you with respect to such
trademark.
Other product names mentioned in this document are used for identification purposes only and may be trademarks or
registered trademarks of their respective companies.
Disclaimer of Liability
Information contained in this document is company private to ADC Telecommunications, and shall not be modified, used,
copied, reproduced or disclosed in whole or in part without the written consent of ADC.
Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice.
In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits, and ADC further
disclaims any and all liability for indirect, incidental, special, consequential or other similar damages. This disclaimer of
liability applies to all products, publications and services during and after the warranty period.
Issue Release Date Revisions Made
1May 9, 2003 Initial release
2March 31, 2004 Updated Certificate and Warranty and Product Support Sections.
3April 28, 2004 Misc technical updates
4July 21, 2004 Misc technical updates/additions.
LTPH-UM-1237-04 Using This Manual
HRM-238 List 1 July 21, 2004 iii
USING THIS MANUAL
The following conventions are used in this manual where applicable:
•Monospace type indicates screen text.
•Keys you press are indicated by small icons such as or . Key combinations to be pressed
simultaneously are indicated with a plus sign as follows: + .
•Items you select are in bold.
The following types of messages, identified by icons, may appear in text.
For a list of abbreviations used in this document, refer to “Appendix C - Abbreviations” on page 15.
INSPECTING SHIPMENT
Upon receipt of the equipment:
•Unpack each container and inspect the contents for signs of damage. If the equipment has been damaged in
transit, immediately report the extent of damage to the transportation company and to ADC
Telecommunications, Inc. Order replacement equipment, if necessary.
•Check the packing list to ensure complete and accurate shipment of each listed item. If the shipment is short
or irregular, contact ADC as described in “Appendix B - Product Support” on page 14. If you must store the
equipment for a prolonged period, store the equipment in its original container.
Notes provide information about special circumstances.
General cautions indicate the possibility of personal injury, product failure, or equipment
damage if instructions are ignored or not completely followed.
An Electrostatic Discharge (ESD) caution indicates that a device or assembly is susceptible
to damage from electrostatic discharge.
An electrical shock warning indicates the presence of a dangerous level of electrical power
and the potential for serious personal injury or equipment damage.
YENTER
CTRL ESC
Inspecting Shipment LTPH-UM-1237-04
iv July 21, 2004 HRM-238 List 1
LTPH-UM-1237-04 Table of Contents
HRM-238 List 1 July 21, 2004 v
TABLE OF CONTENTS
Overview ____________________________________________________________________________ 1
Features..............................................................................................................................................1
Operational Capabilities.....................................................................................................................2
Application ..........................................................................................................................2
Management Cabling...........................................................................................................4
Installation___________________________________________________________________________ 5
Inspecting Your Shipment .................................................................................................................5
Installing the HRM-238 Shelf............................................................................................................5
Installing Frame Ground and Battery Power .....................................................................................5
Installing Communication Wiring .....................................................................................................6
Connect NMA Wiring .........................................................................................................7
Connect to a LAN or Interconnect Shelves.........................................................................9
Connect to a Computer, Terminal, or Modem.....................................................................9
Identifying Alarms...........................................................................................................................11
Turning Up the System....................................................................................................................11
Insert Fuse..........................................................................................................................11
Verify Cabling...................................................................................................................12
Secure Cabling...................................................................................................................12
Installing the Management Unit(s) ..................................................................................................12
Appendix A - Specifications____________________________________________________________ 13
Appendix B - Product Support _________________________________________________________ 14
Appendix C - Abbreviations ___________________________________________________________ 15
Certification and Warranty______________________________________________ Inside Back Cover
List of Figures LTPH-UM-1237-04
vi July 21, 2004 HRM-238 List 1
LIST OF FIGURES
1. HRM-238 List 1 (front view) ........................................................................................................................ 1
2. Recommended Network Setup for 220 Type Shelves................................................................................... 2
3. Recommended Network Setup for 3190 Type Shelves................................................................................. 3
4. Recommended Network Setup for DDM+ Type Shelves ............................................................................. 3
5. HRM-238 Shelf Backplane Connectors (back view) .................................................................................... 4
6. Shelf with Brackets Positioned for 19-inch Rack.......................................................................................... 5
7. Connect -48 Vdc and Frame Grounds to TB1............................................................................................... 6
8. Connect NMA Wiring ................................................................................................................................... 7
9. Using BNC Connector................................................................................................................................... 9
10. AUX or OS Connectors................................................................................................................................. 9
11. Alarm Relay Wire-Wrap Pins...................................................................................................................... 11
LTPH-UM-1237-04 List of Tables
HRM-238 List 1 July 21, 2004 vii
LIST OF TABLES
1.HRM-238 Connectors ......................................................................................................................................4
2.Terminal Block (TB1)......................................................................................................................................6
3.P1 and P6 NMA Connectors ............................................................................................................................8
4.BNC Connector J1 and J3 ................................................................................................................................9
5.AUX P3 and P5 Connectors...........................................................................................................................10
6.OS Port P2 and P4..........................................................................................................................................10
7.Alarm J13 and J14 Pinouts.............................................................................................................................11
List of Tables LTPH-UM-1237-04
viii July 21, 2004 HRM-238 List 1
LTPH-UM-1237-04 Overview
HRM-238 List 1 July 21, 2004 1
OVERVIEW
The HiGain®HRM-238 List 1 is a two-slot HiGain Retrofit Management (HRM) shelf. This shelf fits into either
a 19- or 23-inch Central Office (CO) equipment rack. It accommodates up to two HiGain management units
(HMU-319s). It is used in conjunction with 220-type, unmanaged 3190 type, and DDM+ type mechanic shelves
to manage HiGain line units.
The HRM-238 shelf, with two management units installed, provides network management capabilities for a
maximum of 56 HiGain line units (one 3190 or DDM+ or two 220 shelves). Each management unit in the
HRM-238 shelf can manage up to 28 line units.
The HMU-319 management unit installs horizontally into the 4 ¾-inch slots labeled A or B on the HRM-238 shelf
(Figure 1). Each management unit connects to the shelf backplane through a 96-pin DIN connector.
Figure 1. HRM-238 List 1 (front view)
FEATURES
Standard features include:
•50-pin Amp-type connectors for connection between the management units in the HRM-238 shelf and
previously unmanaged HiGain line units in 220, 3190, or DDM+ mechanics shelves.
•DB-25 connectors for connection to a computer, terminal, or modem
•British Naval Connector (BNC) for connection to a Local Area Network (LAN) or to a HMU-319 multi-shelf
connection
•screw-type terminals for -48 Vdc power connection and grounding
•23 wire-wrap pins to monitor alarm relay activity
AB
96-pin DIN
connector (J2) 96-pin DIN
connector (J4)
H0543-A
Overview LTPH-UM-1237-04
2 July 21, 2004 HRM-238 List 1
OPERATIONAL CAPABILITIES
Application
With two HMU-319 management units installed, the HRM-238 shelf provides network management for up to 56
HiGain line units.
Recommended Network Setup for 220 Type Shelves
The configuration shown in Figure 2 is the recommended setup for 220 type mechanics shelves. Position the
HRM-238 shelf between the 220 type shelves, with up to two 220-type shelves above and two below. This limits
the distance for the wire leads between the connectors for the management units and the line units they manage.
Figure 2 shows the HRM-238 shelf from the rear view with the A-side connectors on the right and the B-side
connectors on the left. The leads from the HRM-238 shelf connector attach to the Network Management Agent
(NMA) pins on the rear of the 220-type mechanics shelves for each line unit managed. The NMA pin on 220 type
chassis is pin 46.
Figure 2. Recommended Network Setup for 220 Type Shelves
HCS-417/418
HCS-417/418
HCS-417/418
HCS-417/418
HRM-238
-48V A
-48V A
-48V A
-48V A
-48V B
-48V B
-48V B
-48V B
NMA 1 to 14 B
NMA 15 to 28 B
NMA 1 to 28 B
NMA 1 to 14 A
Network B Network A
TB1
CO -48V
Supply
NMA 15 to 28 A
NMA 1 to 28 A
H0544-B
