DUAL CONTROLLER

DURASTOR 6200S/7200S

CONFIGURATION GUIDE

DuraStor 6200S and 7200S.book Page 1 Tuesday, July 9, 2002 3:25 PM

DuraStor 6200S/7200S

External RAID Controller

Dual Controller

Configuration Guide

DuraStor 6200S and 7200S.book Page i Tuesday, July 9, 2002 3:25 PM

reproduced, stored in a retrieval system, or transmitted in any form or by any

means, electronic, mechanical, photocopying, recording or otherwise, without the

prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.

Trademarks

Adaptec and the Adaptec logo are trademarks of Adaptec, Inc., which may be

registered in some jurisdictions.

Windows 95, Windows 98, Windows NT, and Windows 2000 are trademarks of

Microsoft Corporation in the US and other countries, used under license.

All other trademarks are the property of their respective owners.

Changes

The material in this document is for information only and is subject to change

without notice. While reasonable efforts have been made in the preparation of this

document to assure its accuracy, Adaptec, Inc. assumes no liability resulting from

errors or omissions in this document, or from the use of the information contained

herein.

Adaptec reserves the right to make changes in the product design without

reservation and without notification to its users.

Disclaimer

IF THIS PRODUCT DIRECTS YOU TO COPY MATERIALS, YOU MUST HAVE

PERMISSION FROM THE COPYRIGHT OWNER OF THE MATERIALS TO AVOID

VIOLATING THE LAW WHICH COULD RESULT IN DAMAGES OR OTHER

REMEDIES.

DuraStor 6200S and 7200S.book Page ii Tuesday, July 9, 2002 3:25 PM

iii

Adaptec Customer Support

If you have questions about installing or using your Adaptec product, check this

document first—you will find answers to most of your questions here. If you need

further assistance, use the support options listed below.

Technical Support Identification (TSID) Number

■Before contacting Technical Support, you need your unique 12-digit TSID

number. The TSID number identifies your product and support status.

■The TSID number is included on two white, bar-coded labels, like the example

below.

■Affix a copy of the TSID label to the cover of your Installation Guide so that you

don’t lose it.

Support Options

■Search the Adaptec Support Knowledgebase (ASK) at ask.adaptec.com for

articles, troubleshooting tips, and frequently asked questions for your product.

■For support via Email, submit your question to Adaptec’s Technical Support

Specialists at ask.adaptec.com.

■For support via telephone, consult the Read This! card included in your product

package, or find the technical support telephone number on www.adaptec.com.

DuraStor 6200S and 7200S.book Page iii Tuesday, July 9, 2002 3:25 PM

Installation and Configuration

In this Guide

This document describes how to install the 6200S SCSI and the

7200S Fibre Channel RAID controllers into a DuraStor External

RAID subsystem to create a dual-controller configuration.

System Requirements 2

Installation Overview 2

Upgrading the Controller Firmware 3

Changing the Controller’s Operating Mode 8

Verifying the Controller’s Operating Mode 10

DuraStor 6200S and 7200S.book Page 1 Tuesday, July 9, 2002 3:25 PM

DuraStor 6200S/7200S Dual Controller Configuration Guide

System Requirements

To work in a dual-controller environment, both controllers must

have the same:

■amount of memory installed.

■firmware version. See Upgrading the Controller Firmware on

page 3.

Installation Overview

Follow the installation process in this guide to insure that both

controllers are installed and configured correctly.

The installation process includes the following tasks:

1Verify that both the primary and secondary controllers have the

same amount of memory.

2Verify that both controllers have the latest version of firmware.

See Verifying the Firmware Version on Your Controller on page 3.

If necessary, you can download a newer version of the firmware

from www.adaptec.com.

3Remove the primary controller. Refer to the DuraStor Installation

and User’s Guide.

4Install the second controller into the Controller 1 bay. Refer to

the DuraStor Installation and User’s Guide.

Note: On the 6220SS, 7220SS, and 6200SR, the Controller 1 bay

is the left-most controller bay. On the 6320SS and 7320SS, the

Controller 1 bay is the lower controller bay.

The second controller now becomes the primary controller.

5Change the mode of the new primary controller. See Changing

the Controller’s Operating Mode on page 8.

6Hot-plug the new secondary controller into the Controller 2

bay. Refer to the DuraStor Installation and User’s Guide.

DuraStor 6200S and 7200S.book Page 2 Tuesday, July 9, 2002 3:25 PM

Upgrading the Controller Firmware

This section describes how to upgrade the firmware of your

DuraStor RAID controller. Adaptec recommends that you use the

latest version of the firmware for both of your controllers. You can

visit www.adaptec.com to download the latest firmware release.

Before upgrading the controller firmware, verify the version

already installed on your controller.

Verifying the Firmware Version on Your Controller

To verify the firmware version:

1Run a terminal emulator program or start the terminal. The

screen shots included in this procedure show a Windows

HyperTerminal session.

2Connect to COM 1 if you are using the COM 1 port.

3Set the port settings to:

■Baud rate: 115,200 bps

■Data bits: 8

■Parity: None

■Stop bits: 1

■Flow control: Xon/Xoff

4Press Ctrl+R to refresh the terminal screen.

5Press Enter to display the System Menu in the Adaptec Disk

Array Administrator window.

DuraStor 6200S and 7200S.book Page 3 Tuesday, July 9, 2002 3:25 PM

DuraStor 6200S/7200S Dual Controller Configuration Guide

6Select Utilities Menu and press Enter.

7Select Hardware Information.

The Base Level indicates the firmware version of the controller.

If the firmware version is not the latest version identified on the

Adaptec web site, be sure to download the current version

before proceeding.

DuraStor 6200S and 7200S.book Page 4 Tuesday, July 9, 2002 3:25 PM

Upgrading the Controller Firmware

Upgrading the Firmware

To upgrade the firmware on both the primary and secondary

controllers:

1From the System Menu, select Shutdown/Restart.

2Select Yes and then press Enter to confirm the shutdown.

3Press Enter again to restart the system.

4After the restart, hold down the Space Bar when prompted. The

Flash Utility menu appears.

5Select option 3. XMODEM transfer protocol.

The message, “Ready to receive xmodem download.” appears.

DuraStor 6200S and 7200S.book Page 5 Tuesday, July 9, 2002 3:25 PM

DuraStor 6200S/7200S Dual Controller Configuration Guide

6From the terminal menu, select Transfer, then Send File.

7Click Browse to navigate to the firmware file and click Open.

Note: If you downloaded a newer version of the firmware

from www.adaptec.com, navigate to the directory where you

saved the file.

An example of the firmware file name is shown in the Filename

field.

8Verify that the protocol is set to Xmodem and click Send. The

upgrade takes about 3 minutes.
