M Series Processor User Manual - Page 1 of 26
M Series Processor User Manual - Page 3 of 26
Contents
1.0 Introduction.........................................................................................................................5
2.0 Features...............................................................................................................................6
3.0 Front Panel Functions...........................................................................................................7
4.0 Rear Panel Functions............................................................................................................8
5.0 Powering Up the Device.......................................................................................................9
6.0 Operating the Device........................................................................................................10
6.1 Input menus.......................................................................................10
6.2 Output Menus....................................................................................12
6.3 System Menus....................................................................................16
7.0 Quick Reference................................................................................................................20
8.0 PC Control Software...........................................................................................................21
9.0 Specifications....................................................................................................................22
10.0 Warranty...........................................................................................................................24
M Series Processor User Manual - Page 5 of 26
The M Series Processor is a complete 4 input - 8 output digital loudspeaker management system designed for the
touring or fixed sound installation markets. The absolute latest in available technology is utilized with 32-bit (40-bit
extended) floating point processors and high performance 24-bit Analog Converters. The high-bit DSP prevents
noise and distortion induced by truncation errors of the commonly used 24-bit fixed-point devices. A complete
set of parameters include I/O levels, delay, polarity, 6 bands of parametric EQ per channel, multiple crossover
selections and full function limiters. Precise frequency control is achieved with its 1 Hz resolution. Inputs and outputs
can be routed in multiple configuration to meet any requirements. The M Series Processor can be controlled or
configured in real time on the front panel or with the intuitive PC GUI accessed via the RS-232 interface. Software
upgrade for CPU and DSP via PC keeps the device current with newly developed algorithms and functions once
available. Multiple setup storage and system security complete this professional package.
1.0 Introduction
M Series Processor User Manual - Page 6 of 26
•4 Inputs and 8 Outputs with flexible routing
•32-bit (40-bit extended) floating point DSP
•48/96kHz Sampling Rate Selectable
•High Performance 24-bit A/D Converters
•1 Hz Frequency Resolution
•6 Parametric Equalizers for each Input and Output
•Multiple Crossover types with Full Function Limiters
•Precise Level, Polarity and Delay
•CPU and DSP upgrade via PC
•Individual Channel Buttons with Linking capability
•4-Line x 26 Character Backlit LCD Display
•Full 5-segment LED’s on every Input and Output
•Storage of up to 30 Program Setups
•Multiple Levels of Security Locks
•RS-232 Interface for PC Control and Configuration
•Future options available
2.0 Features
M Series Processor User Manual - Page 7 of 26
1. Mute keys - Mute/Unmute input and output channels. When an input channel is muted, a red LED will come
on for indication.
2. Gain/Menu keys - Selects the corresponding channel for the LCD menu display and is acknowledged by a
green LED. The last modified menu will be displayed on the LCD. Linking multiple channels is accomplished by
pressing and holding the first channel key, then pushing the other desired channels. This eases programming for
same parameters across multiple channels. Multiple Inputs can be linked together and multiple outputs can be
linked together. Inputs and Outputs are linked separately.
3. Peak Level LED - Indicates the current peak level of the Signal: Signal (-42dB), -12dB, -6dB, -3dB, Over/Limit.
The Input Over LED references to the device’s maximum headroom. The Output Limit LED references to the
threshold of the limiter.
4. LCD - Shows all the necessary information to control the unit.
5. Menu Control keys - There are 6 menu keys: <<Menu (Menu Down), Menu>> (Menu Up), <<Cursor (Cursor
Down), Cursor>> (Cursor Up), Enter/Sys/Speed and Exit. The functions of each key is explained below:
<<Menu: Previous menu screen
Menu>>: Next menu screen
<<Cursor: Previous cursor in the menu screen
Cursor>>: Next cursor in the menu Screen
Enter/Sys/Speed: Enter is used only in the System Menu to proceed with selected actions
Sys enters the System Menu from the main menu
Speed modifies delay and frequency (1 Hz resolution mode) data values by
100X.
Exit: Exit to the Main Menu
6. Rotary Thumb Wheel - Changes parameter data values. The wheel has travel velocity sensing which ease
large incremental data modifications. For modifying delay and frequency (1 Hz resolution), pressing the Speed
key simultaneously will increment/decrement the data value by 100X.
3.0 Front Panel Functions
M Series Processor User Manual - Page 8 of 26
1. Power switch - Controls power On/Off.
2. Main Power - Connects via a standard IEC socket. A compatible power cord is supplied with the unit. The
voltage input is either 115VAC or 230VAC and is clearly specified on the unit. Voltage requirement has to be
stated upon ordering.
3. Main Fuse - T200mA-250V. Slow blow type.
4. RS232 - a standard female DB9 socket. A straight through cable is required for PC connection.
5. Option slot - Option slot for future use.
6. XLR input and outputs - Separate 3-pin XLR connectors are provided for each audio input and output. The
device’s output stage employs the balanced impedance topology. All I/O connectors have pin 1 as ground
(shield), pin 2 as + and pin 3 as -.
4.0 Rear Panel Functions
M Series Processor User Manual - Page 9 of 26
• After powering up the unit, the following initialization screen is displayed on the LCD:
*** ADAMSON M SERIES ***
** DLP-4080 CONTROLLER ***
------ INITIALIZING ------
• The initialization process takes about 8 seconds and during that period the unit boots and displays the M Series
Processor’s firmware version.
• After the initialization process is finished the M Series Processor displays its main screen:
*** ADAMSON M SERIES ***
******** DLP-4080 ********
PROGRAM:01 XXXXXXXXXXXX
• The screen shows the current program number and program name assigned to the unit. The program
assigned is always the last program the user recalled or stored before powering down the unit.
• Now the M Series Processor is now ready to operate.
5.0 Powering Up the Device
M Series Processor User Manual - Page 10 of 26
Tips: Channel Linking - If the user presses one of the Input or Output Menu keys, holds it down and press any other
Menu key(s) in the same group (Input or Output group), then the channels are linked together. The green menu
LEDs for the linked channels are lit. Any modification of the data for the selected channel will be applied to the
linked channels as well. To cancel the linking, just press any other Menu key or the Sys key after releasing the held
key.
6.0 Operating The Device
