ADA INSTRUMENTS CUBE 360 Manual de usuario

Line Laser

OPERATING MANUAL

CUBE 360

adainstruments.com

2English

vertical line

horizontal line

90°

THE MANUFACTURE RESERVES THE RIGHT TO MAKE CHANGES (NOT

HAVING AN IMPACT ON THE SPECIFICATIONS) TO THE DESIGN,

COMPLETE SET WITHOUT GIVING PRIOR WARNING.

APPLICATION

Line laser ADA Cube 360 is designed to check the horizontal and vertical

position of the surfaces of the elements of building structures and also

to transfer the angle of inclination of the structural part to similar parts

during construction and installation works.

SPECIFICATIONS

Laser beam ................................................

Horizontal line 360° vertical line

Light sources ............................................. 2 laser diodes with laser emission

wave length of 620-690nm

Laser safety class ..................................... Class 2, <1mW

Accuracy ..................................................... ±1/8 in at 30 ft (3 mm/10 m)

Self-leveling range ................................... ±4°

Operating range with/without receiver ...... 230/65 ft (70/20 m)

Power source ............................................ 3 alkaline batteries, AA type

Operation time......................................... Approx.5-8 hours, if everything is on

Tripod thread ............................................ 2x1/4”

Operating temperature ......................... 23º F to 113º F (-5°C +45°C)

Weight ...........................................................0,79 lb (390 g)

LASER LINES

FEATURES

1. Laser lines on/o

2. Indoor/outdoor operating mode

3. Battery compartment

4. Tripod mount 1/4’’

5. Compensator switch (ON/X/OFF)

6. Vertical laser window

7. Horizontal laser window

English

4English

CHANGE OF BATTERIES

Open battery compartment. Insert batteries. Take care to correct polarity.

Close battery compartment. ATTENTION: If you are not going to use instru-

ment for a long time, take out batteries.

OPERATION

Cube 360 is a reliable and convenient line laser. It will be irreplaceable

tool for many years. Before use, remove battery compartment cover. In-

sert three batteries into battery compartment with proper polarity, then

put the cover back. Set the compensator locking grip (5) into ON position,

two laser beams will be on. If the switch is ON,that means the power is on

and the compensator is working. Visual alarm (blinking line) and audible

signal indicate that the device was not installed within the compensation

range ± 4 º. To properly work align the unit in a horizontal plane. If the

switch (5) is in intermediate position, that means the power is opened,the

compensation is still locked, but it will not warn if you issue the slope. It’s

the hand-mode. If the switch (5) is OFF, that means that the line laser is

o, the compensator is also locked. Press button (1) only once- horizontal

beam will turn on. Press the button (1) one more time - vertical laser beam

will turn on. Again press the button (1) - horizontal and vertical beams will

turn on. Press button (2) once. Otdoor mode is activated. Press button (2)

one more time. The line laser begins to work in indoor mode.

TO CHECK THE ACCURACY OF LINE LASER (SLOPE OF PLANE)

Place line laser on the tripod 5m away from the wall so the horizontal laser

line will be directed to the wall. Switch on the power. The line laser starts

to self-level. Mark point A on the wall to show the contact of laser beam

with the wall. Turn the line laser by 90° and mark points В, С, D on the wall.

Measure distance “h” between the highest and lowest points (these are A

and D points in the picture). If “h”is ≤ 6 mm, the line laser accuracy is good.

If “h” exceeds 6 mm, apply service center.

TO CHECK PLUMB

Choose a wall and set laser 5 m away from the wall. Hang a plumb with the

length 2.5 m on the wall. Turn on the line laser and make the vertical laser

line meet the point of the plumb. The accuracy of the line is in the range if

the vertical line doesn’t exceed (up or down) the accuracy that is shown in

the specications (±3 mm/10 m). If the accuracy isn’t corresponding with

claimed accuracy, contact the authorized service center.

Note: Because of construction of laser emitter laser beam may be unho-

mogeneous and has dierent intensity of brightness along the perimeter

in dierent light conditions. Unhomogeneous of laser beam: laser patch of

light but the center of laser beam is identied. Dierent laser beam bright-

ness: dierence of intensity is up to 50%.

PRODUCT LIFE

Product life of the tool is 7 years. The battery and the tool should never

be placed in municipal waste. Date of production, manufacturer’s contact

information, country of origin are indicated on the product sticker.

CARE AND CLEANING

Please handle line laser with care. Clean with soft cloth only after any use.

If necessary damp cloth with some water. If instrument is wet clean and

dry it carefully. Pack it up only if it is perfectly dry. Transport in original

container/case only.

Note: During transport On/O compensator lock (5) must be set to posi-

tion “OFF”. Disregard may lead to damage of compensator.

SPECIFIC REASONS FOR ERRONEOUS MEASURING RESULTS

• Measurements through glass or plastic windows;

• Dirty laser emitting window;

• After line laser has been dropped or hit. Please check the accuracy;

• Large uctuation of temperature: if instrument will beused in cold areas

English

6English

after it has been stored in warm areas (or the other way round) please wait

some minutes before carrying out measurements.

ELECTROMAGNETIC ACCEPTABILITY (EMC)

• It cannot be completely excluded that this instrument will disturb other

instruments (e.g. navigation systems);

• will be disturbed by other instruments (e.g. intensive electromagnetic ra-

diation nearby industrial facilities or radio transmitters).

LASER CLASS 2 WARNING LABEL ON THE LINE LASER

LASER CLASSIFICATION

The line laser is a laser class 2 laser product accortding to DIN IEC 60825-

1:2014 and Class II.

SAFETY INSTRUCTIONS

• Please follow up instructions given in operators’ manual.

• Do not stare into beam. Laser beam can lead to eye injury (even from

greater distances).

• Do not aim laser beam at persons or animals. The laser plane should

be set up above eye level of persons. Use the instrument for measuring

jobs only.

• Do not open instrument housing. Repairs should be carried out by au-

thorized workshops only. Please contact your local dealer.

• Do not remove warning labels or safety instructions.

• Keep instrument away from children.

• Do not use instrument in explosive environment.

7English

WARRANTY

This product is warranted by the manufacturer to the original purchaser to

be free from defects in material and workmanship under normal use for a

period of two (2) years from the date of purchase. During the warranty pe-

riod, and upon proof of purchase, the product will be repaired or replaced

(with the same or similar model at manufactures option), without charge

for either parts of labour. In case of a defect please contact the dealer

where you originally purchased this product. The warranty will not apply

to this product if it has been misused, abused or altered. Without limiting

the foregoing, leakage of the battery, bending or dropping the unit are

presumed to be defects resulting from misuse or abuse.

EXCEPTIONS FROM RESPONSIBILITY

The user of this product is expected to follow the instructions given in op-

erators’ manual. Although all instruments left our warehouse in perfect

condition and adjustment the user is expected to carry out periodic checks

of the product’s accuracy and general performance. The manufacturer,

or its representatives, assumes no responsibility of results of a faulty or

intentional usage or misuse including any direct, indirect, consequential

damage, and loss of prots. The manufacturer, or its representatives, as-

sumes no responsibility for consequential damage, and loss of prots by

any disaster (earthquake, storm, ood ...), re, accident, or an act of a third

party and/or a usage in other than usual conditions.

The manufacturer, or its representatives, assumes no responsibility for

any damage, and loss of prots due to a change of data, loss of data and

interruption of business etc., caused by using the product or an unusable

product. The manufacturer, or its representatives, assumes no responsi-

bility for any damage, and loss of prots caused by usage other thsn ex-

plained in the users’ manual.

The manufacturer, or its representatives, assumes no responsibility for

damage caused by wrong movement or action due to connecting with oth-

er products.

8English

WARRANTY DOESN’T EXTEND TO FOLLOWING CASES:

1. If the standard or serial product number will be changed, erased, re-

moved or wil be unreadable.

2. Periodic maintenance, repair or changing parts as a result of their nor-

mal runout.

3. All adaptations and modications with the purpose of improvement

and expansion of normal sphere of product application, mentioned in the

service instruction, without tentative written agreement of the expert pro-

vider.

4. Service by anyone other than an authorized service center.

5. Damage to products or parts caused by misuse, including, without lim-

itation, misapplication or nrgligence of the terms of service instruction.

6. Power supply units, chargers, accessories, wearing parts.

7. Products, damaged from mishandling, faulty adjustment, maintenance

with low-quality and non-standard materials, presence of any liquids and

foreign objects inside the product.

8. Acts of God and/or actions of third persons.

9. In case of unwarranted repair till the end of warranty period because

of damages during the operation of the product, it’s transportation and

storing, warranty doesn’t resume.

English

WARRANTY CARD

Name and model of the product __________________________________________

Serial number___________________________Date of sale______________________

Name of commercial organization ________________________________________

stamp of commercial organization

Warranty period for the instrument explotation is 24 months after the

date of original retail purchase.

During this warranty period the owner of the product has the right for

free repair of his instrument in case of manufacturing defects.

Warranty is valid only with original warranty card, fully and clear lled

(stamp or mark of thr seller is obligatory).

Technical examination of instruments for fault identication which is

under the warranty, is made only in the authorized service center.

In no event shall manufacturer be liable before the client for direct or

consequential damages, loss of prot or any other damage which occur

in the result of the instrument outage.

The product is received in the state of operability, without any visible

damages, in full completeness. It is tested in my presence. I have no

complaints to the product quality. I am familiar with the conditions of

qarranty service and i agree.

purchaser signature _______________________________

Before operating you should read service instruction!

If you have any questions about the warranty service and technical support contact

seller of this product

10 Russian

vertical line

horizontal line

90°

Tabla de contenidos

Idiomas:

Otros manuales de Instrumento de medición de ADA INSTRUMENTS

ADA INSTRUMENTS

ADA INSTRUMENTS COSMO 70eter Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ZHT 100 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS LASERMARKER 70 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS WHEEL 50 DIGITAL Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ProDigit MICRO Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ZFM 100 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ZSM 330 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS PaintMeter 1500 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS Cosmo 40 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS PROF X2 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS Robot Mini Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS 3D Liner 2V Green Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS PROF X15 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ROTARY 500 HV SERVO Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS TOPLINER 3-360 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS DigiTeo-2 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ZCM 130 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS COSMO MINI Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS AngleMeter 30 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ZHT 125 Electronic Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ProDigit MICRO Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS ROBOT-40 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS Cosmo 70 Manual de usuario

ADA INSTRUMENTS

ADA INSTRUMENTS PRODIGIT MARKER Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
