ACS ACR1255 Manual de usuario

Subject to change without prior notice [email protected]

www.acs.com.hk

Name Signature Date

Prepared by: Tommy Wong 2015-05-28

Reviewed by:

Approved by:

User Manual V1.00

ACR1255

NFCBluetooth

SmartCardReader

[email protected]

Version 1.00 www.acs.com.hk

Table of Contents

1.0.Introduction .............................................................................................................3

1.1.NFC and Smart Card Reader..............................................................................................3

1.2.Compact Design..................................................................................................................3

Firmware..............................................................................................................................3

1.3.Upgradeable Feature...........................................................................................................3

1.4.Bluetooth® Connectivity ......................................................................................................3

1.5.Ease of Integration...............................................................................................................3

2.0.Features ...................................................................................................................4

3.0.Typical Applications ...............................................................................................6

4.0.Technical Specifications ......................................................................................10 

[email protected]

Version 1.00 www.acs.com.hk

1.0.Introduction

ACR1255 NFC Bluetooth Smart Card Reader combines the latest 13.56 MHz contactless

technology with Bluetooth Smart connectivity for on-the-go smart card and NFC applications.

1.1. NFC and Smart Card Reader

ACR1255 supports ISO 14443 Type A and B smart

cards, MIFARE®, FeliCa®, and most NFC tags and devices

compliant with ISO 18092 standard. This makes it the ideal

device for a broad range of solutions, such as hands-free

verification for physical and logical access control, and

inventory tracking. ACR1255 has both Bluetooth

interface for pairing with mobile devices and USB Full Speed

for PC-linked operation. Additionally, it can read/write at

speeds of up to 424 Kbps for contactless smart card and NFC

device access.

1.2. Compact Design

With a compact design and a rechargeable Lithium-ion

battery for power, ACR1255 is extremely portable and

convenient for use anytime, anywhere with most Bluetooth-

enabled smartphones and tablets in the market.

1.3. Firmware Upgradeable Feature

of ACR1255 could conveniently be upgraded in-

field to allow users to cope with the fast-changing technology for their applications in order to suit

different scenarios.

1.4. Bluetooth® Connectivity

With Bluetooth® Low Energy (LE) 4.0 technology, ACR1255 can connect wirelessly with ease to

any device running on Android™ 4.3 and above, iOS 5.0 and above, Windows®, and Mac OS X®

operating systems.

1.5. Ease of Integration

ACR1255 could easily be installed for use with any PC running on Windows® operating system

because it is PC/SC and CCID compliant. Its drivers are also compatible with Linux® and Mac OS X®.

With its numerous features, the ACR12255 is the perfect Bluetooth NFC reader for your smart

card solution.

To save valuable cost and time, the firmware

[email protected]

Version 1.00 www.acs.com.hk

2.0.Features

USB 2.0 Full Speed Interface

Bluetooth Low Energy (LE) 4.0 Interface

Plug and Play – CCID support brings utmost mobility1

USB Firmware Upgradeability2

Smart Card Reader:

oBuilt-in antenna for contactless tag access, with reading distance of up to 60 mm

(depending on tag type)

oSupports ISO 14443 Part 4 Type A and B cards

oSupports MIFARE® and MIFARE DESFire®

oSupports FeliCa®

oSupports ISO 18092 Tags (NFC Tags)

oBuilt-in anti-collision feature (only one tag is accessed at any time)

oNFC Support:

oCard reader/writer mode

oCard emulation mode

oSupports AES-128 encryption algorithm

Application Programming Interface:

oSupports PC/SC3

oSupports CT-API (through wrapper on top of PC/SC)

Supports Android™ 4.3 and above4

Supports iOS 5.0 and above

Built-in Peripherals:

oTwo user-controllable bi-color LEDs

oUser-controllable buzzer

Compliant with the following standards:

oEN60950/IEC 60950

oISO 18092

oISO 14443

oCE

oFCC

oVCCI

oPC/SC

oCCID

1Applicable under PC-linked mode

2Same as above

3Same as above

4PC/SC and CCID support is not applicable.

[email protected]

Version 1.00 www.acs.com.hk

oBluetooth®QDL

oMicrosoft®WHQL

oRoHS2

oREACH

[email protected]

Version 1.00 www.acs.com.hk

3.0.Typical Applications

Mobile Banking & Payment

e-Government

e-Healthcare

Network Security

Access Control

e-Purse & Loyalty

Public Key Infrastructure

[email protected]

Version 1.00 www.acs.com.hk

4.0.Driver installation Procedure

The installation procedure is the same for Unified PC/SC Driver version 4.0.0.2 and above. The latest

device drivers of the ACS Smart Card Readers may be downloaded from the ACS Driver Download

Webpage:

http://acs.com.hk/en/drivers/

To install the ACS Driver:

1. In the ACS Unified Driver folder, run the file Setup.exe.

2. Select the language of your choice, and then click OK.

3. The Setup Wizard will be displayed. Click Next to proceed with the installation.

[email protected]

Version 1.00 www.acs.com.hk

4. Click Next to install the driver to the default folder located at X:\Program Files\Advanced

Card Systems Ltd\ACS Unified PCSC Driver 4.0.0.2\, with Xas the drive letter of you local

drive. Otherwise, click Change to choose another destination folder.

5. Click Install to begin the installation.

[email protected]

Version 1.00 www.acs.com.hk

6. Wait for the installation process to finish.

7. Once the driver installation is finished, click Finish to exit the setup wizard.

[email protected]

Version 1.00 www.acs.com.hk

5.0.Technical Specifications

Universal Serial Bus Interface

Type............................................... USB Full Speed, four lines: +5 V, GND, D+ and D-

Power Source................................. From USB

Speed............................................. 12 Mbps

Supply Voltage………………………Regulated 5V DC

Supply Current………………………<250mA

Battery Specification…………………Lithium-ion Battery (320mAh)

Firmware........................................ Upgradeable through USB interface

Bluetooth Interface

Type............................................... Bluetooth Smart 4.0

Power Source................................. From battery

Operating Frequency ..................... 2.4 GHz

Speed............................................. 1 Mbps (on-air data rate)

Contactless Smart Card Interface

Standard ........................................ ISO/IEC 18092 NFC, ISO 14443 Type A & B, MIFARE, DESFire, FeliCa

Protocol.......................................... ISO 14443 T=CL for ISO14443-4 compliant cards and T=CL Emulation for

MIFARE Classic 1K/4K, ISO 18092, FeliCa and NFC tags

Operating Frequency ..................... 13.56 MHz

Operating Distance ........................ Up to 60 mm (depending on tag type)

Smart Card Read/Write Speed....... 106 Kbps, 212 Kbps, 424 Kbps

Built-In Peripheral

LED................................................ 2, Bi-color (Red and Blue, Red and Green,)

Buzzer............................................ Monotone

Application Programming Interface

PC/SC

CT-API (through wrapper on top of PC/SC)
