Contents

TravelMate Notebook Series

Quick Guide

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

TravelMate Notebook Series Quick Guide

Original Issue: 08/2010

First things first

We would like to thank you for making an Acer notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the setup poster helps you get started with setting up your computer.

The TravelMate Series Generic User Guide contains useful information applying

to all models in the TravelMate product series. It covers basic topics such as

using the keyboard and audio, etc. Please understand that due to its nature, the

AcerSystem User Guide mentioned below will occasionally refer to functions or

features which are only contained in certain models of the series, but not

necessarily in the model you purchased. Such instances are marked in the text

with language such as "only for certain models".

This Quick Guide introduces you to the basic features and functions of your new

computer. For more on how your computer can help you to be more productive,

please refer to the AcerSystem User Guide. This guide contains detailed

information on such subjects as system utilities, data recovery, expansion

options and troubleshooting. In addition it contains warranty information and

the general regulations and safety notices for your notebook. It is available in

Portable Document Format (PDF) and comes preloaded on your notebook.

Follow these steps to access it:

1 Click on Start > All Programs > AcerSystem.

2 Click on AcerSystem User Guide.

Note: Viewing the file requires Adobe Reader. If Adobe Reader is not

installed on your computer, clicking on AcerSystem User Guide will run the

Adobe Reader setup program first. Follow the instructions on the screen to

complete the installation. For instructions on how to use Adobe Reader,

access the Help and Support menu.

English

Your Acer notebook tour

After setting up your computer as illustrated in the setup poster, let us show

you around your new Acer notebook.

Top view

#Icon Item Description

1Microphone Stereo internal microphone for sound

recording.

2Acer Crystal Eye

webcam

Web camera for video communication.

(only for certain models)

3Display screen Also called Liquid-Crystal Display (LCD),

displays computer output (Configuration

may vary by models).

English

Hotkeys

The computer employs hotkeys or key combinations to access most of the

computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the <Fn> key before pressing the other key

in the hotkey combination.

4Communication

indicator

Indicates the computer’s wireless

connectivity device status.

HDD indicator Indicates when the hard disk drive is

active.

5Power switch Turns the computer on and off.

6Speaker Delivers audio output.

7Keyboard For entering data into your computer.

8Touchpad Touch-sensitive pointing device which

functions like a computer mouse.

9Click buttons

(left and right)

The left and right buttons function like

the left and right mouse buttons.

10 Palmrest Comfortable support area for your

hands when you use the computer.

Hotkey Icon Function Description

<Fn> + <F3>Communication Enables / disables the computer’s

communication devices.

(Communication devices may vary by

configuration.)

<Fn> + <F4>Sleep Puts the computer in Sleep mode.

<Fn> + <F5>Display toggle Switches display output between the

display screen, external monitor (if

connected) and both.

<Fn> + <F6>Display off Turns the display screen backlight off

to save power. Press any key to

return.

<Fn> + <F7>Touchpad

toggle

Turns the touchpad on and off.

#Icon Item Description

English

Closed front view

#Icon Item Description

12-in-1 card reader Accepts Secure Digital (SD),

MultiMediaCard (MMC).

Note: Push to remove/install the card.

Only one card can operate at any given

time.

2Power indicator Indicates the computer's power status.

Battery indicator Indicates the computer's battery status.

1. Charging: The light shows amber when

the battery is charging.

2. Fully charged: The light shows blue

when in AC mode.

<Fn> + <F8>Speaker toggle Turns the speakers on and off.

<Fn> + < >Volume up Increases the sound volume.

<Fn> + < >Volume down Decreases the sound volume.

<Fn> + < >Brightness up Increases the screen brightness.

<Fn> + < >Brightness

down

Decreases the screen brightness.

Hotkey Icon Function Description

English

Rear view

#Icon Item Description

1Battery Provides power for the computer to be used while

unplugged.

Left view

12 73654

#Icon Item Description

1DC-in jack Connects to an AC adapter.

2Ventilation slots Enable the computer to stay cool,

even after prolonged use.

3External display

(VGA) port

Connects to a display device (e.g.,

external monitor, LCD projector).

4Ethernet (RJ-45)

port

Connects to an Ethernet 10/100/1000-

based network.

5HDMI port Supports high-definition digital video

connections.

6USB 2.0 port Connects to USB 2.0 devices

(e.g., USB mouse, USB camera).

7Microphone-in jack Accepts inputs from external

microphones.

Headphone/

speaker/line-out

jack

Connects to audio line-out devices

(e.g., speakers, headphones).

English

Right view

35 642

#Icon Item Description

1USB 2.0 ports Connect to USB 2.0 devices (e.g., USB

mouse, USB camera).

2Optical drive Internal optical drive; accepts CDs or

DVDs.

3Optical disk access

indicator

Lights up when the optical drive is active.

4Optical drive eject

button

Ejects the optical disk from the drive .

5Emergency eject

hole

Ejects the optical drive tray when the

computer is turned off.

Note: Insert a paper clip to the emergency

eject hole to eject the optical drive tray

when the computer is off.

6Kensington lock

slot

Connects to a Kensington-compatible

computer security lock.

Note: Wrap the computer security lock

cable around an immovable object such as

a table or handle of a locked drawer.

Insert the lock into the notch and turn the

key to secure the lock. Some keyless

models are also available.
